SMC MHM Magnet Gripper (Tube Bore 16 to 50 mm)

SMC MHM Magnet Gripper (Tube Bore 16 to 50 mm)

SMC MHM pneumatically operated magnet gripper that attracts and holds steel workpieces, including perforated and uneven sheets, and keeps holding them even when air is cut off.

Key features

  • Holds ferrous workpieces by a built-in magnet; holding is maintained at air supply loss (drop prevention)
  • Residual holding force 0.3 N or less after release
  • Body types: basic, holding force adjustable, center mount with M thread or G thread
  • Auto switches mountable on 2 faces (D-M9 series, magnetic-field-resistant P3DWA series), ordered as suffix
  • Replaceable packing; work contact cushion pads MHM-A1613 to A5013 and center mount adapters MHM-A1612 to A5012G available

Specifications

Fluid Air
Action Double acting
Operating pressure 0.2 to 0.6 MPa (work <= 2 mm); >2 mm: 0.2-0.6 (16, 25), 0.35-0.6 MPa (32, 50)
Proof pressure 0.9 MPa
Ambient and fluid temperature -10 to 60 C (no freezing)
Residual holding force 0.3 N or less
Lubrication Not required
Holding force note Theoretical, low-carbon steel plate covering whole surface
Source SMC Korea catalog MHM (SMCKR_MHM.pdf), p. 5-6 (PDF p. 6-7)
MHM-16D Tube bore: 16 mm | Body type: Basic | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 50 N / 50 N
MHM-16D1 Tube bore: 16 mm | Body type: Holding force adjustable | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 50 N / 50 N
MHM-16D2 Tube bore: 16 mm | Body type: Center mount (M thread) | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 50 N / 50 N
MHM-16D3 Tube bore: 16 mm | Body type: Center mount (G thread) | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 50 N / 50 N
MHM-25D Tube bore: 25 mm | Body type: Basic | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 160 N / 200 N
MHM-25D1 Tube bore: 25 mm | Body type: Holding force adjustable | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 160 N / 200 N
MHM-25D2 Tube bore: 25 mm | Body type: Center mount (M thread) | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 160 N / 200 N
MHM-25D3 Tube bore: 25 mm | Body type: Center mount (G thread) | Operating port: M5x0.8 | Holding force (2 / 6 mm work): 160 N / 200 N
MHM-32D Tube bore: 32 mm | Body type: Basic | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 250 N / 500 N
MHM-32D1 Tube bore: 32 mm | Body type: Holding force adjustable | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 250 N / 500 N
MHM-32D2 Tube bore: 32 mm | Body type: Center mount (M thread) | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 250 N / 500 N
MHM-32D3 Tube bore: 32 mm | Body type: Center mount (G thread) | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 250 N / 500 N
MHM-50D Tube bore: 50 mm | Body type: Basic | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 400 N / 1000 N
MHM-50D1 Tube bore: 50 mm | Body type: Holding force adjustable | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 400 N / 1000 N
MHM-50D2 Tube bore: 50 mm | Body type: Center mount (M thread) | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 400 N / 1000 N
MHM-50D3 Tube bore: 50 mm | Body type: Center mount (G thread) | Operating port: Rc1/8 | Holding force (2 / 6 mm work): 400 N / 1000 N
