SMC SL5400 High-Purity Regulator (Springless, Medium Flow)

SMC SL5400 High-Purity Regulator (Springless, Medium Flow)

SMC SL5400 series single-stage high-purity springless regulator for medium flow process gas lines, inlet up to 6.9 MPa.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; precision cleaned and helium leak tested
  • Springless construction: no poppet spring in the wetted area
  • Inlet up to 1000 psig (6.9 MPa); set pressure 0.007-0.2 to 0.014-0.7 MPa
  • Material S or SH (Ni-Cr-Mo poppet)
  • 2, 3 or 4-port bodies with 1/4, 3/8 or 1/2 face seal or tube weld connections
  • Listed codes: gauge ports "0" (1/4 face seal male port, no gauge); gauges (V3, L, 1, H, 2, 4, 40), MPA scale, VS/TF seat, HF high-flow and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Mounting Bottom mount (panel mount option P)
Internal finish Ra max 0.25 um, M (options 0.18/0.13 um)
Inlet pressure Vacuum to 6.9 MPa
Pressure characteristic 0.011 MPa rise per 0.7 MPa inlet drop
Internal volume 19 cm3
Mass 1.91 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 692-693
SL5402SM2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5402SM2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5402SM2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5402SM2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5402SM2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5402SM2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5402SM2PWFV8FV8 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal female
SL5402SM2PWMV8MV8 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal male
SL5402SM2PWTW8TW8 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 tube weld
SL5402SM3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5402SM3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5402SM3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5402SM3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5402SM3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5402SM3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5402SM3PWFV8FV80 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5402SM3PWMV8MV80 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5402SM3PWTW8TW80 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5402SM4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5402SM4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5402SM4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5402SM4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5402SM4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5402SM4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5402SM4PWFV8FV800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5402SM4PWMV8MV800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5402SM4PWTW8TW800 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5402SHM2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
SL5402SHM2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
SL5402SHM2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
SL5402SHM2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
SL5402SHM2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
SL5402SHM2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
SL5402SHM2PWFV8FV8 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal female
SL5402SHM2PWMV8MV8 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal male
SL5402SHM2PWTW8TW8 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 tube weld
SL5402SHM3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5402SHM3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5402SHM3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5402SHM3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5402SHM3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5402SHM3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5402SHM3PWFV8FV80 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5402SHM3PWMV8MV80 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5402SHM3PWTW8TW80 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5402SHM4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5402SHM4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5402SHM4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5402SHM4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5402SHM4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5402SHM4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5402SHM4PWFV8FV800 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5402SHM4PWMV8MV800 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5402SHM4PWTW8TW800 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5406SM2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5406SM2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5406SM2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5406SM2PWFV6FV6 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5406SM2PWMV6MV6 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5406SM2PWTW6TW6 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5406SM2PWFV8FV8 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal female
SL5406SM2PWMV8MV8 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal male
SL5406SM2PWTW8TW8 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 tube weld
SL5406SM3PWFV4FV40 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5406SM3PWMV4MV40 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5406SM3PWTW4TW40 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5406SM3PWFV6FV60 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5406SM3PWMV6MV60 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5406SM3PWTW6TW60 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5406SM3PWFV8FV80 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5406SM3PWMV8MV80 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5406SM3PWTW8TW80 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5406SM4PWFV4FV400 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5406SM4PWMV4MV400 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5406SM4PWTW4TW400 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5406SM4PWFV6FV600 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5406SM4PWMV6MV600 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5406SM4PWTW6TW600 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5406SM4PWFV8FV800 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5406SM4PWMV8MV800 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5406SM4PWTW8TW800 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5406SHM2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
SL5406SHM2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
SL5406SHM2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
SL5406SHM2PWFV6FV6 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
SL5406SHM2PWMV6MV6 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
SL5406SHM2PWTW6TW6 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
SL5406SHM2PWFV8FV8 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal female
SL5406SHM2PWMV8MV8 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal male
SL5406SHM2PWTW8TW8 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 tube weld
SL5406SHM3PWFV4FV40 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5406SHM3PWMV4MV40 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5406SHM3PWTW4TW40 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5406SHM3PWFV6FV60 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5406SHM3PWMV6MV60 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5406SHM3PWTW6TW60 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5406SHM3PWFV8FV80 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5406SHM3PWMV8MV80 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5406SHM3PWTW8TW80 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5406SHM4PWFV4FV400 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5406SHM4PWMV4MV400 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5406SHM4PWTW4TW400 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5406SHM4PWFV6FV600 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5406SHM4PWMV6MV600 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5406SHM4PWTW6TW600 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5406SHM4PWFV8FV800 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5406SHM4PWMV8MV800 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5406SHM4PWTW8TW800 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5410SM2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5410SM2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5410SM2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5410SM2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5410SM2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5410SM2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5410SM2PWFV8FV8 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal female
SL5410SM2PWMV8MV8 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal male
SL5410SM2PWTW8TW8 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 tube weld
SL5410SM3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5410SM3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5410SM3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5410SM3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5410SM3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5410SM3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5410SM3PWFV8FV80 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5410SM3PWMV8MV80 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5410SM3PWTW8TW80 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5410SM4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5410SM4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5410SM4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5410SM4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5410SM4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5410SM4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5410SM4PWFV8FV800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5410SM4PWMV8MV800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5410SM4PWTW8TW800 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5410SHM2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
SL5410SHM2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
SL5410SHM2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
SL5410SHM2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
SL5410SHM2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
SL5410SHM2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
SL5410SHM2PWFV8FV8 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal female
SL5410SHM2PWMV8MV8 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal male
SL5410SHM2PWTW8TW8 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 tube weld
SL5410SHM3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5410SHM3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5410SHM3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5410SHM3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5410SHM3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5410SHM3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5410SHM3PWFV8FV80 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5410SHM3PWMV8MV80 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5410SHM3PWTW8TW80 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5410SHM4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5410SHM4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5410SHM4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5410SHM4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5410SHM4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5410SHM4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5410SHM4PWFV8FV800 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5410SHM4PWMV8MV800 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5410SHM4PWTW8TW800 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
RegulatorsSMC
162 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC SL5400 High-Purity Regulator (Springless, Medium Flow)

Brand SMC·Regulators

Available part numbers (162)

SL5402SM2PWFV4FV4, SL5402SM2PWMV4MV4, SL5402SM2PWTW4TW4, SL5402SM2PWFV6FV6, SL5402SM2PWMV6MV6, SL5402SM2PWTW6TW6, SL5402SM2PWFV8FV8, SL5402SM2PWMV8MV8, SL5402SM2PWTW8TW8, SL5402SM3PWFV4FV40 + 152 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SL5402SM2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5402SM2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5402SM2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5402SM2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5402SM2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5402SM2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5402SM2PWFV8FV8Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal female
SL5402SM2PWMV8MV8Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal male
SL5402SM2PWTW8TW8Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 tube weld
SL5402SM3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5402SM3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5402SM3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5402SM3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5402SM3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5402SM3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5402SM3PWFV8FV80Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5402SM3PWMV8MV80Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5402SM3PWTW8TW80Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5402SM4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5402SM4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5402SM4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5402SM4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5402SM4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5402SM4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5402SM4PWFV8FV800Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5402SM4PWMV8MV800Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5402SM4PWTW8TW800Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5402SHM2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
SL5402SHM2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
SL5402SHM2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
SL5402SHM2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
SL5402SHM2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
SL5402SHM2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
SL5402SHM2PWFV8FV8Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal female
SL5402SHM2PWMV8MV8Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal male
SL5402SHM2PWTW8TW8Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 tube weld
SL5402SHM3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5402SHM3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5402SHM3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5402SHM3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5402SHM3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5402SHM3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5402SHM3PWFV8FV80Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5402SHM3PWMV8MV80Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5402SHM3PWTW8TW80Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5402SHM4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5402SHM4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5402SHM4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5402SHM4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5402SHM4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5402SHM4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5402SHM4PWFV8FV800Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5402SHM4PWMV8MV800Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5402SHM4PWTW8TW800Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5406SM2PWFV4FV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5406SM2PWMV4MV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5406SM2PWTW4TW4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5406SM2PWFV6FV6Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5406SM2PWMV6MV6Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5406SM2PWTW6TW6Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5406SM2PWFV8FV8Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal female
SL5406SM2PWMV8MV8Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal male
SL5406SM2PWTW8TW8Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 tube weld
SL5406SM3PWFV4FV40Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5406SM3PWMV4MV40Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5406SM3PWTW4TW40Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5406SM3PWFV6FV60Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5406SM3PWMV6MV60Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5406SM3PWTW6TW60Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5406SM3PWFV8FV80Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5406SM3PWMV8MV80Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5406SM3PWTW8TW80Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5406SM4PWFV4FV400Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5406SM4PWMV4MV400Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5406SM4PWTW4TW400Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5406SM4PWFV6FV600Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5406SM4PWMV6MV600Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5406SM4PWTW6TW600Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5406SM4PWFV8FV800Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5406SM4PWMV8MV800Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5406SM4PWTW8TW800Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5406SHM2PWFV4FV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
SL5406SHM2PWMV4MV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
SL5406SHM2PWTW4TW4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
SL5406SHM2PWFV6FV6Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
SL5406SHM2PWMV6MV6Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
SL5406SHM2PWTW6TW6Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
SL5406SHM2PWFV8FV8Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal female
SL5406SHM2PWMV8MV8Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal male
SL5406SHM2PWTW8TW8Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 tube weld
SL5406SHM3PWFV4FV40Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5406SHM3PWMV4MV40Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5406SHM3PWTW4TW40Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5406SHM3PWFV6FV60Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5406SHM3PWMV6MV60Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5406SHM3PWTW6TW60Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5406SHM3PWFV8FV80Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5406SHM3PWMV8MV80Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5406SHM3PWTW8TW80Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5406SHM4PWFV4FV400Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5406SHM4PWMV4MV400Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5406SHM4PWTW4TW400Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5406SHM4PWFV6FV600Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5406SHM4PWMV6MV600Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5406SHM4PWTW6TW600Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5406SHM4PWFV8FV800Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5406SHM4PWMV8MV800Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5406SHM4PWTW8TW800Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5410SM2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5410SM2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5410SM2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5410SM2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5410SM2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5410SM2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5410SM2PWFV8FV8Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal female
SL5410SM2PWMV8MV8Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 face seal male
SL5410SM2PWTW8TW8Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/2 tube weld
SL5410SM3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5410SM3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5410SM3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5410SM3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5410SM3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5410SM3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5410SM3PWFV8FV80Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5410SM3PWMV8MV80Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5410SM3PWTW8TW80Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5410SM4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5410SM4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5410SM4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5410SM4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5410SM4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5410SM4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5410SM4PWFV8FV800Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5410SM4PWMV8MV800Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5410SM4PWTW8TW800Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5410SHM2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal female
SL5410SHM2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 face seal male
SL5410SHM2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/4 tube weld
SL5410SHM2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal female
SL5410SHM2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 face seal male
SL5410SHM2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 3/8 tube weld
SL5410SHM2PWFV8FV8Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal female
SL5410SHM2PWMV8MV8Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 face seal male
SL5410SHM2PWTW8TW8Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 2 ports | Connection: 1/2 tube weld
SL5410SHM3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5410SHM3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5410SHM3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5410SHM3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5410SHM3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5410SHM3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5410SHM3PWFV8FV80Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5410SHM3PWMV8MV80Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5410SHM3PWTW8TW80Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5410SHM4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5410SHM4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5410SHM4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5410SHM4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5410SHM4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5410SHM4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5410SHM4PWFV8FV800Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5410SHM4PWMV8MV800Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5410SHM4PWTW8TW800Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
