SMC SL5500 High-Purity Regulator (Springless, Low Flow)

SMC SL5500 High-Purity Regulator (Springless, Low Flow)

SMC SL5500 series single-stage high-purity springless regulator for low flow (below 30 slpm) process gas lines, inlet up to 24.1 MPa.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; precision cleaned and helium leak tested
  • Springless construction: no poppet spring in the wetted area
  • Inlet up to 3500 psig (24.1 MPa); flow below 30 slpm
  • Set pressure 0.007-0.2 to 0.014-0.7 MPa; vacuum-regulation version SL5502..A
  • 2, 3 or 4-port bodies with 1/4 or 3/8 face seal or tube weld connections
  • Listed codes: gauge ports "0" (1/4 face seal male port, no gauge); gauges (V3, L, 1, H, 2, 4, 40), MPA scale, VS/TF seat, HF high-flow and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Mounting Bottom mount (panel mount option P)
Internal finish Ra max 0.25 um, M (options 0.18/0.13 um)
Inlet pressure Vacuum to 24.1 MPa
Internal volume 9 cm3
Mass 1.63 kg
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 690-691
SL5502SM2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SM2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SM2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SM2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SM2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SM2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SM3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SM3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SM3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SM3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SM3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SM3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SM4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SM4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SM4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SM4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SM4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SM4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5502SHM2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SHM2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SHM2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SHM2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SHM2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SHM2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SHM3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SHM3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SHM3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SHM3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SHM3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SHM3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SHM4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SHM4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SHM4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SHM4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SHM4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SHM4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5506SM2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5506SM2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5506SM2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5506SM2PWFV6FV6 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5506SM2PWMV6MV6 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5506SM2PWTW6TW6 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5506SM3PWFV4FV40 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5506SM3PWMV4MV40 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5506SM3PWTW4TW40 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5506SM3PWFV6FV60 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5506SM3PWMV6MV60 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5506SM3PWTW6TW60 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5506SM4PWFV4FV400 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5506SM4PWMV4MV400 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5506SM4PWTW4TW400 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5506SM4PWFV6FV600 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5506SM4PWMV6MV600 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5506SM4PWTW6TW600 Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5506SHM2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5506SHM2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5506SHM2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5506SHM2PWFV6FV6 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5506SHM2PWMV6MV6 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5506SHM2PWTW6TW6 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5506SHM3PWFV4FV40 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5506SHM3PWMV4MV40 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5506SHM3PWTW4TW40 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5506SHM3PWFV6FV60 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5506SHM3PWMV6MV60 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5506SHM3PWTW6TW60 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5506SHM4PWFV4FV400 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5506SHM4PWMV4MV400 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5506SHM4PWTW4TW400 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5506SHM4PWFV6FV600 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5506SHM4PWMV6MV600 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5506SHM4PWTW6TW600 Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5510SM2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5510SM2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5510SM2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5510SM2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5510SM2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5510SM2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5510SM3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5510SM3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5510SM3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5510SM3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5510SM3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5510SM3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5510SM4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5510SM4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5510SM4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5510SM4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5510SM4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5510SM4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5510SHM2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5510SHM2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5510SHM2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5510SHM2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5510SHM2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5510SHM2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5510SHM3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5510SHM3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5510SHM3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5510SHM3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5510SHM3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5510SHM3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5510SHM4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5510SHM4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5510SHM4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5510SHM4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5510SHM4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5510SHM4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5502SMA2PWFV4FV4 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SMA2PWMV4MV4 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SMA2PWTW4TW4 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SMA2PWFV6FV6 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SMA2PWMV6MV6 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SMA2PWTW6TW6 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SMA3PWFV4FV40 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SMA3PWMV4MV40 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SMA3PWTW4TW40 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SMA3PWFV6FV60 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SMA3PWMV6MV60 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SMA3PWTW6TW60 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SMA4PWFV4FV400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SMA4PWMV4MV400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SMA4PWTW4TW400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SMA4PWFV6FV600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SMA4PWMV6MV600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SMA4PWTW6TW600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5502SHMA2PWFV4FV4 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SHMA2PWMV4MV4 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SHMA2PWTW4TW4 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SHMA2PWFV6FV6 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SHMA2PWMV6MV6 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SHMA2PWTW6TW6 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SHMA3PWFV4FV40 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SHMA3PWMV4MV40 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SHMA3PWTW4TW40 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SHMA3PWFV6FV60 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SHMA3PWMV6MV60 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SHMA3PWTW6TW60 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SHMA4PWFV4FV400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SHMA4PWMV4MV400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SHMA4PWTW4TW400 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SHMA4PWFV6FV600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SHMA4PWMV6MV600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SHMA4PWTW6TW600 Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
RegulatorsSMC
144 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC SL5500 High-Purity Regulator (Springless, Low Flow)

Brand SMC·Regulators

Available part numbers (144)

SL5502SM2PWFV4FV4, SL5502SM2PWMV4MV4, SL5502SM2PWTW4TW4, SL5502SM2PWFV6FV6, SL5502SM2PWMV6MV6, SL5502SM2PWTW6TW6, SL5502SM3PWFV4FV40, SL5502SM3PWMV4MV40, SL5502SM3PWTW4TW40, SL5502SM3PWFV6FV60 + 134 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SL5502SM2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SM2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SM2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SM2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SM2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SM2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SM3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SM3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SM3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SM3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SM3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SM3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SM4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SM4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SM4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SM4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SM4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SM4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5502SHM2PWFV4FV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SHM2PWMV4MV4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SHM2PWTW4TW4Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SHM2PWFV6FV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SHM2PWMV6MV6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SHM2PWTW6TW6Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SHM3PWFV4FV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SHM3PWMV4MV40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SHM3PWTW4TW40Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SHM3PWFV6FV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SHM3PWMV6MV60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SHM3PWTW6TW60Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SHM4PWFV4FV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SHM4PWMV4MV400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SHM4PWTW4TW400Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SHM4PWFV6FV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SHM4PWMV6MV600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SHM4PWTW6TW600Set pressure: 0.007 to 0.2 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5506SM2PWFV4FV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5506SM2PWMV4MV4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5506SM2PWTW4TW4Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5506SM2PWFV6FV6Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5506SM2PWMV6MV6Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5506SM2PWTW6TW6Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5506SM3PWFV4FV40Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5506SM3PWMV4MV40Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5506SM3PWTW4TW40Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5506SM3PWFV6FV60Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5506SM3PWMV6MV60Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5506SM3PWTW6TW60Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5506SM4PWFV4FV400Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5506SM4PWMV4MV400Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5506SM4PWTW4TW400Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5506SM4PWFV6FV600Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5506SM4PWMV6MV600Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5506SM4PWTW6TW600Set pressure: 0.007 to 0.4 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5506SHM2PWFV4FV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5506SHM2PWMV4MV4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5506SHM2PWTW4TW4Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5506SHM2PWFV6FV6Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5506SHM2PWMV6MV6Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5506SHM2PWTW6TW6Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5506SHM3PWFV4FV40Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5506SHM3PWMV4MV40Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5506SHM3PWTW4TW40Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5506SHM3PWFV6FV60Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5506SHM3PWMV6MV60Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5506SHM3PWTW6TW60Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5506SHM4PWFV4FV400Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5506SHM4PWMV4MV400Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5506SHM4PWTW4TW400Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5506SHM4PWFV6FV600Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5506SHM4PWMV6MV600Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5506SHM4PWTW6TW600Set pressure: 0.007 to 0.4 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5510SM2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5510SM2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5510SM2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5510SM2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5510SM2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5510SM2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5510SM3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5510SM3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5510SM3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5510SM3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5510SM3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5510SM3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5510SM4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5510SM4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5510SM4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5510SM4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5510SM4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5510SM4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5510SHM2PWFV4FV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5510SHM2PWMV4MV4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5510SHM2PWTW4TW4Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5510SHM2PWFV6FV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5510SHM2PWMV6MV6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5510SHM2PWTW6TW6Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5510SHM3PWFV4FV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5510SHM3PWMV4MV40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5510SHM3PWTW4TW40Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5510SHM3PWFV6FV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5510SHM3PWMV6MV60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5510SHM3PWTW6TW60Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5510SHM4PWFV4FV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5510SHM4PWMV4MV400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5510SHM4PWTW4TW400Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5510SHM4PWFV6FV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5510SHM4PWMV6MV600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5510SHM4PWTW6TW600Set pressure: 0.014 to 0.7 MPa | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5502SMA2PWFV4FV4Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SMA2PWMV4MV4Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SMA2PWTW4TW4Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SMA2PWFV6FV6Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SMA2PWMV6MV6Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SMA2PWTW6TW6Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SMA3PWFV4FV40Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SMA3PWMV4MV40Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SMA3PWTW4TW40Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SMA3PWFV6FV60Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SMA3PWMV6MV60Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SMA3PWTW6TW60Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SMA4PWFV4FV400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SMA4PWMV4MV400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SMA4PWTW4TW400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SMA4PWFV6FV600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SMA4PWMV6MV600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SMA4PWTW6TW600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: SUS316L (standard) | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5502SHMA2PWFV4FV4Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal female
SL5502SHMA2PWMV4MV4Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 face seal male
SL5502SHMA2PWTW4TW4Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 1/4 tube weld
SL5502SHMA2PWFV6FV6Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal female
SL5502SHMA2PWMV6MV6Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 face seal male
SL5502SHMA2PWTW6TW6Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 2 ports | Connection: 3/8 tube weld
SL5502SHMA3PWFV4FV40Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5502SHMA3PWMV4MV40Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5502SHMA3PWTW4TW40Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5502SHMA3PWFV6FV60Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5502SHMA3PWMV6MV60Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5502SHMA3PWTW6TW60Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5502SHMA4PWFV4FV400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5502SHMA4PWMV4MV400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5502SHMA4PWTW4TW400Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5502SHMA4PWFV6FV600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5502SHMA4PWMV6MV600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5502SHMA4PWTW6TW600Set pressure: -88 kPa to 0.2 MPa (vacuum regulation) | Material: Ni-Cr-Mo poppet/diaphragm | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
