SMC SL5800 High-Purity Regulator (Springless, Medium Flow, 2.1 MPa)

SMC SL5800 High-Purity Regulator (Springless, Medium Flow, 2.1 MPa)

SMC SL5800 series single-stage high-purity springless regulator for medium flow (below 200 slpm) process gas lines, inlet up to 2.1 MPa.

Key features

  • High-purity SUS316L double-melt body, electropolished and passivated; precision cleaned and helium leak tested
  • Springless construction: no poppet spring in the wetted area
  • Inlet up to 300 psig (2.1 MPa); flow below 200 slpm
  • Set pressure 0.007-0.2 to 0.014-0.7 MPa
  • 2, 3 or 4-port bodies with 1/4, 3/8 or 1/2 face seal or tube weld connections
  • Listed codes: gauge ports "0" (1/4 face seal male port, no gauge); gauges (V3, L, 1, H, 2, 4, 40), MPA scale, VS/TF seat, HF high-flow and panel mount (P) are ordered as suffixes

Specifications

Fluid Gases that do not corrode wetted parts
Leakage Inboard 2x10^-11, outboard 2x10^-10 Pa m3/s
Ambient and fluid temperature -40 to 71 C (no freezing)
Mounting Bottom mount (panel mount option P)
Internal finish Ra max 0.25 um, M (options 0.18/0.13 um)
Inlet pressure Vacuum to 2.1 MPa
Pressure characteristic 0.035 MPa rise per 0.7 MPa inlet drop
Internal volume 19.7 cm3
Mass 1.91 kg
Material SUS316L
Source SMC Korea catalog Process Gas Equipment (SMCKR_AP_SL_AZ_AK_BP.pdf), p. 694-695
SL5802SM2PWFV4FV4 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 1/4 face seal female
SL5802SM2PWMV4MV4 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 1/4 face seal male
SL5802SM2PWTW4TW4 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 1/4 tube weld
SL5802SM2PWFV6FV6 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 3/8 face seal female
SL5802SM2PWMV6MV6 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 3/8 face seal male
SL5802SM2PWTW6TW6 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 3/8 tube weld
SL5802SM2PWFV8FV8 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 1/2 face seal female
SL5802SM2PWMV8MV8 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 1/2 face seal male
SL5802SM2PWTW8TW8 Set pressure: 0.007 to 0.2 MPa | Ports: 2 ports | Connection: 1/2 tube weld
SL5802SM3PWFV4FV40 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5802SM3PWMV4MV40 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5802SM3PWTW4TW40 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5802SM3PWFV6FV60 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5802SM3PWMV6MV60 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5802SM3PWTW6TW60 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5802SM3PWFV8FV80 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5802SM3PWMV8MV80 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5802SM3PWTW8TW80 Set pressure: 0.007 to 0.2 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5802SM4PWFV4FV400 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5802SM4PWMV4MV400 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5802SM4PWTW4TW400 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5802SM4PWFV6FV600 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5802SM4PWMV6MV600 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5802SM4PWTW6TW600 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5802SM4PWFV8FV800 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5802SM4PWMV8MV800 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5802SM4PWTW8TW800 Set pressure: 0.007 to 0.2 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5806SM2PWFV4FV4 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 1/4 face seal female
SL5806SM2PWMV4MV4 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 1/4 face seal male
SL5806SM2PWTW4TW4 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 1/4 tube weld
SL5806SM2PWFV6FV6 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 3/8 face seal female
SL5806SM2PWMV6MV6 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 3/8 face seal male
SL5806SM2PWTW6TW6 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 3/8 tube weld
SL5806SM2PWFV8FV8 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 1/2 face seal female
SL5806SM2PWMV8MV8 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 1/2 face seal male
SL5806SM2PWTW8TW8 Set pressure: 0.007 to 0.4 MPa | Ports: 2 ports | Connection: 1/2 tube weld
SL5806SM3PWFV4FV40 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5806SM3PWMV4MV40 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5806SM3PWTW4TW40 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5806SM3PWFV6FV60 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5806SM3PWMV6MV60 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5806SM3PWTW6TW60 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5806SM3PWFV8FV80 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5806SM3PWMV8MV80 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5806SM3PWTW8TW80 Set pressure: 0.007 to 0.4 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5806SM4PWFV4FV400 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5806SM4PWMV4MV400 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5806SM4PWTW4TW400 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5806SM4PWFV6FV600 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5806SM4PWMV6MV600 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5806SM4PWTW6TW600 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5806SM4PWFV8FV800 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5806SM4PWMV8MV800 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5806SM4PWTW8TW800 Set pressure: 0.007 to 0.4 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
SL5810SM2PWFV4FV4 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 1/4 face seal female
SL5810SM2PWMV4MV4 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 1/4 face seal male
SL5810SM2PWTW4TW4 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 1/4 tube weld
SL5810SM2PWFV6FV6 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 3/8 face seal female
SL5810SM2PWMV6MV6 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 3/8 face seal male
SL5810SM2PWTW6TW6 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 3/8 tube weld
SL5810SM2PWFV8FV8 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 1/2 face seal female
SL5810SM2PWMV8MV8 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 1/2 face seal male
SL5810SM2PWTW8TW8 Set pressure: 0.014 to 0.7 MPa | Ports: 2 ports | Connection: 1/2 tube weld
SL5810SM3PWFV4FV40 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 face seal female
SL5810SM3PWMV4MV40 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 face seal male
SL5810SM3PWTW4TW40 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 1/4 tube weld
SL5810SM3PWFV6FV60 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 face seal female
SL5810SM3PWMV6MV60 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 face seal male
SL5810SM3PWTW6TW60 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 3/8 tube weld
SL5810SM3PWFV8FV80 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 face seal female
SL5810SM3PWMV8MV80 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 face seal male
SL5810SM3PWTW8TW80 Set pressure: 0.014 to 0.7 MPa | Ports: 3 ports (gauge port) | Connection: 1/2 tube weld
SL5810SM4PWFV4FV400 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal female
SL5810SM4PWMV4MV400 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 face seal male
SL5810SM4PWTW4TW400 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/4 tube weld
SL5810SM4PWFV6FV600 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal female
SL5810SM4PWMV6MV600 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 face seal male
SL5810SM4PWTW6TW600 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 3/8 tube weld
SL5810SM4PWFV8FV800 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal female
SL5810SM4PWMV8MV800 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 face seal male
SL5810SM4PWTW8TW800 Set pressure: 0.014 to 0.7 MPa | Ports: 4 ports (IN + OUT gauge) | Connection: 1/2 tube weld
RegulatorsSMC
81 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC SL5800 High-Purity Regulator (Springless, Medium Flow, 2.1 MPa)

Brand SMC·Regulators

Available part numbers (81)

SL5802SM2PWFV4FV4, SL5802SM2PWMV4MV4, SL5802SM2PWTW4TW4, SL5802SM2PWFV6FV6, SL5802SM2PWMV6MV6, SL5802SM2PWTW6TW6, SL5802SM2PWFV8FV8, SL5802SM2PWMV8MV8, SL5802SM2PWTW8TW8, SL5802SM3PWFV4FV40 + 71 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
