SMC SX10 High Speed 2-Port Valve (9 mm Width, up to 1200 Hz)

SMC SX10 High Speed 2-Port Valve (9 mm Width, up to 1200 Hz)

SMC SX10 series 9 mm wide high-speed 2-port N.C. valve for air, with flow rates of 50 to 150 L/min and switching frequencies up to 1200 Hz.

Key features

  • High-speed response: ON 0.45 ms / OFF 0.4 ms (50 L/min, 80 W type); up to 1200 Hz
  • Long life: 5 billion cycles or more (50 L/min, DC24V, 0.25 MPa, SMC test conditions)
  • Power consumption 80 W/40 W (power-saving driver required), 10 W, or 4 W for continuous energizing
  • Screw mounting (M3 screws and gasket included) or quick-release type; optional IN-port filter
  • Manifold base to be prepared by the customer

Specifications

Valve type 2-position 2-port N.C., air return
Seal Metal poppet seal
Valve width 9 mm
Fluid Air
Min. operating pressure 0.15 MPa
Max. operating pressure 0.25 to 0.7 MPa (by type, DC24V)
Ambient and fluid temperature -10 to 50°C (no freezing)
Lubrication Not allowed
Rated voltage DC24V
Electrical entry Grommet
Mass 27 g (screw), 29 g (quick release)
Source SMC Korea catalog SX10 Series (SMCKR_SX10-A.pdf), p. 505-511 (PDF p. 1-7)
SX11-AG Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX11-AH Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX11-AJ Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX11-BG Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX11-BH Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX11-BJ Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX11-CG Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX11-CH Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX11-CJ Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX11-DG Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX11-DH Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX11-DJ Mounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX11-EG Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX11-EH Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX11-EJ Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX11-FG Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX11-FH Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX11-FJ Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX11-GG Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX11-GH Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX11-GJ Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX11-HG Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX11-HH Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX11-HJ Mounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX11-JG Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX11-JH Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX11-JJ Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX11-KG Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX11-KH Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX11-KJ Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX11-LG Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX11-LH Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX11-LJ Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX11-MG Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX11-MH Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX11-MJ Mounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
SX11F-AG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX11F-AH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX11F-AJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX11F-BG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX11F-BH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX11F-BJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX11F-CG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX11F-CH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX11F-CJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX11F-DG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX11F-DH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX11F-DJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX11F-EG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX11F-EH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX11F-EJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX11F-FG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX11F-FH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX11F-FJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX11F-GG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX11F-GH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX11F-GJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX11F-HG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX11F-HH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX11F-HJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX11F-JG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX11F-JH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX11F-JJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX11F-KG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX11F-KH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX11F-KJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX11F-LG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX11F-LH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX11F-LJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX11F-MG Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX11F-MH Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX11F-MJ Mounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
SX12-AG Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX12-AH Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX12-AJ Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX12-BG Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX12-BH Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX12-BJ Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX12-CG Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX12-CH Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX12-CJ Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX12-DG Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX12-DH Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX12-DJ Mounting: Quick release | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX12-EG Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX12-EH Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX12-EJ Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX12-FG Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX12-FH Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX12-FJ Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX12-GG Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX12-GH Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX12-GJ Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX12-HG Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX12-HH Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX12-HJ Mounting: Quick release | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX12-JG Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX12-JH Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX12-JJ Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX12-KG Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX12-KH Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX12-KJ Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX12-LG Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX12-LH Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX12-LJ Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX12-MG Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX12-MH Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX12-MJ Mounting: Quick release | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
SX12F-AG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX12F-AH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX12F-AJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX12F-BG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX12F-BH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX12F-BJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX12F-CG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX12F-CH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX12F-CJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX12F-DG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX12F-DH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX12F-DJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX12F-EG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX12F-EH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX12F-EJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX12F-FG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX12F-FH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX12F-FJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX12F-GG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX12F-GH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX12F-GJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX12F-HG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX12F-HH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX12F-HJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX12F-JG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX12F-JH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX12F-JJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX12F-KG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX12F-KH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX12F-KJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX12F-LG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX12F-LH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX12F-LJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX12F-MG Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX12F-MH Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX12F-MJ Mounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
2-Port ValvesSMC
144 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC SX10 High Speed 2-Port Valve (9 mm Width, up to 1200 Hz)

Brand SMC·2-Port Valves

Available part numbers (144)

SX11-AG, SX11-AH, SX11-AJ, SX11-BG, SX11-BH, SX11-BJ, SX11-CG, SX11-CH, SX11-CJ, SX11-DG + 134 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SX11-AGMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX11-AHMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX11-AJMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX11-BGMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX11-BHMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX11-BJMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX11-CGMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX11-CHMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX11-CJMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX11-DGMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX11-DHMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX11-DJMounting: Screw mounting | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX11-EGMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX11-EHMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX11-EJMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX11-FGMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX11-FHMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX11-FJMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX11-GGMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX11-GHMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX11-GJMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX11-HGMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX11-HHMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX11-HJMounting: Screw mounting | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX11-JGMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX11-JHMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX11-JJMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX11-KGMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX11-KHMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX11-KJMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX11-LGMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX11-LHMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX11-LJMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX11-MGMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX11-MHMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX11-MJMounting: Screw mounting | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
SX11F-AGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX11F-AHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX11F-AJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX11F-BGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX11F-BHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX11F-BJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX11F-CGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX11F-CHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX11F-CJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX11F-DGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX11F-DHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX11F-DJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX11F-EGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX11F-EHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX11F-EJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX11F-FGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX11F-FHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX11F-FJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX11F-GGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX11F-GHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX11F-GJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX11F-HGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX11F-HHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX11F-HJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX11F-JGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX11F-JHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX11F-JJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX11F-KGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX11F-KHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX11F-KJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX11F-LGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX11F-LHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX11F-LJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX11F-MGMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX11F-MHMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX11F-MJMounting: Screw mounting | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
SX12-AGMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX12-AHMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX12-AJMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX12-BGMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX12-BHMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX12-BJMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX12-CGMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX12-CHMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX12-CJMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX12-DGMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX12-DHMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX12-DJMounting: Quick release | Filter: Without | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX12-EGMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX12-EHMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX12-EJMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX12-FGMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX12-FHMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX12-FJMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX12-GGMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX12-GHMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX12-GJMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX12-HGMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX12-HHMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX12-HJMounting: Quick release | Filter: Without | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX12-JGMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX12-JHMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX12-JJMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX12-KGMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX12-KHMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX12-KJMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX12-LGMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX12-LHMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX12-LJMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX12-MGMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX12-MHMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX12-MJMounting: Quick release | Filter: Without | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm
SX12F-AGMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 300 mm
SX12F-AHMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 500 mm
SX12F-AJMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 80 W, 1200 Hz | Lead wire: 1000 mm
SX12F-BGMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 300 mm
SX12F-BHMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 500 mm
SX12F-BJMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 40 W, 1000 Hz | Lead wire: 1000 mm
SX12F-CGMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 300 mm
SX12F-CHMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 500 mm
SX12F-CJMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 10 W, 550 Hz | Lead wire: 1000 mm
SX12F-DGMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 300 mm
SX12F-DHMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 500 mm
SX12F-DJMounting: Quick release | Filter: With IN-port filter | Flow/power: 50 L/min, 4 W, 350 Hz | Lead wire: 1000 mm
SX12F-EGMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 300 mm
SX12F-EHMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 500 mm
SX12F-EJMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 80 W, 650 Hz | Lead wire: 1000 mm
SX12F-FGMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 300 mm
SX12F-FHMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 500 mm
SX12F-FJMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 40 W, 550 Hz | Lead wire: 1000 mm
SX12F-GGMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 300 mm
SX12F-GHMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 500 mm
SX12F-GJMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 10 W, 300 Hz | Lead wire: 1000 mm
SX12F-HGMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 300 mm
SX12F-HHMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 500 mm
SX12F-HJMounting: Quick release | Filter: With IN-port filter | Flow/power: 100 L/min, 4 W, 200 Hz | Lead wire: 1000 mm
SX12F-JGMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 300 mm
SX12F-JHMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 500 mm
SX12F-JJMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 80 W, 600 Hz | Lead wire: 1000 mm
SX12F-KGMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 300 mm
SX12F-KHMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 500 mm
SX12F-KJMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 40 W, 500 Hz | Lead wire: 1000 mm
SX12F-LGMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 300 mm
SX12F-LHMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 500 mm
SX12F-LJMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 10 W, 250 Hz | Lead wire: 1000 mm
SX12F-MGMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 300 mm
SX12F-MHMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 500 mm
SX12F-MJMounting: Quick release | Filter: With IN-port filter | Flow/power: 150 L/min, 4 W, 150 Hz | Lead wire: 1000 mm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
