SMC SYJ 5-Port Solenoid Valve (SYJ3000/5000/7000, Single Unit)

SMC SYJ series compact rubber-seal pilot-operated 5-port solenoid valve, body ported or base mounted, in three body sizes with 2- and 3-position switching.

Key features

Rubber seal spool valve; stainless steel pilot valve cover and M2 mounting screws for improved strength
Five switching types: 2-position single/double and 3-position closed, exhaust and pressure center
Body ported (20 type) or base mounted with or without sub-plate (40 type); 4-port base mounted (30 type) is for manifolds only
Listed codes cover DC24V, AC100V and AC200V with grommet, L or M plug connector; DC12V/6V/5V/3V, AC110V/220V, DIN terminal (SYJ5000/7000) and M8 connector on order
Power-saving circuit (T, 0.1 W holding), light/surge suppressor (S, Z, R, U), common exhaust body (3), locking manual override (D, E), bracket (F) and G/NPT/NPTF threads are suffix options
Matching manifolds SS5YJ3/5/7 (20, 21P, 21SA, 32, 41, 42 types and EX510 serial) are ordered separately

Specifications

Fluid	Air
Operating pressure	0.15 to 0.7 MPa (2-pos single), 0.1 to 0.7 MPa (2-pos double), 0.2 to 0.7 MPa (3-pos)
Ambient and fluid temperature	-10 to 50°C (no freezing)
Lubrication	Not required
Mounting orientation	Unrestricted
Impact/vibration resistance	150/30 m/s²
Enclosure	Dustproof (M8 connector IP65)
Allowable voltage fluctuation	±10% of rated voltage
Power consumption (DC)	0.35 W (with light 0.4 W), SYJ3000
Flow rate C [dm³/(s·bar)]	SYJ3000 0.46, SYJ5000 0.83, SYJ7000 2.9
Source	SMC Korea catalog SYJ3000/5000/7000 (SMCKR_SYJ3000_5000_7000.pdf), p. 143, 148-150, 178, 210 (PDF p. 1, 6-8, 38, 72)

SYJ3120-5G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3120-5L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3120-5M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3120-1G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3120-1L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3120-1M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3120-2G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3120-2L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3120-2M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3220-5G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3220-5L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3220-5M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3220-1G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3220-1L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3220-1M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3220-2G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3220-2L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3220-2M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3320-5G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3320-5L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3320-5M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3320-1G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3320-1L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3320-1M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3320-2G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3320-2L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3320-2M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3420-5G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3420-5L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3420-5M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3420-1G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3420-1L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3420-1M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3420-2G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3420-2L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3420-2M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3520-5G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3520-5L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3520-5M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3520-1G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3520-1L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3520-1M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3520-2G-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
SYJ3520-2L-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
SYJ3520-2M-M3		Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
SYJ3140-5G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3140-5G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3140-5L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3140-5L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3140-5M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3140-5M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3140-1G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3140-1G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3140-1L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3140-1L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3140-1M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3140-1M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3140-2G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3140-2G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3140-2L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3140-2L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3140-2M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3140-2M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3240-5G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3240-5G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3240-5L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3240-5L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3240-5M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3240-5M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3240-1G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3240-1G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3240-1L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3240-1L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3240-1M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3240-1M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3240-2G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3240-2G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3240-2L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3240-2L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3240-2M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3240-2M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3340-5G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3340-5G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3340-5L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3340-5L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3340-5M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3340-5M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3340-1G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3340-1G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3340-1L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3340-1L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3340-1M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3340-1M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3340-2G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3340-2G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3340-2L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3340-2L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3340-2M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3340-2M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3440-5G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3440-5G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3440-5L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3440-5L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3440-5M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3440-5M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3440-1G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3440-1G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3440-1L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3440-1L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3440-1M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3440-1M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3440-2G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3440-2G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3440-2L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3440-2L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3440-2M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3440-2M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3540-5G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3540-5G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3540-5L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3540-5L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3540-5M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3540-5M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3540-1G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3540-1G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3540-1L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3540-1L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3540-1M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3540-1M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ3540-2G		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ3540-2G-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
SYJ3540-2L		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ3540-2L-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
SYJ3540-2M		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ3540-2M-M5		Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
SYJ5120-5G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5120-5G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5120-5G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5120-5L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5120-5L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5120-5L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5120-5M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5120-5M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5120-5M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5120-1G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5120-1G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5120-1G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5120-1L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5120-1L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5120-1L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5120-1M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5120-1M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5120-1M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5120-2G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5120-2G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5120-2G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5120-2L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5120-2L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5120-2L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5120-2M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5120-2M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5120-2M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5220-5G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5220-5G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5220-5G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5220-5L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5220-5L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5220-5L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5220-5M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5220-5M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5220-5M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5220-1G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5220-1G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5220-1G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5220-1L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5220-1L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5220-1L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5220-1M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5220-1M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5220-1M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5220-2G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5220-2G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5220-2G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5220-2L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5220-2L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5220-2L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5220-2M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5220-2M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5220-2M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5320-5G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5320-5G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5320-5G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5320-5L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5320-5L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5320-5L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5320-5M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5320-5M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5320-5M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5320-1G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5320-1G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5320-1G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5320-1L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5320-1L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5320-1L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5320-1M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5320-1M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5320-1M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5320-2G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5320-2G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5320-2G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5320-2L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5320-2L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5320-2L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5320-2M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5320-2M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5320-2M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5420-5G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5420-5G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5420-5G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5420-5L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5420-5L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5420-5L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5420-5M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5420-5M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5420-5M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5420-1G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5420-1G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5420-1G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5420-1L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5420-1L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5420-1L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5420-1M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5420-1M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5420-1M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5420-2G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5420-2G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5420-2G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5420-2L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5420-2L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5420-2L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5420-2M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5420-2M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5420-2M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5520-5G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5520-5G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5520-5G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5520-5L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5520-5L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5520-5L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5520-5M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5520-5M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5520-5M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5520-1G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5520-1G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5520-1G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5520-1L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5520-1L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5520-1L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5520-1M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5520-1M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5520-1M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5520-2G-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
SYJ5520-2G-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
SYJ5520-2G-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ5520-2L-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
SYJ5520-2L-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
SYJ5520-2L-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ5520-2M-M5		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
SYJ5520-2M-C4		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
SYJ5520-2M-C6		Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ5140-5G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5140-5G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5140-5L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5140-5L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5140-5M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5140-5M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5140-1G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5140-1G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5140-1L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5140-1L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5140-1M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5140-1M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5140-2G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5140-2G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5140-2L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5140-2L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5140-2M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5140-2M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5240-5G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5240-5G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5240-5L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5240-5L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5240-5M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5240-5M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5240-1G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5240-1G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5240-1L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5240-1L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5240-1M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5240-1M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5240-2G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5240-2G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5240-2L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5240-2L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5240-2M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5240-2M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5340-5G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5340-5G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5340-5L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5340-5L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5340-5M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5340-5M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5340-1G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5340-1G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5340-1L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5340-1L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5340-1M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5340-1M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5340-2G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5340-2G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5340-2L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5340-2L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5340-2M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5340-2M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5440-5G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5440-5G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5440-5L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5440-5L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5440-5M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5440-5M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5440-1G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5440-1G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5440-1L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5440-1L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5440-1M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5440-1M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5440-2G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5440-2G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5440-2L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5440-2L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5440-2M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5440-2M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5540-5G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5540-5G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5540-5L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5540-5L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5540-5M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5540-5M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5540-1G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5540-1G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5540-1L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5540-1L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5540-1M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5540-1M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ5540-2G		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ5540-2G-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ5540-2L		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ5540-2L-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ5540-2M		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ5540-2M-01		Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7120-5G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7120-5G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7120-5G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7120-5L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7120-5L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7120-5L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7120-5M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7120-5M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7120-5M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7120-1G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7120-1G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7120-1G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7120-1L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7120-1L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7120-1L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7120-1M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7120-1M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7120-1M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7120-2G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7120-2G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7120-2G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7120-2L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7120-2L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7120-2L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7120-2M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7120-2M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7120-2M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7220-5G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7220-5G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7220-5G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7220-5L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7220-5L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7220-5L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7220-5M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7220-5M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7220-5M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7220-1G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7220-1G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7220-1G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7220-1L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7220-1L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7220-1L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7220-1M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7220-1M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7220-1M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7220-2G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7220-2G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7220-2G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7220-2L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7220-2L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7220-2L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7220-2M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7220-2M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7220-2M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7320-5G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7320-5G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7320-5G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7320-5L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7320-5L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7320-5L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7320-5M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7320-5M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7320-5M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7320-1G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7320-1G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7320-1G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7320-1L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7320-1L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7320-1L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7320-1M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7320-1M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7320-1M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7320-2G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7320-2G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7320-2G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7320-2L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7320-2L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7320-2L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7320-2M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7320-2M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7320-2M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7420-5G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7420-5G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7420-5G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7420-5L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7420-5L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7420-5L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7420-5M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7420-5M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7420-5M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7420-1G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7420-1G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7420-1G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7420-1L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7420-1L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7420-1L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7420-1M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7420-1M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7420-1M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7420-2G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7420-2G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7420-2G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7420-2L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7420-2L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7420-2L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7420-2M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7420-2M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7420-2M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7520-5G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7520-5G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7520-5G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7520-5L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7520-5L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7520-5L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7520-5M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7520-5M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7520-5M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7520-1G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7520-1G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7520-1G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7520-1L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7520-1L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7520-1L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7520-1M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7520-1M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7520-1M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7520-2G-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
SYJ7520-2G-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
SYJ7520-2G-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
SYJ7520-2L-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
SYJ7520-2L-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
SYJ7520-2L-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
SYJ7520-2M-01		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
SYJ7520-2M-C6		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
SYJ7520-2M-C8		Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
SYJ7140-5G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7140-5G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7140-5G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7140-5L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7140-5L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7140-5L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7140-5M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7140-5M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7140-5M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7140-1G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7140-1G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7140-1G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7140-1L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7140-1L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7140-1L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7140-1M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7140-1M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7140-1M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7140-2G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7140-2G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7140-2G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7140-2L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7140-2L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7140-2L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7140-2M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7140-2M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7140-2M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7240-5G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7240-5G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7240-5G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7240-5L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7240-5L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7240-5L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7240-5M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7240-5M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7240-5M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7240-1G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7240-1G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7240-1G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7240-1L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7240-1L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7240-1L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7240-1M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7240-1M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7240-1M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7240-2G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7240-2G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7240-2G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7240-2L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7240-2L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7240-2L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7240-2M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7240-2M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7240-2M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7340-5G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7340-5G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7340-5G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7340-5L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7340-5L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7340-5L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7340-5M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7340-5M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7340-5M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7340-1G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7340-1G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7340-1G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7340-1L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7340-1L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7340-1L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7340-1M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7340-1M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7340-1M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7340-2G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7340-2G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7340-2G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7340-2L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7340-2L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7340-2L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7340-2M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7340-2M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7340-2M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7440-5G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7440-5G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7440-5G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7440-5L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7440-5L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7440-5L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7440-5M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7440-5M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7440-5M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7440-1G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7440-1G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7440-1G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7440-1L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7440-1L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7440-1L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7440-1M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7440-1M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7440-1M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7440-2G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7440-2G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7440-2G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7440-2L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7440-2L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7440-2L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7440-2M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7440-2M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7440-2M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7540-5G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7540-5G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7540-5G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7540-5L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7540-5L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7540-5L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7540-5M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7540-5M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7540-5M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7540-1G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7540-1G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7540-1G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7540-1L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7540-1L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7540-1L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7540-1M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7540-1M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7540-1M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
SYJ7540-2G		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
SYJ7540-2G-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
SYJ7540-2G-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
SYJ7540-2L		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
SYJ7540-2L-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
SYJ7540-2L-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
SYJ7540-2M		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
SYJ7540-2M-01		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
SYJ7540-2M-02		Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4

5-Port Solenoid ValvesSMC

630 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC SYJ 5-Port Solenoid Valve (SYJ3000/5000/7000, Single Unit)

Brand SMC·5-Port Solenoid Valves

Available part numbers (630)

SYJ3120-5G-M3, SYJ3120-5L-M3, SYJ3120-5M-M3, SYJ3120-1G-M3, SYJ3120-1L-M3, SYJ3120-1M-M3, SYJ3120-2G-M3, SYJ3120-2L-M3, SYJ3120-2M-M3, SYJ3220-5G-M3 + 620 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	SYJ3120-5G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3120-5L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3120-5M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3120-1G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3120-1L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3120-1M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3120-2G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3120-2L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3120-2M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3220-5G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3220-5L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3220-5M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3220-1G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3220-1L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3220-1M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3220-2G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3220-2L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3220-2M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3320-5G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3320-5L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3320-5M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3320-1G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3320-1L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3320-1M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3320-2G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3320-2L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3320-2M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3420-5G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3420-5L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3420-5M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3420-1G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3420-1L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3420-1M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3420-2G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3420-2L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3420-2M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3520-5G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3520-5L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3520-5M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3520-1G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3520-1L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3520-1M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3520-2G-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M3x0.5
	SYJ3520-2L-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M3x0.5
	SYJ3520-2M-M3	Series: SYJ3000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M3x0.5
	SYJ3140-5G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3140-5G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3140-5L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3140-5L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3140-5M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3140-5M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3140-1G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3140-1G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3140-1L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3140-1L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3140-1M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3140-1M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3140-2G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3140-2G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3140-2L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3140-2L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3140-2M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3140-2M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3240-5G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3240-5G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3240-5L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3240-5L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3240-5M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3240-5M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3240-1G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3240-1G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3240-1L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3240-1L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3240-1M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3240-1M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3240-2G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3240-2G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3240-2L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3240-2L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3240-2M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3240-2M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3340-5G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3340-5G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3340-5L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3340-5L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3340-5M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3340-5M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3340-1G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3340-1G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3340-1L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3340-1L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3340-1M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3340-1M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3340-2G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3340-2G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3340-2L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3340-2L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3340-2M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3340-2M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3440-5G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3440-5G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3440-5L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3440-5L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3440-5M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3440-5M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3440-1G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3440-1G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3440-1L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3440-1L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3440-1M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3440-1M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3440-2G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3440-2G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3440-2L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3440-2L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3440-2M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3440-2M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3540-5G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3540-5G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3540-5L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3540-5L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3540-5M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3540-5M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3540-1G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3540-1G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3540-1L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3540-1L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3540-1M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3540-1M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3540-2G	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ3540-2G-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate M5x0.8
	SYJ3540-2L	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ3540-2L-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate M5x0.8
	SYJ3540-2M	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ3540-2M-M5	Series: SYJ3000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate M5x0.8
	SYJ5120-5G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5120-5G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5120-5G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5120-5L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5120-5L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5120-5L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5120-5M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5120-5M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5120-5M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5120-1G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5120-1G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5120-1G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5120-1L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5120-1L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5120-1L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5120-1M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5120-1M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5120-1M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5120-2G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5120-2G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5120-2G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5120-2L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5120-2L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5120-2L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5120-2M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5120-2M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5120-2M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5220-5G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5220-5G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5220-5G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5220-5L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5220-5L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5220-5L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5220-5M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5220-5M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5220-5M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5220-1G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5220-1G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5220-1G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5220-1L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5220-1L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5220-1L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5220-1M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5220-1M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5220-1M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5220-2G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5220-2G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5220-2G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5220-2L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5220-2L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5220-2L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5220-2M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5220-2M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5220-2M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5320-5G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5320-5G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5320-5G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5320-5L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5320-5L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5320-5L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5320-5M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5320-5M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5320-5M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5320-1G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5320-1G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5320-1G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5320-1L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5320-1L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5320-1L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5320-1M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5320-1M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5320-1M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5320-2G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5320-2G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5320-2G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5320-2L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5320-2L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5320-2L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5320-2M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5320-2M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5320-2M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5420-5G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5420-5G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5420-5G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5420-5L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5420-5L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5420-5L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5420-5M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5420-5M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5420-5M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5420-1G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5420-1G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5420-1G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5420-1L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5420-1L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5420-1L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5420-1M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5420-1M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5420-1M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5420-2G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5420-2G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5420-2G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5420-2L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5420-2L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5420-2L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5420-2M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5420-2M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5420-2M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5520-5G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5520-5G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5520-5G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5520-5L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5520-5L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5520-5L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5520-5M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5520-5M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5520-5M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5520-1G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5520-1G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5520-1G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5520-1L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5520-1L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5520-1L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5520-1M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5520-1M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5520-1M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5520-2G-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: M5x0.8
	SYJ5520-2G-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 4
	SYJ5520-2G-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ5520-2L-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: M5x0.8
	SYJ5520-2L-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5520-2L-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5520-2M-M5	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: M5x0.8
	SYJ5520-2M-C4	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 4
	SYJ5520-2M-C6	Series: SYJ5000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ5140-5G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5140-5G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5140-5L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5140-5L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5140-5M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5140-5M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5140-1G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5140-1G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5140-1L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5140-1L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5140-1M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5140-1M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5140-2G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5140-2G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5140-2L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5140-2L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5140-2M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5140-2M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5240-5G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5240-5G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5240-5L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5240-5L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5240-5M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5240-5M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5240-1G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5240-1G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5240-1L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5240-1L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5240-1M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5240-1M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5240-2G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5240-2G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5240-2L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5240-2L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5240-2M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5240-2M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5340-5G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5340-5G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5340-5L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5340-5L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5340-5M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5340-5M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5340-1G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5340-1G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5340-1L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5340-1L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5340-1M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5340-1M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5340-2G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5340-2G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5340-2L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5340-2L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5340-2M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5340-2M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5440-5G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5440-5G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5440-5L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5440-5L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5440-5M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5440-5M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5440-1G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5440-1G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5440-1L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5440-1L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5440-1M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5440-1M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5440-2G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5440-2G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5440-2L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5440-2L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5440-2M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5440-2M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5540-5G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5540-5G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5540-5L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5540-5L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5540-5M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5540-5M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5540-1G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5540-1G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5540-1L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5540-1L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5540-1M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5540-1M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5540-2G	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ5540-2G-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ5540-2L	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ5540-2L-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ5540-2M	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ5540-2M-01	Series: SYJ5000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7120-5G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7120-5G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7120-5G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7120-5L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7120-5L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7120-5L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7120-5M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7120-5M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7120-5M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7120-1G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7120-1G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7120-1G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7120-1L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7120-1L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7120-1L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7120-1M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7120-1M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7120-1M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7120-2G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7120-2G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7120-2G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7120-2L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7120-2L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7120-2L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7120-2M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7120-2M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7120-2M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7220-5G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7220-5G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7220-5G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7220-5L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7220-5L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7220-5L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7220-5M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7220-5M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7220-5M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7220-1G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7220-1G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7220-1G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7220-1L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7220-1L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7220-1L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7220-1M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7220-1M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7220-1M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7220-2G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7220-2G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7220-2G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7220-2L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7220-2L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7220-2L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7220-2M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7220-2M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7220-2M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7320-5G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7320-5G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7320-5G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7320-5L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7320-5L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7320-5L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7320-5M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7320-5M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7320-5M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7320-1G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7320-1G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7320-1G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7320-1L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7320-1L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7320-1L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7320-1M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7320-1M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7320-1M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7320-2G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7320-2G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7320-2G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7320-2L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7320-2L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7320-2L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7320-2M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7320-2M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7320-2M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7420-5G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7420-5G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7420-5G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7420-5L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7420-5L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7420-5L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7420-5M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7420-5M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7420-5M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7420-1G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7420-1G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7420-1G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7420-1L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7420-1L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7420-1L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7420-1M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7420-1M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7420-1M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7420-2G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7420-2G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7420-2G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7420-2L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7420-2L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7420-2L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7420-2M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7420-2M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7420-2M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7520-5G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7520-5G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7520-5G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7520-5L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7520-5L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7520-5L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7520-5M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7520-5M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7520-5M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7520-1G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7520-1G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7520-1G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7520-1L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7520-1L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7520-1L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7520-1M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7520-1M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7520-1M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7520-2G-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Rc1/8
	SYJ7520-2G-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 6
	SYJ7520-2G-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: One-touch fitting dia. 8
	SYJ7520-2L-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Rc1/8
	SYJ7520-2L-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7520-2L-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7520-2M-01	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Rc1/8
	SYJ7520-2M-C6	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 6
	SYJ7520-2M-C8	Series: SYJ7000 \| Piping: Body ported \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: One-touch fitting dia. 8
	SYJ7140-5G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7140-5G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7140-5G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7140-5L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7140-5L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7140-5L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7140-5M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7140-5M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7140-5M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7140-1G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7140-1G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7140-1G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7140-1L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7140-1L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7140-1L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7140-1M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7140-1M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7140-1M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7140-2G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7140-2G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7140-2G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7140-2L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7140-2L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7140-2L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7140-2M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7140-2M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7140-2M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos single \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7240-5G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7240-5G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7240-5G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7240-5L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7240-5L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7240-5L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7240-5M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7240-5M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7240-5M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7240-1G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7240-1G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7240-1G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7240-1L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7240-1L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7240-1L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7240-1M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7240-1M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7240-1M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7240-2G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7240-2G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7240-2G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7240-2L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7240-2L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7240-2L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7240-2M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7240-2M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7240-2M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 2-pos double \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7340-5G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7340-5G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7340-5G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7340-5L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7340-5L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7340-5L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7340-5M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7340-5M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7340-5M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7340-1G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7340-1G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7340-1G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7340-1L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7340-1L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7340-1L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7340-1M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7340-1M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7340-1M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7340-2G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7340-2G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7340-2G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7340-2L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7340-2L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7340-2L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7340-2M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7340-2M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7340-2M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos closed center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7440-5G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7440-5G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7440-5G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7440-5L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7440-5L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7440-5L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7440-5M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7440-5M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7440-5M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7440-1G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7440-1G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7440-1G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7440-1L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7440-1L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7440-1L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7440-1M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7440-1M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7440-1M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7440-2G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7440-2G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7440-2G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7440-2L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7440-2L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7440-2L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7440-2M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7440-2M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7440-2M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos exhaust center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7540-5G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7540-5G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7540-5G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7540-5L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7540-5L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7540-5L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7540-5M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7540-5M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7540-5M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: DC24V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7540-1G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7540-1G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7540-1G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7540-1L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7540-1L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7540-1L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7540-1M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7540-1M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7540-1M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC100V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7540-2G	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Without sub-plate
	SYJ7540-2G-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/8
	SYJ7540-2G-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: Grommet \| Port: Sub-plate Rc1/4
	SYJ7540-2L	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Without sub-plate
	SYJ7540-2L-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7540-2L-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: L-type plug connector \| Port: Sub-plate Rc1/4
	SYJ7540-2M	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Without sub-plate
	SYJ7540-2M-01	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/8
	SYJ7540-2M-02	Series: SYJ7000 \| Piping: Base mounted \| Switching: 3-pos pressure center \| Voltage: AC200V \| Electrical entry: M-type plug connector \| Port: Sub-plate Rc1/4

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC SYJ 5-Port Solenoid Valve (SYJ3000/5000/7000, Single Unit)
