SMC VCC 2/3-Port Air Operated Valve (Water/Solvent-Based Fluids)

SMC VCC 2/3-Port Air Operated Valve (Water/Solvent-Based Fluids)

SMC VCC series compact 2-port and 3-port air operated valve for water-based and solvent-based paints, inks and cleaning fluids, for manifold mounting or as a single unit with sub-base.

Key features

  • Compact, lightweight cartridge valve suitable for mounting on robot arms
  • VCC12 2-port, VCC13 3-port (circulation) and VCC12D diaphragm type for two-component paint
  • Poppet seal of PEEK resin and stainless steel with special fluororesin; PTFE diaphragm on VCC12D
  • Leak detection port separates fluid section from pilot air
  • Single unit sub-base Rc1/4 (02) or G1/4 (02F); mounts on VVCC1 manifolds; disassembly for cleaning with dedicated tools

Specifications

Fluid Water-based and solvent-based paint, ink, cleaning fluids, air
Operating pressure range 0 to 1.0 MPa (VCC12D 0 to 0.7 MPa)
Proof pressure 2 MPa (VCC12D 1.5 MPa)
Pilot pressure 0.4 to 0.7 MPa
Orifice ø3.8 mm
Flow (Kv) 0.28 (VCC13 IN-RETURN 0.25)
Fluid and ambient temperature 5 to 50°C
Lubrication Not allowed
Explosion proof Non-explosion-proof construction
Source SMC Korea catalog VCC (SMCKR_VCC.pdf), p. 646-648 (PDF p. 6-8)
VCC12-00 Valve type: 2-port | Connection: Manifold mounting
VCC12-02 Valve type: 2-port | Connection: Single unit, Rc1/4 sub-base
VCC12D-00 Valve type: 2-port diaphragm (2-component paint) | Connection: Manifold mounting
VCC12D-02 Valve type: 2-port diaphragm (2-component paint) | Connection: Single unit, Rc1/4 sub-base
VCC13-00 Valve type: 3-port | Connection: Manifold mounting
VCC13-02 Valve type: 3-port | Connection: Single unit, Rc1/4 sub-base
