SMC VFM200 5-Port Mechanical Valve (Metal Seal, Rc1/4)

SMC VFM200 5-Port Mechanical Valve (Metal Seal, Rc1/4)

SMC VFM200 series pilot-operated 5-port mechanical valve with metal seal spool and Rc1/4 ports, internal or external pilot.

Key features

  • Compact with large flow: C = 4.0 dm³/(s·bar); metal seal for high frequency and long life (300 c.p.m. max.)
  • Mechanical actuators: roller lever, one-way roller lever, straight plunger and roller plunger (POM or hardened steel rollers)
  • Manual actuators: flip toggle, push buttons, 2-position selector and key selector; four button colors
  • Internal or external pilot type; all EXH ports can be piped
  • Bracket (F, internal pilot only) and push-lock buttons (X207A/X219A) on order

Specifications

Fluid Air
Operating pressure 0.1 to 1.0 MPa (external pilot: main 0 to 1.0, pilot 0.1 to 1.0)
Ambient and fluid temperature -5 to 60°C (no freezing)
Flow rate C [dm³/(s·bar)] 4.0 (P-A/B), 3.5 (A/B-EA/EB)
Cv 0.9 / 0.85
Max. operating frequency 300 c.p.m. (mechanical operation)
Port size Main Rc1/4; pilot/exhaust M5
Seal Metal seal spool
Lubrication Not required (use ISO VG32 turbine oil if lubricated)
Replacement actuator part no. VM-<code>C; 05/06/08: VM-<code>D
Source SMC Korea catalog VM/VZM/VFM (SMCKR_VM_VZM_VFM.pdf), p. 1468-1469 (PDF p. 62-63)
VFM250-02-00 Pilot: Internal pilot | Actuator: Basic type (no actuator) | Color: N/A
VFM251-02-00 Pilot: External pilot | Actuator: Basic type (no actuator) | Color: N/A
VFM250-02-01 Pilot: Internal pilot | Actuator: Roller lever, POM roller | Color: N/A
VFM251-02-01 Pilot: External pilot | Actuator: Roller lever, POM roller | Color: N/A
VFM250-02-01S Pilot: Internal pilot | Actuator: Roller lever, steel roller | Color: N/A
VFM251-02-01S Pilot: External pilot | Actuator: Roller lever, steel roller | Color: N/A
VFM250-02-02 Pilot: Internal pilot | Actuator: One-way roller lever, POM roller | Color: N/A
VFM251-02-02 Pilot: External pilot | Actuator: One-way roller lever, POM roller | Color: N/A
VFM250-02-02S Pilot: Internal pilot | Actuator: One-way roller lever, steel roller | Color: N/A
VFM251-02-02S Pilot: External pilot | Actuator: One-way roller lever, steel roller | Color: N/A
VFM250-02-06 Pilot: Internal pilot | Actuator: Roller plunger, POM roller | Color: N/A
VFM251-02-06 Pilot: External pilot | Actuator: Roller plunger, POM roller | Color: N/A
VFM250-02-06S Pilot: Internal pilot | Actuator: Roller plunger, steel roller | Color: N/A
VFM251-02-06S Pilot: External pilot | Actuator: Roller plunger, steel roller | Color: N/A
VFM250-02-05 Pilot: Internal pilot | Actuator: Straight plunger | Color: N/A
VFM251-02-05 Pilot: External pilot | Actuator: Straight plunger | Color: N/A
VFM250-02-08 Pilot: Internal pilot | Actuator: Flip toggle | Color: N/A
VFM251-02-08 Pilot: External pilot | Actuator: Flip toggle | Color: N/A
VFM250-02-30R Pilot: Internal pilot | Actuator: Push button (mushroom) | Color: Red
VFM251-02-30R Pilot: External pilot | Actuator: Push button (mushroom) | Color: Red
VFM250-02-30B Pilot: Internal pilot | Actuator: Push button (mushroom) | Color: Black
VFM251-02-30B Pilot: External pilot | Actuator: Push button (mushroom) | Color: Black
VFM250-02-30G Pilot: Internal pilot | Actuator: Push button (mushroom) | Color: Green
VFM251-02-30G Pilot: External pilot | Actuator: Push button (mushroom) | Color: Green
VFM250-02-30Y Pilot: Internal pilot | Actuator: Push button (mushroom) | Color: Yellow
VFM251-02-30Y Pilot: External pilot | Actuator: Push button (mushroom) | Color: Yellow
VFM250-02-33 Pilot: Internal pilot | Actuator: Push button (flush) | Color: 4-color set (R/B/G/Y)
VFM251-02-33 Pilot: External pilot | Actuator: Push button (flush) | Color: 4-color set (R/B/G/Y)
VFM250-02-34R Pilot: Internal pilot | Actuator: Selector (2-position) | Color: Red
VFM251-02-34R Pilot: External pilot | Actuator: Selector (2-position) | Color: Red
VFM250-02-34B Pilot: Internal pilot | Actuator: Selector (2-position) | Color: Black
VFM251-02-34B Pilot: External pilot | Actuator: Selector (2-position) | Color: Black
VFM250-02-34G Pilot: Internal pilot | Actuator: Selector (2-position) | Color: Green
VFM251-02-34G Pilot: External pilot | Actuator: Selector (2-position) | Color: Green
VFM250-02-34Y Pilot: Internal pilot | Actuator: Selector (2-position) | Color: Yellow
VFM251-02-34Y Pilot: External pilot | Actuator: Selector (2-position) | Color: Yellow
VFM250-02-36 Pilot: Internal pilot | Actuator: Key selector (2-position) | Color: N/A
VFM251-02-36 Pilot: External pilot | Actuator: Key selector (2-position) | Color: N/A
VFM250-02-32R Pilot: Internal pilot | Actuator: Push button (extended) | Color: Red
VFM251-02-32R Pilot: External pilot | Actuator: Push button (extended) | Color: Red
VFM250-02-32B Pilot: Internal pilot | Actuator: Push button (extended) | Color: Black
VFM251-02-32B Pilot: External pilot | Actuator: Push button (extended) | Color: Black
VFM250-02-32G Pilot: Internal pilot | Actuator: Push button (extended) | Color: Green
VFM251-02-32G Pilot: External pilot | Actuator: Push button (extended) | Color: Green
VFM250-02-32Y Pilot: Internal pilot | Actuator: Push button (extended) | Color: Yellow
VFM251-02-32Y Pilot: External pilot | Actuator: Push button (extended) | Color: Yellow
Mechanical ValvesSMC
46 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC VFM200 5-Port Mechanical Valve (Metal Seal, Rc1/4)

Brand SMC·Mechanical Valves

Available part numbers (46)

VFM250-02-00, VFM251-02-00, VFM250-02-01, VFM251-02-01, VFM250-02-01S, VFM251-02-01S, VFM250-02-02, VFM251-02-02, VFM250-02-02S, VFM251-02-02S + 36 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VFM250-02-00Pilot: Internal pilot | Actuator: Basic type (no actuator) | Color: N/A
VFM251-02-00Pilot: External pilot | Actuator: Basic type (no actuator) | Color: N/A
VFM250-02-01Pilot: Internal pilot | Actuator: Roller lever, POM roller | Color: N/A
VFM251-02-01Pilot: External pilot | Actuator: Roller lever, POM roller | Color: N/A
VFM250-02-01SPilot: Internal pilot | Actuator: Roller lever, steel roller | Color: N/A
VFM251-02-01SPilot: External pilot | Actuator: Roller lever, steel roller | Color: N/A
VFM250-02-02Pilot: Internal pilot | Actuator: One-way roller lever, POM roller | Color: N/A
VFM251-02-02Pilot: External pilot | Actuator: One-way roller lever, POM roller | Color: N/A
VFM250-02-02SPilot: Internal pilot | Actuator: One-way roller lever, steel roller | Color: N/A
VFM251-02-02SPilot: External pilot | Actuator: One-way roller lever, steel roller | Color: N/A
VFM250-02-06Pilot: Internal pilot | Actuator: Roller plunger, POM roller | Color: N/A
VFM251-02-06Pilot: External pilot | Actuator: Roller plunger, POM roller | Color: N/A
VFM250-02-06SPilot: Internal pilot | Actuator: Roller plunger, steel roller | Color: N/A
VFM251-02-06SPilot: External pilot | Actuator: Roller plunger, steel roller | Color: N/A
VFM250-02-05Pilot: Internal pilot | Actuator: Straight plunger | Color: N/A
VFM251-02-05Pilot: External pilot | Actuator: Straight plunger | Color: N/A
VFM250-02-08Pilot: Internal pilot | Actuator: Flip toggle | Color: N/A
VFM251-02-08Pilot: External pilot | Actuator: Flip toggle | Color: N/A
VFM250-02-30RPilot: Internal pilot | Actuator: Push button (mushroom) | Color: Red
VFM251-02-30RPilot: External pilot | Actuator: Push button (mushroom) | Color: Red
VFM250-02-30BPilot: Internal pilot | Actuator: Push button (mushroom) | Color: Black
VFM251-02-30BPilot: External pilot | Actuator: Push button (mushroom) | Color: Black
VFM250-02-30GPilot: Internal pilot | Actuator: Push button (mushroom) | Color: Green
VFM251-02-30GPilot: External pilot | Actuator: Push button (mushroom) | Color: Green
VFM250-02-30YPilot: Internal pilot | Actuator: Push button (mushroom) | Color: Yellow
VFM251-02-30YPilot: External pilot | Actuator: Push button (mushroom) | Color: Yellow
VFM250-02-33Pilot: Internal pilot | Actuator: Push button (flush) | Color: 4-color set (R/B/G/Y)
VFM251-02-33Pilot: External pilot | Actuator: Push button (flush) | Color: 4-color set (R/B/G/Y)
VFM250-02-34RPilot: Internal pilot | Actuator: Selector (2-position) | Color: Red
VFM251-02-34RPilot: External pilot | Actuator: Selector (2-position) | Color: Red
VFM250-02-34BPilot: Internal pilot | Actuator: Selector (2-position) | Color: Black
VFM251-02-34BPilot: External pilot | Actuator: Selector (2-position) | Color: Black
VFM250-02-34GPilot: Internal pilot | Actuator: Selector (2-position) | Color: Green
VFM251-02-34GPilot: External pilot | Actuator: Selector (2-position) | Color: Green
VFM250-02-34YPilot: Internal pilot | Actuator: Selector (2-position) | Color: Yellow
VFM251-02-34YPilot: External pilot | Actuator: Selector (2-position) | Color: Yellow
VFM250-02-36Pilot: Internal pilot | Actuator: Key selector (2-position) | Color: N/A
VFM251-02-36Pilot: External pilot | Actuator: Key selector (2-position) | Color: N/A
VFM250-02-32RPilot: Internal pilot | Actuator: Push button (extended) | Color: Red
VFM251-02-32RPilot: External pilot | Actuator: Push button (extended) | Color: Red
VFM250-02-32BPilot: Internal pilot | Actuator: Push button (extended) | Color: Black
VFM251-02-32BPilot: External pilot | Actuator: Push button (extended) | Color: Black
VFM250-02-32GPilot: Internal pilot | Actuator: Push button (extended) | Color: Green
VFM251-02-32GPilot: External pilot | Actuator: Push button (extended) | Color: Green
VFM250-02-32YPilot: Internal pilot | Actuator: Push button (extended) | Color: Yellow
VFM251-02-32YPilot: External pilot | Actuator: Push button (extended) | Color: Yellow
