SMC VQ1000/2000-FPG Perfect Block (Residual Pressure Release)

SMC VQ1000/2000-FPG Perfect Block (Residual Pressure Release)

SMC VQ1000/2000-FPG separately mounted perfect block with residual pressure release valve, preventing cylinder drop and allowing temporary intermediate stops.

Key features

  • Dual pilot check block installed between valve and cylinder; prevents cylinder drop with 2-position single/double valves
  • Intermediate stop when combined with a 3-position exhaust center valve (not for closed or pressure center)
  • Residual pressure release valves with manual operation (tool required)
  • IN/OUT ports: VQ1000 size M5 or ø3.2/ø4/ø6 one-touch; VQ2000 size Rc1/8, Rc1/4 or ø4/ø6/ø8 one-touch; inch one-touch on order
  • Single units for DIN rail (D) mount on VVQ1000/2000-FPG manifolds (1 to 16 stations); bracket (F) and name plate (N) options

Specifications

Fluid Air
Proof pressure 1.5 MPa
Operating pressure range 0.15 to 0.8 MPa
Ambient and fluid temperature -5 to 50°C
Sonic conductance VQ1000-FPG 0.6 dm³/(s·bar), VQ2000-FPG 3.0 dm³/(s·bar)
Applicable cylinder bore VQ1000-FPG up to ø40, VQ2000-FPG up to ø63
Pressure drop IN/OUT (0.5 MPa supply) VQ1000 0.1 MPa, VQ2000 0.07 MPa
Bracket assembly VQ1000-FPG-FB / VQ2000-FPG-FB
Source SMC Korea information ’22-K789 (SMCKR_PerfectBlock_VQ.pdf), p. 1-2 (PDF p. 1-3)
VQ1000-FPG-M5M5 Size: VQ1000 | IN side: M5x0.8 | OUT side: M5x0.8 | Mounting: Standalone
VQ1000-FPG-M5M5-D Size: VQ1000 | IN side: M5x0.8 | OUT side: M5x0.8 | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-M5C3 Size: VQ1000 | IN side: M5x0.8 | OUT side: ø3.2 one-touch | Mounting: Standalone
VQ1000-FPG-M5C3-D Size: VQ1000 | IN side: M5x0.8 | OUT side: ø3.2 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-M5C4 Size: VQ1000 | IN side: M5x0.8 | OUT side: ø4 one-touch | Mounting: Standalone
VQ1000-FPG-M5C4-D Size: VQ1000 | IN side: M5x0.8 | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-M5C6 Size: VQ1000 | IN side: M5x0.8 | OUT side: ø6 one-touch | Mounting: Standalone
VQ1000-FPG-M5C6-D Size: VQ1000 | IN side: M5x0.8 | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C3M5 Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: M5x0.8 | Mounting: Standalone
VQ1000-FPG-C3M5-D Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: M5x0.8 | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C3C3 Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: ø3.2 one-touch | Mounting: Standalone
VQ1000-FPG-C3C3-D Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: ø3.2 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C3C4 Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: ø4 one-touch | Mounting: Standalone
VQ1000-FPG-C3C4-D Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C3C6 Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: ø6 one-touch | Mounting: Standalone
VQ1000-FPG-C3C6-D Size: VQ1000 | IN side: ø3.2 one-touch | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C4M5 Size: VQ1000 | IN side: ø4 one-touch | OUT side: M5x0.8 | Mounting: Standalone
VQ1000-FPG-C4M5-D Size: VQ1000 | IN side: ø4 one-touch | OUT side: M5x0.8 | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C4C3 Size: VQ1000 | IN side: ø4 one-touch | OUT side: ø3.2 one-touch | Mounting: Standalone
VQ1000-FPG-C4C3-D Size: VQ1000 | IN side: ø4 one-touch | OUT side: ø3.2 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C4C4 Size: VQ1000 | IN side: ø4 one-touch | OUT side: ø4 one-touch | Mounting: Standalone
VQ1000-FPG-C4C4-D Size: VQ1000 | IN side: ø4 one-touch | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C4C6 Size: VQ1000 | IN side: ø4 one-touch | OUT side: ø6 one-touch | Mounting: Standalone
VQ1000-FPG-C4C6-D Size: VQ1000 | IN side: ø4 one-touch | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C6M5 Size: VQ1000 | IN side: ø6 one-touch | OUT side: M5x0.8 | Mounting: Standalone
VQ1000-FPG-C6M5-D Size: VQ1000 | IN side: ø6 one-touch | OUT side: M5x0.8 | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C6C3 Size: VQ1000 | IN side: ø6 one-touch | OUT side: ø3.2 one-touch | Mounting: Standalone
VQ1000-FPG-C6C3-D Size: VQ1000 | IN side: ø6 one-touch | OUT side: ø3.2 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C6C4 Size: VQ1000 | IN side: ø6 one-touch | OUT side: ø4 one-touch | Mounting: Standalone
VQ1000-FPG-C6C4-D Size: VQ1000 | IN side: ø6 one-touch | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ1000-FPG-C6C6 Size: VQ1000 | IN side: ø6 one-touch | OUT side: ø6 one-touch | Mounting: Standalone
VQ1000-FPG-C6C6-D Size: VQ1000 | IN side: ø6 one-touch | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VVQ1000-FPG-01 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 1 station(s)
VVQ1000-FPG-02 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 2 station(s)
VVQ1000-FPG-03 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 3 station(s)
VVQ1000-FPG-04 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 4 station(s)
VVQ1000-FPG-05 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 5 station(s)
VVQ1000-FPG-06 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 6 station(s)
VVQ1000-FPG-07 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 7 station(s)
VVQ1000-FPG-08 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 8 station(s)
VVQ1000-FPG-09 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 9 station(s)
VVQ1000-FPG-10 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 10 station(s)
VVQ1000-FPG-11 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 11 station(s)
VVQ1000-FPG-12 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 12 station(s)
VVQ1000-FPG-13 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 13 station(s)
VVQ1000-FPG-14 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 14 station(s)
VVQ1000-FPG-15 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 15 station(s)
VVQ1000-FPG-16 Size: VQ1000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 16 station(s)
VQ2000-FPG-0101 Size: VQ2000 | IN side: Rc1/8 | OUT side: Rc1/8 | Mounting: Standalone
VQ2000-FPG-0101-D Size: VQ2000 | IN side: Rc1/8 | OUT side: Rc1/8 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-0102 Size: VQ2000 | IN side: Rc1/8 | OUT side: Rc1/4 | Mounting: Standalone
VQ2000-FPG-0102-D Size: VQ2000 | IN side: Rc1/8 | OUT side: Rc1/4 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-01C4 Size: VQ2000 | IN side: Rc1/8 | OUT side: ø4 one-touch | Mounting: Standalone
VQ2000-FPG-01C4-D Size: VQ2000 | IN side: Rc1/8 | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-01C6 Size: VQ2000 | IN side: Rc1/8 | OUT side: ø6 one-touch | Mounting: Standalone
VQ2000-FPG-01C6-D Size: VQ2000 | IN side: Rc1/8 | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-01C8 Size: VQ2000 | IN side: Rc1/8 | OUT side: ø8 one-touch | Mounting: Standalone
VQ2000-FPG-01C8-D Size: VQ2000 | IN side: Rc1/8 | OUT side: ø8 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-0201 Size: VQ2000 | IN side: Rc1/4 | OUT side: Rc1/8 | Mounting: Standalone
VQ2000-FPG-0201-D Size: VQ2000 | IN side: Rc1/4 | OUT side: Rc1/8 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-0202 Size: VQ2000 | IN side: Rc1/4 | OUT side: Rc1/4 | Mounting: Standalone
VQ2000-FPG-0202-D Size: VQ2000 | IN side: Rc1/4 | OUT side: Rc1/4 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-02C4 Size: VQ2000 | IN side: Rc1/4 | OUT side: ø4 one-touch | Mounting: Standalone
VQ2000-FPG-02C4-D Size: VQ2000 | IN side: Rc1/4 | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-02C6 Size: VQ2000 | IN side: Rc1/4 | OUT side: ø6 one-touch | Mounting: Standalone
VQ2000-FPG-02C6-D Size: VQ2000 | IN side: Rc1/4 | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-02C8 Size: VQ2000 | IN side: Rc1/4 | OUT side: ø8 one-touch | Mounting: Standalone
VQ2000-FPG-02C8-D Size: VQ2000 | IN side: Rc1/4 | OUT side: ø8 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C401 Size: VQ2000 | IN side: ø4 one-touch | OUT side: Rc1/8 | Mounting: Standalone
VQ2000-FPG-C401-D Size: VQ2000 | IN side: ø4 one-touch | OUT side: Rc1/8 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C402 Size: VQ2000 | IN side: ø4 one-touch | OUT side: Rc1/4 | Mounting: Standalone
VQ2000-FPG-C402-D Size: VQ2000 | IN side: ø4 one-touch | OUT side: Rc1/4 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C4C4 Size: VQ2000 | IN side: ø4 one-touch | OUT side: ø4 one-touch | Mounting: Standalone
VQ2000-FPG-C4C4-D Size: VQ2000 | IN side: ø4 one-touch | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C4C6 Size: VQ2000 | IN side: ø4 one-touch | OUT side: ø6 one-touch | Mounting: Standalone
VQ2000-FPG-C4C6-D Size: VQ2000 | IN side: ø4 one-touch | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C4C8 Size: VQ2000 | IN side: ø4 one-touch | OUT side: ø8 one-touch | Mounting: Standalone
VQ2000-FPG-C4C8-D Size: VQ2000 | IN side: ø4 one-touch | OUT side: ø8 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C601 Size: VQ2000 | IN side: ø6 one-touch | OUT side: Rc1/8 | Mounting: Standalone
VQ2000-FPG-C601-D Size: VQ2000 | IN side: ø6 one-touch | OUT side: Rc1/8 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C602 Size: VQ2000 | IN side: ø6 one-touch | OUT side: Rc1/4 | Mounting: Standalone
VQ2000-FPG-C602-D Size: VQ2000 | IN side: ø6 one-touch | OUT side: Rc1/4 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C6C4 Size: VQ2000 | IN side: ø6 one-touch | OUT side: ø4 one-touch | Mounting: Standalone
VQ2000-FPG-C6C4-D Size: VQ2000 | IN side: ø6 one-touch | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C6C6 Size: VQ2000 | IN side: ø6 one-touch | OUT side: ø6 one-touch | Mounting: Standalone
VQ2000-FPG-C6C6-D Size: VQ2000 | IN side: ø6 one-touch | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C6C8 Size: VQ2000 | IN side: ø6 one-touch | OUT side: ø8 one-touch | Mounting: Standalone
VQ2000-FPG-C6C8-D Size: VQ2000 | IN side: ø6 one-touch | OUT side: ø8 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C801 Size: VQ2000 | IN side: ø8 one-touch | OUT side: Rc1/8 | Mounting: Standalone
VQ2000-FPG-C801-D Size: VQ2000 | IN side: ø8 one-touch | OUT side: Rc1/8 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C802 Size: VQ2000 | IN side: ø8 one-touch | OUT side: Rc1/4 | Mounting: Standalone
VQ2000-FPG-C802-D Size: VQ2000 | IN side: ø8 one-touch | OUT side: Rc1/4 | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C8C4 Size: VQ2000 | IN side: ø8 one-touch | OUT side: ø4 one-touch | Mounting: Standalone
VQ2000-FPG-C8C4-D Size: VQ2000 | IN side: ø8 one-touch | OUT side: ø4 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C8C6 Size: VQ2000 | IN side: ø8 one-touch | OUT side: ø6 one-touch | Mounting: Standalone
VQ2000-FPG-C8C6-D Size: VQ2000 | IN side: ø8 one-touch | OUT side: ø6 one-touch | Mounting: DIN rail mount (for manifold)
VQ2000-FPG-C8C8 Size: VQ2000 | IN side: ø8 one-touch | OUT side: ø8 one-touch | Mounting: Standalone
VQ2000-FPG-C8C8-D Size: VQ2000 | IN side: ø8 one-touch | OUT side: ø8 one-touch | Mounting: DIN rail mount (for manifold)
VVQ2000-FPG-01 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 1 station(s)
VVQ2000-FPG-02 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 2 station(s)
VVQ2000-FPG-03 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 3 station(s)
VVQ2000-FPG-04 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 4 station(s)
VVQ2000-FPG-05 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 5 station(s)
VVQ2000-FPG-06 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 6 station(s)
VVQ2000-FPG-07 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 7 station(s)
VVQ2000-FPG-08 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 8 station(s)
VVQ2000-FPG-09 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 9 station(s)
VVQ2000-FPG-10 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 10 station(s)
VVQ2000-FPG-11 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 11 station(s)
VVQ2000-FPG-12 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 12 station(s)
VVQ2000-FPG-13 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 13 station(s)
VVQ2000-FPG-14 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 14 station(s)
VVQ2000-FPG-15 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 15 station(s)
VVQ2000-FPG-16 Size: VQ2000 | IN side: Manifold base | OUT side: Manifold base | Mounting: DIN rail manifold, 16 station(s)
