SMC VV100 Manifold Base (for V100 3-Port Valves)

SMC VV100 Manifold Base (for V100 3-Port Valves)

SMC VV100 S41 type single-base manifold for V100 direct-operated 3-port solenoid valves, common supply and exhaust, 2 to 20 stations.

Key features

  • VV100-S41 for V114/V114A/V124/V124A valves, all ports M5x0.8 (N.C. and N.O. not mixed)
  • VV100U-S41 for high-flow V114UT valves, 1 and 3 ports Rc1/8, 2 port M5x0.8
  • VV100U port 1/3 take-off position selectable: U side, D side or both sides
  • Blanking plate assembly V100-77-1A; G1/8 and NPT1/8 (F, N) available as suffix

Specifications

Manifold type Single base, B mount
P (SUP) / R (EXH) Common SUP, common EXH
Valve stations 2 to 20
Output port location Base, side
Port size (VV100-S41) 1, 2, 3 ports M5x0.8
Port size (VV100U-S41) 1, 3 ports 1/8; 2 port M5x0.8
