SMC VV5ZA2/VV5ZA4 Manifold for VZA Air Operated Valves

SMC VV5ZA2/VV5ZA4 Manifold for VZA Air Operated Valves

SMC VV5ZA2/VV5ZA4 manifold base for VZA2000/4000 air operated valves, in direct piping (type 20) or base piping (type 50) versions, 2 to 10 stations.

Key features

  • Common P, EA, EB supply and exhaust with side piping
  • Type 20 for direct piping valves (VZA21); type 50 base piping with cylinder ports in the base (VZA41-2)
  • Base cylinder ports: VV5ZA2 M5, Rc1/8, ø4/ø6 one-touch; VV5ZA4 Rc1/8, Rc1/4, ø6/ø8 one-touch
  • Order valves and blanking plates (VVZ2000-31A- / VVZ4000-31A-) together with the manifold base
  • Thread type Rc standard; NPT (N), NPTF (T), G (F) on order

Specifications

Fluid Air
P, EA, EB port VV5ZA2 Rc1/8, VV5ZA4 Rc1/4
Stations 2 to 10
Flow path P, EA, EB common, side piping
Applicable valves VZA2000 / VZA4000 series
Valves Order separately
Source SMC Korea catalog VZA2000/4000 (SMCKR_VZA2000_4000.pdf), p. 1292-1293, 1297-1298 (PDF p. 1-2, 6-7)
VV5ZA2-20-021 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 2 | Cylinder port: On valve
VV5ZA2-50-021-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: M5x0.8
VV5ZA2-50-021-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: Rc1/8
VV5ZA2-50-021-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-021-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-031 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 3 | Cylinder port: On valve
VV5ZA2-50-031-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: M5x0.8
VV5ZA2-50-031-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: Rc1/8
VV5ZA2-50-031-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-031-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-041 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 4 | Cylinder port: On valve
VV5ZA2-50-041-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: M5x0.8
VV5ZA2-50-041-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: Rc1/8
VV5ZA2-50-041-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-041-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-051 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 5 | Cylinder port: On valve
VV5ZA2-50-051-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: M5x0.8
VV5ZA2-50-051-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: Rc1/8
VV5ZA2-50-051-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-051-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-061 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 6 | Cylinder port: On valve
VV5ZA2-50-061-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: M5x0.8
VV5ZA2-50-061-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: Rc1/8
VV5ZA2-50-061-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-061-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-071 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 7 | Cylinder port: On valve
VV5ZA2-50-071-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: M5x0.8
VV5ZA2-50-071-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: Rc1/8
VV5ZA2-50-071-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-071-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-081 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 8 | Cylinder port: On valve
VV5ZA2-50-081-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: M5x0.8
VV5ZA2-50-081-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: Rc1/8
VV5ZA2-50-081-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-081-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-091 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 9 | Cylinder port: On valve
VV5ZA2-50-091-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: M5x0.8
VV5ZA2-50-091-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: Rc1/8
VV5ZA2-50-091-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-091-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: ø6 one-touch fitting
VV5ZA2-20-101 Series: VZA2000 | Manifold type: 20 direct piping | Stations: 10 | Cylinder port: On valve
VV5ZA2-50-101-M5 Series: VZA2000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: M5x0.8
VV5ZA2-50-101-01 Series: VZA2000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: Rc1/8
VV5ZA2-50-101-C4 Series: VZA2000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: ø4 one-touch fitting
VV5ZA2-50-101-C6 Series: VZA2000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: ø6 one-touch fitting
VV5ZA4-20-021 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 2 | Cylinder port: On valve
VV5ZA4-50-021-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: Rc1/8
VV5ZA4-50-021-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: Rc1/4
VV5ZA4-50-021-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-021-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 2 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-031 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 3 | Cylinder port: On valve
VV5ZA4-50-031-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: Rc1/8
VV5ZA4-50-031-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: Rc1/4
VV5ZA4-50-031-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-031-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 3 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-041 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 4 | Cylinder port: On valve
VV5ZA4-50-041-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: Rc1/8
VV5ZA4-50-041-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: Rc1/4
VV5ZA4-50-041-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-041-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 4 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-051 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 5 | Cylinder port: On valve
VV5ZA4-50-051-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: Rc1/8
VV5ZA4-50-051-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: Rc1/4
VV5ZA4-50-051-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-051-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 5 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-061 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 6 | Cylinder port: On valve
VV5ZA4-50-061-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: Rc1/8
VV5ZA4-50-061-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: Rc1/4
VV5ZA4-50-061-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-061-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 6 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-071 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 7 | Cylinder port: On valve
VV5ZA4-50-071-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: Rc1/8
VV5ZA4-50-071-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: Rc1/4
VV5ZA4-50-071-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-071-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 7 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-081 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 8 | Cylinder port: On valve
VV5ZA4-50-081-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: Rc1/8
VV5ZA4-50-081-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: Rc1/4
VV5ZA4-50-081-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-081-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 8 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-091 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 9 | Cylinder port: On valve
VV5ZA4-50-091-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: Rc1/8
VV5ZA4-50-091-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: Rc1/4
VV5ZA4-50-091-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-091-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 9 | Cylinder port: ø8 one-touch fitting
VV5ZA4-20-101 Series: VZA4000 | Manifold type: 20 direct piping | Stations: 10 | Cylinder port: On valve
VV5ZA4-50-101-01 Series: VZA4000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: Rc1/8
VV5ZA4-50-101-02 Series: VZA4000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: Rc1/4
VV5ZA4-50-101-C6 Series: VZA4000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: ø6 one-touch fitting
VV5ZA4-50-101-C8 Series: VZA4000 | Manifold type: 50 base piping | Stations: 10 | Cylinder port: ø8 one-touch fitting
ManifoldsSMC
90 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC VV5ZA2/VV5ZA4 Manifold for VZA Air Operated Valves

Brand SMC·Manifolds

Available part numbers (90)

VV5ZA2-20-021, VV5ZA2-50-021-M5, VV5ZA2-50-021-01, VV5ZA2-50-021-C4, VV5ZA2-50-021-C6, VV5ZA2-20-031, VV5ZA2-50-031-M5, VV5ZA2-50-031-01, VV5ZA2-50-031-C4, VV5ZA2-50-031-C6 + 80 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
