SMC VXB Angle Seat Valve, Air Operated (Steam, 3/8 to 3/4)

SMC VXB Angle Seat Valve, Air Operated (Steam, 3/8 to 3/4)

SMC VXB series air-operated piston angle seat valve for steam (also air and water), N.C., with bronze or SUS316L-equivalent body in 3/8, 1/2 and 3/4 port sizes.

Key features

  • Angle seat construction for low pressure loss; Cv 3.5 / 5.4 / 7.6 for 3/8 / 1/2 / 3/4
  • Steam up to 183°C; air and water up to 99°C; special FKM seal for low leakage (10 cm³/min or less, air)
  • Long life: 3 million cycles (steam), 5 million cycles (air), by SMC test conditions
  • Standard or high pressure (H) actuator; optional open/close indicator (L)
  • G or NPT thread (A/B), pilot port direction 90°/270° (XCA/XCC) and insulating adapter (XA/XAA/XAC) on order

Specifications

Valve construction Air operated piston, angle seat, N.C.
Fluid Steam (air and water also possible)
Proof pressure 2.4 MPa
Seal material FKM
Max. operating pressure Std 1.0/0.6/0.4 MPa, high pressure 1.0/1.0/0.6 MPa (3/8, 1/2, 3/4; steam)
Pilot pressure Standard 0.3 to 1 MPa, high pressure 0.5 to 1 MPa
Fluid temperature Steam 183°C or less; water, air 99°C or less
Ambient temperature -20 to 60°C
Port thread Rc standard (main and pilot ports)
Source SMC Korea catalog CAT.KS70-54B VXB Series (SMCKR_VXB.pdf), p. 1-5 (PDF p. 2-6)
VXB215A Body: Bronze (CAC) | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: Standard | Indicator: None
VXB215AL Body: Bronze (CAC) | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: Standard | Indicator: With indicator
VXB215AH Body: Bronze (CAC) | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: High pressure | Indicator: None
VXB215AHL Body: Bronze (CAC) | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: High pressure | Indicator: With indicator
VXB215B Body: Bronze (CAC) | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: Standard | Indicator: None
VXB215BL Body: Bronze (CAC) | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: Standard | Indicator: With indicator
VXB215BH Body: Bronze (CAC) | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: High pressure | Indicator: None
VXB215BHL Body: Bronze (CAC) | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: High pressure | Indicator: With indicator
VXB215C Body: Bronze (CAC) | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: Standard | Indicator: None
VXB215CL Body: Bronze (CAC) | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: Standard | Indicator: With indicator
VXB215CH Body: Bronze (CAC) | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: High pressure | Indicator: None
VXB215CHL Body: Bronze (CAC) | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: High pressure | Indicator: With indicator
VXB215D Body: SUS316L equiv. | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: Standard | Indicator: None
VXB215DL Body: SUS316L equiv. | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: Standard | Indicator: With indicator
VXB215DH Body: SUS316L equiv. | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: High pressure | Indicator: None
VXB215DHL Body: SUS316L equiv. | Port: Rc3/8 (10A) | Orifice: ø11 mm | Pressure: High pressure | Indicator: With indicator
VXB215E Body: SUS316L equiv. | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: Standard | Indicator: None
VXB215EL Body: SUS316L equiv. | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: Standard | Indicator: With indicator
VXB215EH Body: SUS316L equiv. | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: High pressure | Indicator: None
VXB215EHL Body: SUS316L equiv. | Port: Rc1/2 (15A) | Orifice: ø14 mm | Pressure: High pressure | Indicator: With indicator
VXB215F Body: SUS316L equiv. | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: Standard | Indicator: None
VXB215FL Body: SUS316L equiv. | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: Standard | Indicator: With indicator
VXB215FH Body: SUS316L equiv. | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: High pressure | Indicator: None
VXB215FHL Body: SUS316L equiv. | Port: Rc3/4 (20A) | Orifice: ø18 mm | Pressure: High pressure | Indicator: With indicator
