SMC VY1 E-P HYREG Electro-Pneumatic Regulator (M5 to 2 inch)

SMC VY1 E-P HYREG Electro-Pneumatic Regulator (M5 to 2 inch)

SMC VY1 E-P HYREG hybrid regulator combining a miniature electro-pneumatic pilot valve with a large-capacity 3-port exhaust main regulator, steplessly controlled by an electrical signal.

Key features

  • Port sizes from M5 to 2 inch in base-mounted (D, B, 2, 4) and direct piping (A, 1, 3, 5, 7, 9) bodies
  • Internal or external pilot (external not for size D); large relief flow
  • Command signal DC1-5V, 0-10V, 4-20mA or 0-20mA; DC24V or DC12V supply; DIN terminal
  • Base-mounted sizes B, 2, 4 can be manifolded on VVEX bases
  • Options: bracket (B), foot (F), pressure gauge (G), pilot EXH silencer (N); G/NPT/NPTF threads and low-wattage -X39 on order

Specifications

Fluid Air
Max. operating pressure 0.9 MPa
Set pressure range 0.05 to 0.84 MPa (at 0.9 MPa supply)
External pilot pressure Set pressure + 0.04 to 0.9 MPa
Power supply DC12V or DC24V ±10%, 1.8 W or less
Electrical entry DIN terminal, cable ø4 to 6.5
Bleed (pilot EXH) 0 at rest, 10 L/min (ANR) operating
Ambient and fluid temperature 0 to 50°C (no condensation)
Lubrication Not required
Source SMC Korea catalog (SMCKR_VY1.pdf), p. 990-991 (PDF p. 2-3)
VY1D00-00 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1D00-M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1D00-100 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1D00-1M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1D00-200 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1D00-2M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1D00-300 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1D00-3M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1D00-500 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1D00-5M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1D00-600 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1D00-6M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1D00-700 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1D00-7M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1D00-800 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1D00-8M5 Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1B00-00 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1B00-M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1B00-01 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1B00-100 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1B00-1M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1B00-101 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1B00-200 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1B00-2M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1B00-201 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1B00-300 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1B00-3M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1B00-301 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1B00-500 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1B00-5M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1B00-501 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1B00-600 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1B00-6M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1B00-601 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1B00-700 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1B00-7M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1B00-701 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1B00-800 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1B00-8M5 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1B00-801 Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1B01-00 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1B01-M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1B01-01 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1B01-100 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1B01-1M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1B01-101 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1B01-200 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1B01-2M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1B01-201 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1B01-300 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1B01-3M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1B01-301 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1B01-500 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1B01-5M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1B01-501 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1B01-600 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1B01-6M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1B01-601 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1B01-700 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1B01-7M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1B01-701 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1B01-800 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1B01-8M5 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1B01-801 Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1200-00 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1200-01 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1200-02 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1200-100 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1200-101 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1200-102 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1200-200 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1200-201 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1200-202 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1200-300 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1200-301 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1200-302 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1200-500 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1200-501 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1200-502 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1200-600 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1200-601 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1200-602 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1200-700 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1200-701 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1200-702 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1200-800 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1200-801 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1200-802 Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1201-00 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1201-01 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1201-02 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1201-100 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1201-101 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1201-102 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1201-200 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1201-201 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1201-202 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1201-300 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1201-301 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1201-302 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1201-500 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1201-501 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1201-502 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1201-600 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1201-601 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1201-602 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1201-700 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1201-701 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1201-702 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1201-800 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1201-801 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1201-802 Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1400-00 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1400-02 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1400-03 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1400-04 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1400-100 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1400-102 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1400-103 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1400-104 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1400-200 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1400-202 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1400-203 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1400-204 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1400-300 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1400-302 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1400-303 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1400-304 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1400-500 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1400-502 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1400-503 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1400-504 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1400-600 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1400-602 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1400-603 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1400-604 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1400-700 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1400-702 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1400-703 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1400-704 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1400-800 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1400-802 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1400-803 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1400-804 Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1401-00 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1401-02 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1401-03 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1401-04 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1401-100 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1401-102 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1401-103 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1401-104 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1401-200 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1401-202 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1401-203 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1401-204 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1401-300 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1401-302 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1401-303 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1401-304 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1401-500 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1401-502 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1401-503 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1401-504 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1401-600 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1401-602 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1401-603 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1401-604 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1401-700 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1401-702 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1401-703 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1401-704 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1401-800 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1401-802 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1401-803 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1401-804 Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1A00-M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1A00-1M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1A00-2M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1A00-3M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1A00-5M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1A00-6M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1A00-7M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1A00-8M5 Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1A01-M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1A01-1M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1A01-2M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1A01-3M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1A01-5M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1A01-6M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1A01-7M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1A01-8M5 Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1100-01 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1100-02 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1100-101 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1100-102 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1100-201 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1100-202 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1100-301 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1100-302 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1100-501 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1100-502 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1100-601 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1100-602 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1100-701 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1100-702 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1100-801 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1100-802 Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1101-01 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1101-02 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1101-101 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1101-102 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1101-201 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1101-202 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1101-301 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1101-302 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1101-501 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1101-502 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1101-601 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1101-602 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1101-701 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1101-702 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1101-801 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1101-802 Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1300-02 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1300-03 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1300-04 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1300-102 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1300-103 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1300-104 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1300-202 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1300-203 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1300-204 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1300-302 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1300-303 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1300-304 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1300-502 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1300-503 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1300-504 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1300-602 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1300-603 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1300-604 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1300-702 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1300-703 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1300-704 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1300-802 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1300-803 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1300-804 Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1301-02 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1301-03 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1301-04 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1301-102 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1301-103 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1301-104 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1301-202 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1301-203 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1301-204 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1301-302 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1301-303 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1301-304 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1301-502 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1301-503 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1301-504 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1301-602 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1301-603 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1301-604 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1301-702 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1301-703 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1301-704 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1301-802 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1301-803 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1301-804 Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1500-04 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1500-06 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/4
VY1500-10 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1500-104 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1500-106 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/4
VY1500-110 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1500-204 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1500-206 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/4
VY1500-210 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1500-304 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1500-306 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/4
VY1500-310 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1500-504 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1500-506 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/4
VY1500-510 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1500-604 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1500-606 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/4
VY1500-610 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1500-704 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1500-706 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/4
VY1500-710 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1500-804 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1500-806 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/4
VY1500-810 Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1501-04 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1501-06 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/4
VY1501-10 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1501-104 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1501-106 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/4
VY1501-110 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1501-204 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1501-206 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/4
VY1501-210 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1501-304 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1501-306 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/4
VY1501-310 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1501-504 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1501-506 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/4
VY1501-510 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1501-604 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1501-606 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/4
VY1501-610 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1501-704 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1501-706 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/4
VY1501-710 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1501-804 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1501-806 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/4
VY1501-810 Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1700-10 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1700-12 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/4
VY1700-110 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1700-112 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/4
VY1700-210 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1700-212 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/4
VY1700-310 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1700-312 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/4
VY1700-510 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1700-512 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/4
VY1700-610 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1700-612 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/4
VY1700-710 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1700-712 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/4
VY1700-810 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1700-812 Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/4
VY1701-10 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1701-12 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/4
VY1701-110 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1701-112 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/4
VY1701-210 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1701-212 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/4
VY1701-310 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1701-312 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/4
VY1701-510 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1701-512 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/4
VY1701-610 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1701-612 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/4
VY1701-710 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1701-712 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/4
VY1701-810 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1701-812 Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/4
VY1900-14 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/2
VY1900-20 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc2
VY1900-114 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/2
VY1900-120 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc2
VY1900-214 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/2
VY1900-220 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc2
VY1900-314 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/2
VY1900-320 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc2
VY1900-514 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/2
VY1900-520 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc2
VY1900-614 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/2
VY1900-620 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc2
VY1900-714 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/2
VY1900-720 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc2
VY1900-814 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/2
VY1900-820 Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc2
VY1901-14 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/2
VY1901-20 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc2
VY1901-114 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/2
VY1901-120 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc2
VY1901-214 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/2
VY1901-220 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc2
VY1901-314 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/2
VY1901-320 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc2
VY1901-514 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/2
VY1901-520 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc2
VY1901-614 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/2
VY1901-620 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc2
VY1901-714 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/2
VY1901-720 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc2
VY1901-814 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/2
VY1901-820 Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc2
Electro-Pneumatic RegulatorsSMC
384 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC VY1 E-P HYREG Electro-Pneumatic Regulator (M5 to 2 inch)

Brand SMC·Electro-Pneumatic Regulators

Available part numbers (384)

VY1D00-00, VY1D00-M5, VY1D00-100, VY1D00-1M5, VY1D00-200, VY1D00-2M5, VY1D00-300, VY1D00-3M5, VY1D00-500, VY1D00-5M5 + 374 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VY1D00-00Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1D00-M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1D00-100Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1D00-1M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1D00-200Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1D00-2M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1D00-300Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1D00-3M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1D00-500Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1D00-5M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1D00-600Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1D00-6M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1D00-700Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1D00-7M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1D00-800Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1D00-8M5Body size: D (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1B00-00Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1B00-M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1B00-01Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1B00-100Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1B00-1M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1B00-101Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1B00-200Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1B00-2M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1B00-201Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1B00-300Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1B00-3M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1B00-301Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1B00-500Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1B00-5M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1B00-501Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1B00-600Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1B00-6M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1B00-601Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1B00-700Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1B00-7M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1B00-701Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1B00-800Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1B00-8M5Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1B00-801Body size: B (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1B01-00Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1B01-M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1B01-01Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1B01-100Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1B01-1M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1B01-101Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1B01-200Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1B01-2M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1B01-201Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1B01-300Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1B01-3M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1B01-301Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1B01-500Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1B01-5M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1B01-501Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1B01-600Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1B01-6M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1B01-601Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1B01-700Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1B01-7M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1B01-701Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1B01-800Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1B01-8M5Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1B01-801Body size: B (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1200-00Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1200-01Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1200-02Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1200-100Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1200-101Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1200-102Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1200-200Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1200-201Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1200-202Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1200-300Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1200-301Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1200-302Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1200-500Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1200-501Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1200-502Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1200-600Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1200-601Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1200-602Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1200-700Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1200-701Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1200-702Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1200-800Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1200-801Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1200-802Body size: 2 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1201-00Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1201-01Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1201-02Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1201-100Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1201-101Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1201-102Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1201-200Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1201-201Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1201-202Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1201-300Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1201-301Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1201-302Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1201-500Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1201-501Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1201-502Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1201-600Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1201-601Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1201-602Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1201-700Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1201-701Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1201-702Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1201-800Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1201-801Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1201-802Body size: 2 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1400-00Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1400-02Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1400-03Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1400-04Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1400-100Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1400-102Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1400-103Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1400-104Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1400-200Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1400-202Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1400-203Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1400-204Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1400-300Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1400-302Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1400-303Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1400-304Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1400-500Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1400-502Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1400-503Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1400-504Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1400-600Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1400-602Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1400-603Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1400-604Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1400-700Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1400-702Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1400-703Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1400-704Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1400-800Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1400-802Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1400-803Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1400-804Body size: 4 (Base mounted) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1401-00Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Without sub-plate
VY1401-02Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1401-03Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1401-04Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1401-100Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Without sub-plate
VY1401-102Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1401-103Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1401-104Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1401-200Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Without sub-plate
VY1401-202Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1401-203Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1401-204Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1401-300Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Without sub-plate
VY1401-302Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1401-303Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1401-304Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1401-500Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Without sub-plate
VY1401-502Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1401-503Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1401-504Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1401-600Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Without sub-plate
VY1401-602Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1401-603Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1401-604Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1401-700Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Without sub-plate
VY1401-702Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1401-703Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1401-704Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1401-800Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Without sub-plate
VY1401-802Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1401-803Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1401-804Body size: 4 (Base mounted) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1A00-M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1A00-1M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1A00-2M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1A00-3M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1A00-5M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1A00-6M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1A00-7M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1A00-8M5Body size: A (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1A01-M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: M5
VY1A01-1M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: M5
VY1A01-2M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: M5
VY1A01-3M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: M5
VY1A01-5M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: M5
VY1A01-6M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: M5
VY1A01-7M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: M5
VY1A01-8M5Body size: A (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: M5
VY1100-01Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1100-02Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1100-101Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1100-102Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1100-201Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1100-202Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1100-301Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1100-302Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1100-501Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1100-502Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1100-601Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1100-602Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1100-701Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1100-702Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1100-801Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1100-802Body size: 1 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1101-01Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/8
VY1101-02Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1101-101Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/8
VY1101-102Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1101-201Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/8
VY1101-202Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1101-301Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/8
VY1101-302Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1101-501Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/8
VY1101-502Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1101-601Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/8
VY1101-602Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1101-701Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/8
VY1101-702Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1101-801Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/8
VY1101-802Body size: 1 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1300-02Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1300-03Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1300-04Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1300-102Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1300-103Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1300-104Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1300-202Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1300-203Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1300-204Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1300-302Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1300-303Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1300-304Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1300-502Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1300-503Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1300-504Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1300-602Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1300-603Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1300-604Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1300-702Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1300-703Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1300-704Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1300-802Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1300-803Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1300-804Body size: 3 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1301-02Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/4
VY1301-03Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/8
VY1301-04Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1301-102Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/4
VY1301-103Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/8
VY1301-104Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1301-202Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/4
VY1301-203Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/8
VY1301-204Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1301-302Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/4
VY1301-303Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/8
VY1301-304Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1301-502Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/4
VY1301-503Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/8
VY1301-504Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1301-602Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/4
VY1301-603Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/8
VY1301-604Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1301-702Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/4
VY1301-703Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/8
VY1301-704Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1301-802Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/4
VY1301-803Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/8
VY1301-804Body size: 3 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1500-04Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1500-06Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/4
VY1500-10Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1500-104Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1500-106Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/4
VY1500-110Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1500-204Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1500-206Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/4
VY1500-210Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1500-304Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1500-306Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/4
VY1500-310Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1500-504Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1500-506Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/4
VY1500-510Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1500-604Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1500-606Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/4
VY1500-610Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1500-704Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1500-706Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/4
VY1500-710Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1500-804Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1500-806Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/4
VY1500-810Body size: 5 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1501-04Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1/2
VY1501-06Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc3/4
VY1501-10Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1501-104Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1/2
VY1501-106Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc3/4
VY1501-110Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1501-204Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1/2
VY1501-206Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc3/4
VY1501-210Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1501-304Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1/2
VY1501-306Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc3/4
VY1501-310Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1501-504Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1/2
VY1501-506Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc3/4
VY1501-510Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1501-604Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1/2
VY1501-606Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc3/4
VY1501-610Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1501-704Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1/2
VY1501-706Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc3/4
VY1501-710Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1501-804Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1/2
VY1501-806Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc3/4
VY1501-810Body size: 5 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1700-10Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1700-12Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/4
VY1700-110Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1700-112Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/4
VY1700-210Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1700-212Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/4
VY1700-310Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1700-312Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/4
VY1700-510Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1700-512Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/4
VY1700-610Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1700-612Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/4
VY1700-710Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1700-712Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/4
VY1700-810Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1700-812Body size: 7 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/4
VY1701-10Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1
VY1701-12Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/4
VY1701-110Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1
VY1701-112Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/4
VY1701-210Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1
VY1701-212Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/4
VY1701-310Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1
VY1701-312Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/4
VY1701-510Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1
VY1701-512Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/4
VY1701-610Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1
VY1701-612Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/4
VY1701-710Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1
VY1701-712Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/4
VY1701-810Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1
VY1701-812Body size: 7 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/4
VY1900-14Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/2
VY1900-20Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 1-5V | Port size: Rc2
VY1900-114Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/2
VY1900-120Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-10V | Port size: Rc2
VY1900-214Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/2
VY1900-220Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 4-20mA | Port size: Rc2
VY1900-314Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/2
VY1900-320Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC24V, 0-20mA | Port size: Rc2
VY1900-514Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/2
VY1900-520Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 1-5V | Port size: Rc2
VY1900-614Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/2
VY1900-620Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-10V | Port size: Rc2
VY1900-714Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/2
VY1900-720Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 4-20mA | Port size: Rc2
VY1900-814Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/2
VY1900-820Body size: 9 (Direct piping) | Pilot: Internal pilot | Supply / command: DC12V, 0-20mA | Port size: Rc2
VY1901-14Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc1 1/2
VY1901-20Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 1-5V | Port size: Rc2
VY1901-114Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc1 1/2
VY1901-120Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-10V | Port size: Rc2
VY1901-214Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc1 1/2
VY1901-220Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 4-20mA | Port size: Rc2
VY1901-314Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc1 1/2
VY1901-320Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC24V, 0-20mA | Port size: Rc2
VY1901-514Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc1 1/2
VY1901-520Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 1-5V | Port size: Rc2
VY1901-614Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc1 1/2
VY1901-620Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-10V | Port size: Rc2
VY1901-714Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc1 1/2
VY1901-720Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 4-20mA | Port size: Rc2
VY1901-814Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc1 1/2
VY1901-820Body size: 9 (Direct piping) | Pilot: External pilot | Supply / command: DC12V, 0-20mA | Port size: Rc2

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
