• SMC WF300 Water Strainer (Rc1/4 to 1/2, 25 to 100 Mesh)
1 1

SMC WF300 Water Strainer (Rc1/4 to 1/2, 25 to 100 Mesh)

SMC WF300 Water Strainer (Rc1/4 to 1/2, 25 to 100 Mesh)

SMC WF300 bronze Y-type water strainer that removes foreign matter from water lines, with stainless steel mesh element from 25 to 100 mesh.

Key features

  • Bronze casting body, brass cap, NBR O-ring
  • Stainless steel mesh element: 100 mesh standard; 70, 50, 25 mesh via -X204
  • Ports Rc1/4, 3/8, 1/2
  • Replacement elements 11366-1-1 (70), 11366-2-1 (50), 11366-3-1 (25 mesh)
  • Not for deionized water; FKM O-ring on request

Specifications

Fluid Water (not DI water)
Proof pressure 1.67 MPa
Max. operating pressure 1.18 MPa
Ambient and fluid temperature 5 to 80 C
Body material Bronze casting
Element Stainless steel mesh
Mass 0.29 kg
Source SMC Korea leaflet WF300 (SMCKR_WF300.pdf), 14-K628, p. 1-2
WF300-02 Port size: Rc1/4 | Mesh: 100 mesh (150 um)
WF300-02-1-X204 Port size: Rc1/4 | Mesh: 70 mesh (200 um)
WF300-02-2-X204 Port size: Rc1/4 | Mesh: 50 mesh (300 um)
WF300-02-3-X204 Port size: Rc1/4 | Mesh: 25 mesh (700 um)
WF300-03 Port size: Rc3/8 | Mesh: 100 mesh (150 um)
WF300-03-1-X204 Port size: Rc3/8 | Mesh: 70 mesh (200 um)
WF300-03-2-X204 Port size: Rc3/8 | Mesh: 50 mesh (300 um)
WF300-03-3-X204 Port size: Rc3/8 | Mesh: 25 mesh (700 um)
WF300-04 Port size: Rc1/2 | Mesh: 100 mesh (150 um)
WF300-04-1-X204 Port size: Rc1/2 | Mesh: 70 mesh (200 um)
WF300-04-2-X204 Port size: Rc1/2 | Mesh: 50 mesh (300 um)
WF300-04-3-X204 Port size: Rc1/2 | Mesh: 25 mesh (700 um)
FiltersSMC
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC WF300 Water Strainer (Rc1/4 to 1/2, 25 to 100 Mesh)

Brand SMC·Filters

Available part numbers (12)

WF300-02, WF300-02-1-X204, WF300-02-2-X204, WF300-02-3-X204, WF300-03, WF300-03-1-X204, WF300-03-2-X204, WF300-03-3-X204, WF300-04, WF300-04-1-X204 + 2 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WF300-02Port size: Rc1/4 | Mesh: 100 mesh (150 um)
WF300-02-1-X204Port size: Rc1/4 | Mesh: 70 mesh (200 um)
WF300-02-2-X204Port size: Rc1/4 | Mesh: 50 mesh (300 um)
WF300-02-3-X204Port size: Rc1/4 | Mesh: 25 mesh (700 um)
WF300-03Port size: Rc3/8 | Mesh: 100 mesh (150 um)
WF300-03-1-X204Port size: Rc3/8 | Mesh: 70 mesh (200 um)
WF300-03-2-X204Port size: Rc3/8 | Mesh: 50 mesh (300 um)
WF300-03-3-X204Port size: Rc3/8 | Mesh: 25 mesh (700 um)
WF300-04Port size: Rc1/2 | Mesh: 100 mesh (150 um)
WF300-04-1-X204Port size: Rc1/2 | Mesh: 70 mesh (200 um)
WF300-04-2-X204Port size: Rc1/2 | Mesh: 50 mesh (300 um)
WF300-04-3-X204Port size: Rc1/2 | Mesh: 25 mesh (700 um)
