SMC XMD/XYD Stainless High Vacuum Valve (2-Stage Exhaust, 25-80)

SMC XMD/XYD Stainless High Vacuum Valve (2-Stage Exhaust, 25-80)

SMC XMD (L-type) and XYD (straight type) stainless steel high vacuum valves with integrated two-stage (initial and main) exhaust control.

Key features

  • Initial slow exhaust and main exhaust valves in one stainless body
  • Normally closed, spring seal; bellows main valve, O-ring initial valve
  • Initial exhaust conductance 0.5-3 L/s (25) to 4-18 L/s (80)
  • High-temperature version to 150 C (H0)
  • Auto switch (D-M9N/M9P/M9B/A90/A93, 1 or 2 pcs) is an order suffix, not expanded

Specifications

Valve type N.C., 2-stage control
Fluid Inert gas under vacuum
Body material Stainless steel SCS13 (SUS304 equiv.)
Bellows SUS316L
Operating pressure 1x10^-6 Pa(abs) to atmospheric
Leakage (FKM) Internal 1.3x10^-10, external 1.3x10^-11 Pa m3/s
Main conductance L/s: 25=14, 40=45, 50=80, 63=160, 80=200
Pilot pressure 0.4-0.7 MPa
