SMC ZCUK Free Mount Cylinder with Vacuum Passage (ø10 to ø32)

SMC ZCUK Free Mount Cylinder with Vacuum Passage (ø10 to ø32)

SMC ZCUK series non-rotating free mount cylinder with a vacuum passage through the piston rod, so a vacuum pad can be fitted at the rod end without separate vacuum piping, ø10 to ø32 mm bore.

Key features

  • Vacuum passage through the rod: no vacuum tubing needed around the pad at the rod end
  • Four piping/rod end styles: cap or rod-side vacuum port, each with male rod end (ZPT pad) or direct pad mounting (ZP pad, -X11)
  • Non-rotating rod based on the CUK free mount cylinder; square body mountable on several faces
  • Built-in magnet versions (ZCDUK) accept D-M9, D-M9W, D-M9A and D-A9 auto switches (ordered as a suffix)
  • Vacuum pads (ZPT/ZP series) are ordered separately

Specifications

Action Double acting, single rod, non-rotating
Fluid Air
Proof pressure 1.05 MPa
Max. operating pressure 0.7 MPa
Vacuum port pressure -101 kPa to 0.6 MPa
Ambient and fluid temperature -10 to 70°C without magnet, -10 to 60°C with magnet (no freezing)
Lubrication Not required (non-lube)
Piston speed 50 to 500 mm/s
Cushion Rubber bumper both ends
Stroke length tolerance +1.0/0 mm
Source SMC Korea catalog CU (SMCKR_CU.pdf), p. 777-779 (PDF p. 55-57)
ZCUKC10-5D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-10D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-15D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-20D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-25D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-30D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-5D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-10D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-15D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-20D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-25D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-30D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-5D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-10D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-15D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-20D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-25D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-30D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-40D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-50D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-5D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-10D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-15D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-20D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-25D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-30D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-40D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-50D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC32-5D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-10D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-15D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-20D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-25D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-30D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-40D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-50D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD10-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-40D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-50D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-40D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-50D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD32-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-40D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-50D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ10-5D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-10D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-15D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-20D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-25D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-30D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-5D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-10D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-15D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-20D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-25D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-30D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-5D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-10D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-15D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-20D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-25D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-30D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-40D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-50D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-5D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-10D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-15D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-20D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-25D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-30D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-40D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-50D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ32-5D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-10D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-15D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-20D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-25D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-30D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-40D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-50D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR10-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-40D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-50D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-40D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-50D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR32-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-40D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-50D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCDUKC10-5D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-10D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-15D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-20D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-25D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-30D Vacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-5D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-10D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-15D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-20D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-25D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-30D Vacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-5D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-10D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-15D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-20D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-25D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-30D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-40D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-50D Vacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-5D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-10D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-15D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-20D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-25D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-30D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-40D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-50D Vacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC32-5D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-10D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-15D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-20D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-25D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-30D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-40D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-50D Vacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD10-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-40D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-50D Vacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-40D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-50D Vacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD32-5D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-10D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-15D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-20D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-25D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-30D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-40D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-50D Vacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ10-5D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-10D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-15D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-20D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-25D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-30D Vacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-5D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-10D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-15D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-20D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-25D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-30D Vacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-5D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-10D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-15D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-20D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-25D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-30D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-40D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-50D Vacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-5D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-10D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-15D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-20D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-25D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-30D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-40D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-50D Vacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ32-5D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-10D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-15D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-20D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-25D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-30D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-40D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-50D Vacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR10-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-40D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-50D Vacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-40D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-50D Vacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR32-5D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-10D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-15D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-20D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-25D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-30D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-40D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-50D Vacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
Compact CylindersSMC
288 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ZCUK Free Mount Cylinder with Vacuum Passage (ø10 to ø32)

Brand SMC·Compact Cylinders

Available part numbers (288)

ZCUKC10-5D, ZCUKC10-10D, ZCUKC10-15D, ZCUKC10-20D, ZCUKC10-25D, ZCUKC10-30D, ZCUKC16-5D, ZCUKC16-10D, ZCUKC16-15D, ZCUKC16-20D + 278 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ZCUKC10-5DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-10DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-15DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-20DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-25DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC10-30DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-5DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-10DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-15DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-20DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-25DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC16-30DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-5DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-10DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-15DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-20DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-25DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-30DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-40DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC20-50DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-5DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-10DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-15DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-20DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-25DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-30DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-40DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC25-50DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKC32-5DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-10DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-15DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-20DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-25DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-30DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-40DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKC32-50DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD10-5DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-10DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-15DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-20DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-25DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD10-30DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-5DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-10DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-15DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-20DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-25DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD16-30DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-5DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-10DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-15DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-20DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-25DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-30DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-40DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD20-50DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-5DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-10DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-15DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-20DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-25DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-30DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-40DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD25-50DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKD32-5DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-10DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-15DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-20DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-25DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-30DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-40DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKD32-50DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ10-5DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-10DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-15DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-20DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-25DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ10-30DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-5DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-10DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-15DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-20DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-25DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ16-30DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-5DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-10DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-15DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-20DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-25DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-30DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-40DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ20-50DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-5DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-10DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-15DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-20DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-25DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-30DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-40DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ25-50DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKQ32-5DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-10DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-15DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-20DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-25DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-30DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-40DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKQ32-50DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR10-5DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-10DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-15DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-20DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-25DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR10-30DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-5DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-10DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-15DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-20DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-25DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR16-30DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-5DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-10DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-15DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-20DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-25DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-30DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-40DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR20-50DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-5DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-10DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-15DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-20DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-25DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-30DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-40DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR25-50DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: No | Port: M5x0.8
ZCUKR32-5DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-10DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-15DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-20DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-25DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-30DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-40DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: No | Port: Rc1/8
ZCUKR32-50DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: No | Port: Rc1/8
ZCDUKC10-5DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-10DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-15DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-20DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-25DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC10-30DVacuum piping: Cap piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-5DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-10DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-15DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-20DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-25DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC16-30DVacuum piping: Cap piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-5DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-10DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-15DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-20DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-25DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-30DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-40DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC20-50DVacuum piping: Cap piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-5DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-10DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-15DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-20DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-25DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-30DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-40DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC25-50DVacuum piping: Cap piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKC32-5DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-10DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-15DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-20DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-25DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-30DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-40DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKC32-50DVacuum piping: Cap piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD10-5DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-10DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-15DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-20DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-25DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD10-30DVacuum piping: Cap piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-5DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-10DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-15DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-20DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-25DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD16-30DVacuum piping: Cap piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-5DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-10DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-15DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-20DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-25DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-30DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-40DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD20-50DVacuum piping: Cap piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-5DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-10DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-15DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-20DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-25DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-30DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-40DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD25-50DVacuum piping: Cap piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKD32-5DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-10DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-15DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-20DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-25DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-30DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-40DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKD32-50DVacuum piping: Cap piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ10-5DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-10DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-15DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-20DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-25DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ10-30DVacuum piping: Rod piping, male rod end | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-5DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-10DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-15DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-20DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-25DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ16-30DVacuum piping: Rod piping, male rod end | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-5DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-10DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-15DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-20DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-25DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-30DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-40DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ20-50DVacuum piping: Rod piping, male rod end | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-5DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-10DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-15DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-20DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-25DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-30DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-40DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ25-50DVacuum piping: Rod piping, male rod end | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKQ32-5DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-10DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-15DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-20DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-25DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-30DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-40DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKQ32-50DVacuum piping: Rod piping, male rod end | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR10-5DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-10DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-15DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-20DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-25DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR10-30DVacuum piping: Rod piping, direct pad mount | Bore: ø10 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-5DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-10DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-15DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-20DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-25DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR16-30DVacuum piping: Rod piping, direct pad mount | Bore: ø16 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-5DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-10DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-15DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-20DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-25DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-30DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-40DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR20-50DVacuum piping: Rod piping, direct pad mount | Bore: ø20 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-5DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-10DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-15DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-20DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-25DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-30DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-40DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR25-50DVacuum piping: Rod piping, direct pad mount | Bore: ø25 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: M5x0.8
ZCDUKR32-5DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 5 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-10DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 10 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-15DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 15 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-20DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 20 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-25DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 25 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-30DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 30 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-40DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 40 mm | Auto switch magnet: Yes | Port: Rc1/8
ZCDUKR32-50DVacuum piping: Rod piping, direct pad mount | Bore: ø32 mm | Stroke: 50 mm | Auto switch magnet: Yes | Port: Rc1/8

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
