SMC ZP-905-CJXN0525 Static Dissipative Vacuum Pad (ø4 to ø30)

SMC ZP-905-CJXN0525 Static Dissipative Vacuum Pad (ø4 to ø30)

SMC ZP-905-CJXN0525 static dissipative vacuum pad, ø4 to ø30 in four pad shapes, with matching stainless steel mounting adapters.

Key features

  • Surface resistivity 1.0x10^6 to 9.9x10^9 ohm/sq dissipates static from friction with the workpiece, preventing ESD damage and dust adhesion
  • Pad shapes: MU flat (ø4, ø6), UM flat with groove (ø6, ø8, ø10, ø16), MT flat (ø10 to ø30), MB bellows (ø8, ø10)
  • Material: carbon-containing silicone (black, standard) or carbon-free SCZ-NBR (blue, HBU)
  • All-stainless mounting adapters (copper-free) with M5x0.8 connection, groundable structure
  • Surface resistance varies with temperature and humidity; replace pads when wear reduces vacuum or response

Specifications

Surface resistivity 1.0x10^6 to 9.9x10^9 ohm/sq
Adapter connection M5x0.8
Adapter material Stainless steel (copper-free)
Gasket Supplied with ZP2A-0305/-0406 (0.5 mm); MT pads used without gasket
Order example ZP-905-10MT-CJXN0525
Source SMC Korea leaflet CAT.SK-19-01B (SMCKR_ZP-905-CJXN0525_ZP3-CJXU0723__SK-19-01__250425.pdf), PDF p. 1-4
ZP-905-04MU-CJXN0525 Item: Pad | Pad diameter: ø4 | Pad type: Flat | Material: Silicone (carbon, black)
ZP-905-04MUHBU-CJXN0525 Item: Pad | Pad diameter: ø4 | Pad type: Flat | Material: SCZ-NBR (carbon-free, blue)
ZP-905-06MU-CJXN0525 Item: Pad | Pad diameter: ø6 | Pad type: Flat | Material: Silicone (carbon, black)
ZP-905-06MUHBU-CJXN0525 Item: Pad | Pad diameter: ø6 | Pad type: Flat | Material: SCZ-NBR (carbon-free, blue)
ZP-905-06UM-CJXN0525 Item: Pad | Pad diameter: ø6 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-06UMHBU-CJXN0525 Item: Pad | Pad diameter: ø6 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-08UM-CJXN0525 Item: Pad | Pad diameter: ø8 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-08UMHBU-CJXN0525 Item: Pad | Pad diameter: ø8 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-10UM-CJXN0525 Item: Pad | Pad diameter: ø10 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-10UMHBU-CJXN0525 Item: Pad | Pad diameter: ø10 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-16UM-CJXN0525 Item: Pad | Pad diameter: ø16 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-16UMHBU-CJXN0525 Item: Pad | Pad diameter: ø16 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-10MT-CJXN0525 Item: Pad | Pad diameter: ø10 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-10MTHBU-CJXN0525 Item: Pad | Pad diameter: ø10 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-15MT-CJXN0525 Item: Pad | Pad diameter: ø15 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-15MTHBU-CJXN0525 Item: Pad | Pad diameter: ø15 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-20MT-CJXN0525 Item: Pad | Pad diameter: ø20 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-20MTHBU-CJXN0525 Item: Pad | Pad diameter: ø20 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-25MT-CJXN0525 Item: Pad | Pad diameter: ø25 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-25MTHBU-CJXN0525 Item: Pad | Pad diameter: ø25 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-30MT-CJXN0525 Item: Pad | Pad diameter: ø30 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-30MTHBU-CJXN0525 Item: Pad | Pad diameter: ø30 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-08MB-CJXN0525 Item: Pad | Pad diameter: ø8 | Pad type: Bellows | Material: Silicone (carbon, black)
ZP-905-08MBHBU-CJXN0525 Item: Pad | Pad diameter: ø8 | Pad type: Bellows | Material: SCZ-NBR (carbon-free, blue)
ZP-905-10MB-CJXN0525 Item: Pad | Pad diameter: ø10 | Pad type: Bellows | Material: Silicone (carbon, black)
ZP-905-10MBHBU-CJXN0525 Item: Pad | Pad diameter: ø10 | Pad type: Bellows | Material: SCZ-NBR (carbon-free, blue)
ZP2A-0305-CJXN0885 Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 04MU, 06MU, 06UM, 08UM, 10MT | Pad type: - | Material: Stainless steel
ZP2A-0406-CJXN0885 Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 08MB, 10UM, 16UM, 15MT | Pad type: - | Material: Stainless steel
ZP2A-4678-CJXN0885 Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 10MB | Pad type: - | Material: Stainless steel
ZP2A-0610-CJXN0885 Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 20MT, 25MT, 30MT | Pad type: - | Material: Stainless steel
Vacuum PadsSMC
30 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ZP-905-CJXN0525 Static Dissipative Vacuum Pad (ø4 to ø30)

Brand SMC·Vacuum Pads

Available part numbers (30)

ZP-905-04MU-CJXN0525, ZP-905-04MUHBU-CJXN0525, ZP-905-06MU-CJXN0525, ZP-905-06MUHBU-CJXN0525, ZP-905-06UM-CJXN0525, ZP-905-06UMHBU-CJXN0525, ZP-905-08UM-CJXN0525, ZP-905-08UMHBU-CJXN0525, ZP-905-10UM-CJXN0525, ZP-905-10UMHBU-CJXN0525 + 20 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ZP-905-04MU-CJXN0525Item: Pad | Pad diameter: ø4 | Pad type: Flat | Material: Silicone (carbon, black)
ZP-905-04MUHBU-CJXN0525Item: Pad | Pad diameter: ø4 | Pad type: Flat | Material: SCZ-NBR (carbon-free, blue)
ZP-905-06MU-CJXN0525Item: Pad | Pad diameter: ø6 | Pad type: Flat | Material: Silicone (carbon, black)
ZP-905-06MUHBU-CJXN0525Item: Pad | Pad diameter: ø6 | Pad type: Flat | Material: SCZ-NBR (carbon-free, blue)
ZP-905-06UM-CJXN0525Item: Pad | Pad diameter: ø6 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-06UMHBU-CJXN0525Item: Pad | Pad diameter: ø6 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-08UM-CJXN0525Item: Pad | Pad diameter: ø8 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-08UMHBU-CJXN0525Item: Pad | Pad diameter: ø8 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-10UM-CJXN0525Item: Pad | Pad diameter: ø10 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-10UMHBU-CJXN0525Item: Pad | Pad diameter: ø10 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-16UM-CJXN0525Item: Pad | Pad diameter: ø16 | Pad type: Flat with groove | Material: Silicone (carbon, black)
ZP-905-16UMHBU-CJXN0525Item: Pad | Pad diameter: ø16 | Pad type: Flat with groove | Material: SCZ-NBR (carbon-free, blue)
ZP-905-10MT-CJXN0525Item: Pad | Pad diameter: ø10 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-10MTHBU-CJXN0525Item: Pad | Pad diameter: ø10 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-15MT-CJXN0525Item: Pad | Pad diameter: ø15 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-15MTHBU-CJXN0525Item: Pad | Pad diameter: ø15 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-20MT-CJXN0525Item: Pad | Pad diameter: ø20 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-20MTHBU-CJXN0525Item: Pad | Pad diameter: ø20 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-25MT-CJXN0525Item: Pad | Pad diameter: ø25 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-25MTHBU-CJXN0525Item: Pad | Pad diameter: ø25 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-30MT-CJXN0525Item: Pad | Pad diameter: ø30 | Pad type: Flat (thin lip) | Material: Silicone (carbon, black)
ZP-905-30MTHBU-CJXN0525Item: Pad | Pad diameter: ø30 | Pad type: Flat (thin lip) | Material: SCZ-NBR (carbon-free, blue)
ZP-905-08MB-CJXN0525Item: Pad | Pad diameter: ø8 | Pad type: Bellows | Material: Silicone (carbon, black)
ZP-905-08MBHBU-CJXN0525Item: Pad | Pad diameter: ø8 | Pad type: Bellows | Material: SCZ-NBR (carbon-free, blue)
ZP-905-10MB-CJXN0525Item: Pad | Pad diameter: ø10 | Pad type: Bellows | Material: Silicone (carbon, black)
ZP-905-10MBHBU-CJXN0525Item: Pad | Pad diameter: ø10 | Pad type: Bellows | Material: SCZ-NBR (carbon-free, blue)
ZP2A-0305-CJXN0885Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 04MU, 06MU, 06UM, 08UM, 10MT | Pad type: - | Material: Stainless steel
ZP2A-0406-CJXN0885Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 08MB, 10UM, 16UM, 15MT | Pad type: - | Material: Stainless steel
ZP2A-4678-CJXN0885Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 10MB | Pad type: - | Material: Stainless steel
ZP2A-0610-CJXN0885Item: Mounting adapter (SUS, M5x0.8) | Pad diameter: For 20MT, 25MT, 30MT | Pad type: - | Material: Stainless steel
