SMC ZP2 Vacuum Pad with Ball Spline Buffer (ø2-8)

SMC ZP2 series small flat vacuum pad, ø2 to ø8, on a ball spline guided buffer for precise, low-friction compliance.

Key features

Buffer uses a ball spline guide for smooth, rattle-free stroke
Pad diameters ø2, ø4, ø6 and ø8, flat type
Six pad materials: NBR, silicone, urethane, FKM, conductive NBR, conductive silicone
6 mm buffer stroke with low spring reaction (0.8 to 1.1 N)
Pad supplied unassembled

Specifications

Pad shape	Flat (U)
Vacuum entry	Vertical (T)
Buffer	Ball spline (S), 6 mm stroke
Spring reaction	0.8 N at 0 stroke, 1.1 N at full stroke
Connection	M5x0.8 female, 18x18 mm flange (4x ø3.4)
Buffer assembly	ZP2B-T3S6 (with gasket)
Source	SMC Korea catalog Special-Application Pads ZP2/ZP3/ZP3P (SMCKR_ZP2_ZP3P_specials.pdf), p. 297 (PDF p. 54)

ZP2-T02UNS6		Pad diameter: ø2 \| Pad material: NBR \| Rubber colour: Black
ZP2-T02USS6		Pad diameter: ø2 \| Pad material: Silicone rubber \| Rubber colour: Milky white
ZP2-T02UUS6		Pad diameter: ø2 \| Pad material: Urethane rubber \| Rubber colour: Brown
ZP2-T02UFS6		Pad diameter: ø2 \| Pad material: FKM \| Rubber colour: Black
ZP2-T02UGNS6		Pad diameter: ø2 \| Pad material: Conductive NBR \| Rubber colour: Black
ZP2-T02UGSS6		Pad diameter: ø2 \| Pad material: Conductive silicone rubber \| Rubber colour: Black
ZP2-T04UNS6		Pad diameter: ø4 \| Pad material: NBR \| Rubber colour: Black
ZP2-T04USS6		Pad diameter: ø4 \| Pad material: Silicone rubber \| Rubber colour: Milky white
ZP2-T04UUS6		Pad diameter: ø4 \| Pad material: Urethane rubber \| Rubber colour: Brown
ZP2-T04UFS6		Pad diameter: ø4 \| Pad material: FKM \| Rubber colour: Black
ZP2-T04UGNS6		Pad diameter: ø4 \| Pad material: Conductive NBR \| Rubber colour: Black
ZP2-T04UGSS6		Pad diameter: ø4 \| Pad material: Conductive silicone rubber \| Rubber colour: Black
ZP2-T06UNS6		Pad diameter: ø6 \| Pad material: NBR \| Rubber colour: Black
ZP2-T06USS6		Pad diameter: ø6 \| Pad material: Silicone rubber \| Rubber colour: Milky white
ZP2-T06UUS6		Pad diameter: ø6 \| Pad material: Urethane rubber \| Rubber colour: Brown
ZP2-T06UFS6		Pad diameter: ø6 \| Pad material: FKM \| Rubber colour: Black
ZP2-T06UGNS6		Pad diameter: ø6 \| Pad material: Conductive NBR \| Rubber colour: Black
ZP2-T06UGSS6		Pad diameter: ø6 \| Pad material: Conductive silicone rubber \| Rubber colour: Black
ZP2-T08UNS6		Pad diameter: ø8 \| Pad material: NBR \| Rubber colour: Black
ZP2-T08USS6		Pad diameter: ø8 \| Pad material: Silicone rubber \| Rubber colour: Milky white
ZP2-T08UUS6		Pad diameter: ø8 \| Pad material: Urethane rubber \| Rubber colour: Brown
ZP2-T08UFS6		Pad diameter: ø8 \| Pad material: FKM \| Rubber colour: Black
ZP2-T08UGNS6		Pad diameter: ø8 \| Pad material: Conductive NBR \| Rubber colour: Black
ZP2-T08UGSS6		Pad diameter: ø8 \| Pad material: Conductive silicone rubber \| Rubber colour: Black

Vacuum PadsSMC

24 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ZP2 Vacuum Pad with Ball Spline Buffer (ø2-8)

Brand SMC·Vacuum Pads

Available part numbers (24)

ZP2-T02UNS6, ZP2-T02USS6, ZP2-T02UUS6, ZP2-T02UFS6, ZP2-T02UGNS6, ZP2-T02UGSS6, ZP2-T04UNS6, ZP2-T04USS6, ZP2-T04UUS6, ZP2-T04UFS6 + 14 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
