SMC ZP2 ZJ 4.5-Stage Bellows Vacuum Pad (ø15-46)

SMC ZP2 ZJ 4.5-Stage Bellows Vacuum Pad (ø15-46)

SMC ZP2 series ZJ 4.5-stage bellows vacuum pad for fast-moving and irregularly shaped workpieces, ø15 to ø46, as pad only or with vertical adapter.

Key features

  • 4.5-stage bellows follows varied workpiece shapes and handles high-speed conveyed parts
  • ø15, ø20 and ø30 (outer diameter) in silicone A40 or A60; ø40 and ø46 in NBR, urethane, FKM, conductive NBR/silicone or silicone A50
  • Single-thread adapter with large bore ø5 to ø22 for high-flow vacuum blowers (M10 to M30 male)
  • One-touch fitting adapter (ø6) with M12x1 or M14x1 male thread
  • Mounting nuts supplied unassembled; adapter assemblies also sold separately

Specifications

Pad shape 4.5-stage bellows (ZJ)
Fluid Air (vacuum)
Large bore (single thread type) ø5 to ø22, for high-flow vacuum blowers
Silicone compliance FDA 21CFR177.2600 and Japan Food Sanitation Act
Mounting nuts Supplied unassembled
Source SMC Korea catalog Special-Application Pads ZP2/ZP3/ZP3P (SMCKR_ZP2_ZP3P_specials.pdf), p. 276-281 (PDF p. 29-34)
ZP2-B15ZJS Pad diameter: ø15 | Pad material: Silicone rubber A40 | Mounting: Pad only | Connection: None
ZP2-TB15ZJS-A10 Pad diameter: ø15 | Pad material: Silicone rubber A40 | Mounting: Adapter, vertical, single thread | Connection: M10x1 male, port shared
ZP2-TB15ZJS-AL12-06 Pad diameter: ø15 | Pad material: Silicone rubber A40 | Mounting: Adapter, vertical, one-touch fitting | Connection: M12x1 male, one-touch ø6
ZP2-B15ZJS6 Pad diameter: ø15 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Pad only | Connection: None
ZP2-TB15ZJS6-A10 Pad diameter: ø15 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Adapter, vertical, single thread | Connection: M10x1 male, port shared
ZP2-TB15ZJS6-AL12-06 Pad diameter: ø15 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Adapter, vertical, one-touch fitting | Connection: M12x1 male, one-touch ø6
ZP2-B20ZJS Pad diameter: ø20 | Pad material: Silicone rubber A40 | Mounting: Pad only | Connection: None
ZP2-TB20ZJS-A10 Pad diameter: ø20 | Pad material: Silicone rubber A40 | Mounting: Adapter, vertical, single thread | Connection: M10x1 male, port shared
ZP2-TB20ZJS-AL12-06 Pad diameter: ø20 | Pad material: Silicone rubber A40 | Mounting: Adapter, vertical, one-touch fitting | Connection: M12x1 male, one-touch ø6
ZP2-B20ZJS6 Pad diameter: ø20 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Pad only | Connection: None
ZP2-TB20ZJS6-A10 Pad diameter: ø20 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Adapter, vertical, single thread | Connection: M10x1 male, port shared
ZP2-TB20ZJS6-AL12-06 Pad diameter: ø20 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Adapter, vertical, one-touch fitting | Connection: M12x1 male, one-touch ø6
ZP2-B30ZJS Pad diameter: ø30 | Pad material: Silicone rubber A40 | Mounting: Pad only | Connection: None
ZP2-TB30ZJS-A16 Pad diameter: ø30 | Pad material: Silicone rubber A40 | Mounting: Adapter, vertical, single thread | Connection: M16x1.5 male, port shared
ZP2-TB30ZJS-AL14-06 Pad diameter: ø30 | Pad material: Silicone rubber A40 | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-B30ZJS6 Pad diameter: ø30 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Pad only | Connection: None
ZP2-TB30ZJS6-A16 Pad diameter: ø30 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Adapter, vertical, single thread | Connection: M16x1.5 male, port shared
ZP2-TB30ZJS6-AL14-06 Pad diameter: ø30 | Pad material: Silicone rubber A60 (high hardness) | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-40ZJN Pad diameter: ø40 | Pad material: NBR | Mounting: Pad only | Connection: None
ZP2-T40ZJN-A20 Pad diameter: ø40 | Pad material: NBR | Mounting: Adapter, vertical, single thread | Connection: M20x1.5 male, port shared
ZP2-T40ZJN-AL14-06 Pad diameter: ø40 | Pad material: NBR | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-40ZJU Pad diameter: ø40 | Pad material: Urethane rubber | Mounting: Pad only | Connection: None
ZP2-T40ZJU-A20 Pad diameter: ø40 | Pad material: Urethane rubber | Mounting: Adapter, vertical, single thread | Connection: M20x1.5 male, port shared
ZP2-T40ZJU-AL14-06 Pad diameter: ø40 | Pad material: Urethane rubber | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-40ZJF Pad diameter: ø40 | Pad material: FKM | Mounting: Pad only | Connection: None
ZP2-T40ZJF-A20 Pad diameter: ø40 | Pad material: FKM | Mounting: Adapter, vertical, single thread | Connection: M20x1.5 male, port shared
ZP2-T40ZJF-AL14-06 Pad diameter: ø40 | Pad material: FKM | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-40ZJGN Pad diameter: ø40 | Pad material: Conductive NBR | Mounting: Pad only | Connection: None
ZP2-T40ZJGN-A20 Pad diameter: ø40 | Pad material: Conductive NBR | Mounting: Adapter, vertical, single thread | Connection: M20x1.5 male, port shared
ZP2-T40ZJGN-AL14-06 Pad diameter: ø40 | Pad material: Conductive NBR | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-40ZJGS Pad diameter: ø40 | Pad material: Conductive silicone rubber | Mounting: Pad only | Connection: None
ZP2-T40ZJGS-A20 Pad diameter: ø40 | Pad material: Conductive silicone rubber | Mounting: Adapter, vertical, single thread | Connection: M20x1.5 male, port shared
ZP2-T40ZJGS-AL14-06 Pad diameter: ø40 | Pad material: Conductive silicone rubber | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-40ZJS Pad diameter: ø40 | Pad material: Silicone rubber A50 | Mounting: Pad only | Connection: None
ZP2-T40ZJS-A20 Pad diameter: ø40 | Pad material: Silicone rubber A50 | Mounting: Adapter, vertical, single thread | Connection: M20x1.5 male, port shared
ZP2-T40ZJS-AL14-06 Pad diameter: ø40 | Pad material: Silicone rubber A50 | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-46ZJN Pad diameter: ø46 | Pad material: NBR | Mounting: Pad only | Connection: None
ZP2-T46ZJN-A30 Pad diameter: ø46 | Pad material: NBR | Mounting: Adapter, vertical, single thread | Connection: M30x1.5 male, port shared
ZP2-T46ZJN-AL14-06 Pad diameter: ø46 | Pad material: NBR | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-46ZJU Pad diameter: ø46 | Pad material: Urethane rubber | Mounting: Pad only | Connection: None
ZP2-T46ZJU-A30 Pad diameter: ø46 | Pad material: Urethane rubber | Mounting: Adapter, vertical, single thread | Connection: M30x1.5 male, port shared
ZP2-T46ZJU-AL14-06 Pad diameter: ø46 | Pad material: Urethane rubber | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-46ZJF Pad diameter: ø46 | Pad material: FKM | Mounting: Pad only | Connection: None
ZP2-T46ZJF-A30 Pad diameter: ø46 | Pad material: FKM | Mounting: Adapter, vertical, single thread | Connection: M30x1.5 male, port shared
ZP2-T46ZJF-AL14-06 Pad diameter: ø46 | Pad material: FKM | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-46ZJGN Pad diameter: ø46 | Pad material: Conductive NBR | Mounting: Pad only | Connection: None
ZP2-T46ZJGN-A30 Pad diameter: ø46 | Pad material: Conductive NBR | Mounting: Adapter, vertical, single thread | Connection: M30x1.5 male, port shared
ZP2-T46ZJGN-AL14-06 Pad diameter: ø46 | Pad material: Conductive NBR | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-46ZJGS Pad diameter: ø46 | Pad material: Conductive silicone rubber | Mounting: Pad only | Connection: None
ZP2-T46ZJGS-A30 Pad diameter: ø46 | Pad material: Conductive silicone rubber | Mounting: Adapter, vertical, single thread | Connection: M30x1.5 male, port shared
ZP2-T46ZJGS-AL14-06 Pad diameter: ø46 | Pad material: Conductive silicone rubber | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
ZP2-46ZJS Pad diameter: ø46 | Pad material: Silicone rubber A50 | Mounting: Pad only | Connection: None
ZP2-T46ZJS-A30 Pad diameter: ø46 | Pad material: Silicone rubber A50 | Mounting: Adapter, vertical, single thread | Connection: M30x1.5 male, port shared
ZP2-T46ZJS-AL14-06 Pad diameter: ø46 | Pad material: Silicone rubber A50 | Mounting: Adapter, vertical, one-touch fitting | Connection: M14x1 male, one-touch ø6
