SMC ZP3E High-Rigidity Vacuum Pad (Flat with Groove, ø32-125)

SMC ZP3E series high-rigidity flat vacuum pad with grooved suction face, ø32 to ø125, as pad only, with plate, standard or ball joint adapter, or spring buffer.

Key features

High-rigidity pad, flat with groove (UM), for corrugated board case erectors, palletizers, glass and car body handling
Single mounting screw (reduced from 4 on ZP high-rigidity type); rubber pad and metal parts can be separated for disposal
Grooved and blasted suction face improves release and stabilizes the suction posture
Standard or ball joint (30° swing) adapters with vertical (T) or lateral (Y) vacuum entry, and JB spring buffers with 10/30/50 mm stroke
Five pad materials: NBR, silicone, urethane, FKM and anti-pad-mark NBR (CL)
Mounting nuts supplied unassembled; adapter, buffer and plate assemblies also sold separately

Specifications

Pad diameters	ø32, ø40, ø50, ø63, ø80, ø100, ø125
Fluid	Air (vacuum)
Buffer type	JB: without rotation stop, bushing inserted
Buffer spring reaction	ø32-50: 5.0 N at 0 stroke; ø63-125: 10.0 N at 0 stroke
Ball joint swing angle	30°
Pad material colour/hardness	NBR black A50; silicone milky white A50; urethane blue A60; FKM black (marked F); anti-pad-mark NBR black
Silicone compliance	FDA 21CFR177.2600 and Japan Food Sanitation Act
Source	SMC Korea catalog ZP3E High-Rigidity Pads (SMCKR_ZP3E.pdf), p. 200-219 (PDF p. 1-20)

ZP3E-32UMN		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-32UMN-P		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T32UMN-A10		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T32UMN-B8		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T32UMN-B10		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T32UMN-AL14		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y32UMN-AL14		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y32UMN-B8		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF32UMN-AL6		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF32UMN-B8		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF32UMN-AL14		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF32UMN-AL14		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF32UMN-B8		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T32UMNJB10		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y32UMNJB10		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF32UMNJB10		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF32UMNJB10		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T32UMNJB30		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y32UMNJB30		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF32UMNJB30		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF32UMNJB30		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T32UMNJB50		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y32UMNJB50		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF32UMNJB50		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF32UMNJB50		Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-32UMS		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-32UMS-P		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T32UMS-A10		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T32UMS-B8		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T32UMS-B10		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T32UMS-AL14		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y32UMS-AL14		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y32UMS-B8		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF32UMS-AL6		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF32UMS-B8		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF32UMS-AL14		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF32UMS-AL14		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF32UMS-B8		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T32UMSJB10		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y32UMSJB10		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF32UMSJB10		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF32UMSJB10		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T32UMSJB30		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y32UMSJB30		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF32UMSJB30		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF32UMSJB30		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T32UMSJB50		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y32UMSJB50		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF32UMSJB50		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF32UMSJB50		Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-32UMU		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-32UMU-P		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T32UMU-A10		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T32UMU-B8		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T32UMU-B10		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T32UMU-AL14		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y32UMU-AL14		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y32UMU-B8		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF32UMU-AL6		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF32UMU-B8		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF32UMU-AL14		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF32UMU-AL14		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF32UMU-B8		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T32UMUJB10		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y32UMUJB10		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF32UMUJB10		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF32UMUJB10		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T32UMUJB30		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y32UMUJB30		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF32UMUJB30		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF32UMUJB30		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T32UMUJB50		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y32UMUJB50		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF32UMUJB50		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF32UMUJB50		Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-32UMF		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-32UMF-P		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T32UMF-A10		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T32UMF-B8		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T32UMF-B10		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T32UMF-AL14		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y32UMF-AL14		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y32UMF-B8		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF32UMF-AL6		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF32UMF-B8		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF32UMF-AL14		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF32UMF-AL14		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF32UMF-B8		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T32UMFJB10		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y32UMFJB10		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF32UMFJB10		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF32UMFJB10		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T32UMFJB30		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y32UMFJB30		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF32UMFJB30		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF32UMFJB30		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T32UMFJB50		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y32UMFJB50		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF32UMFJB50		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF32UMFJB50		Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-32UMCL		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-32UMCL-P		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T32UMCL-A10		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T32UMCL-B8		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T32UMCL-B10		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T32UMCL-AL14		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y32UMCL-AL14		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y32UMCL-B8		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF32UMCL-AL6		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF32UMCL-B8		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF32UMCL-AL14		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF32UMCL-AL14		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF32UMCL-B8		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T32UMCLJB10		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y32UMCLJB10		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF32UMCLJB10		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF32UMCLJB10		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T32UMCLJB30		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y32UMCLJB30		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF32UMCLJB30		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF32UMCLJB30		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T32UMCLJB50		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y32UMCLJB50		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF32UMCLJB50		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF32UMCLJB50		Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-40UMN		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-40UMN-P		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T40UMN-A10		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T40UMN-B8		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T40UMN-B10		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T40UMN-AL14		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y40UMN-AL14		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y40UMN-B8		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF40UMN-AL6		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF40UMN-B8		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF40UMN-AL14		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF40UMN-AL14		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF40UMN-B8		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T40UMNJB10		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y40UMNJB10		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF40UMNJB10		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF40UMNJB10		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T40UMNJB30		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y40UMNJB30		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF40UMNJB30		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF40UMNJB30		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T40UMNJB50		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y40UMNJB50		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF40UMNJB50		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF40UMNJB50		Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-40UMS		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-40UMS-P		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T40UMS-A10		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T40UMS-B8		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T40UMS-B10		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T40UMS-AL14		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y40UMS-AL14		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y40UMS-B8		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF40UMS-AL6		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF40UMS-B8		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF40UMS-AL14		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF40UMS-AL14		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF40UMS-B8		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T40UMSJB10		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y40UMSJB10		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF40UMSJB10		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF40UMSJB10		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T40UMSJB30		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y40UMSJB30		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF40UMSJB30		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF40UMSJB30		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T40UMSJB50		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y40UMSJB50		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF40UMSJB50		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF40UMSJB50		Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-40UMU		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-40UMU-P		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T40UMU-A10		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T40UMU-B8		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T40UMU-B10		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T40UMU-AL14		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y40UMU-AL14		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y40UMU-B8		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF40UMU-AL6		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF40UMU-B8		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF40UMU-AL14		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF40UMU-AL14		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF40UMU-B8		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T40UMUJB10		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y40UMUJB10		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF40UMUJB10		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF40UMUJB10		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T40UMUJB30		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y40UMUJB30		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF40UMUJB30		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF40UMUJB30		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T40UMUJB50		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y40UMUJB50		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF40UMUJB50		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF40UMUJB50		Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-40UMF		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-40UMF-P		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T40UMF-A10		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T40UMF-B8		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T40UMF-B10		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T40UMF-AL14		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y40UMF-AL14		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y40UMF-B8		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF40UMF-AL6		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF40UMF-B8		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF40UMF-AL14		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF40UMF-AL14		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF40UMF-B8		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T40UMFJB10		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y40UMFJB10		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF40UMFJB10		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF40UMFJB10		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T40UMFJB30		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y40UMFJB30		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF40UMFJB30		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF40UMFJB30		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T40UMFJB50		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y40UMFJB50		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF40UMFJB50		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF40UMFJB50		Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-40UMCL		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-40UMCL-P		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T40UMCL-A10		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T40UMCL-B8		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T40UMCL-B10		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T40UMCL-AL14		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y40UMCL-AL14		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y40UMCL-B8		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF40UMCL-AL6		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF40UMCL-B8		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF40UMCL-AL14		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF40UMCL-AL14		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF40UMCL-B8		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T40UMCLJB10		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y40UMCLJB10		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF40UMCLJB10		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF40UMCLJB10		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T40UMCLJB30		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y40UMCLJB30		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF40UMCLJB30		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF40UMCLJB30		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T40UMCLJB50		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y40UMCLJB50		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF40UMCLJB50		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF40UMCLJB50		Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-50UMN		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-50UMN-P		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T50UMN-A10		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T50UMN-B8		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T50UMN-B10		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T50UMN-AL14		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y50UMN-AL14		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y50UMN-B8		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF50UMN-AL6		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF50UMN-B8		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF50UMN-AL14		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF50UMN-AL14		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF50UMN-B8		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T50UMNJB10		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y50UMNJB10		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF50UMNJB10		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF50UMNJB10		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T50UMNJB30		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y50UMNJB30		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF50UMNJB30		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF50UMNJB30		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T50UMNJB50		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y50UMNJB50		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF50UMNJB50		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF50UMNJB50		Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-50UMS		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-50UMS-P		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T50UMS-A10		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T50UMS-B8		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T50UMS-B10		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T50UMS-AL14		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y50UMS-AL14		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y50UMS-B8		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF50UMS-AL6		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF50UMS-B8		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF50UMS-AL14		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF50UMS-AL14		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF50UMS-B8		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T50UMSJB10		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y50UMSJB10		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF50UMSJB10		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF50UMSJB10		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T50UMSJB30		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y50UMSJB30		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF50UMSJB30		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF50UMSJB30		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T50UMSJB50		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y50UMSJB50		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF50UMSJB50		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF50UMSJB50		Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-50UMU		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-50UMU-P		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T50UMU-A10		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T50UMU-B8		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T50UMU-B10		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T50UMU-AL14		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y50UMU-AL14		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y50UMU-B8		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF50UMU-AL6		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF50UMU-B8		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF50UMU-AL14		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF50UMU-AL14		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF50UMU-B8		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T50UMUJB10		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y50UMUJB10		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF50UMUJB10		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF50UMUJB10		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T50UMUJB30		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y50UMUJB30		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF50UMUJB30		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF50UMUJB30		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T50UMUJB50		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y50UMUJB50		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF50UMUJB50		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF50UMUJB50		Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-50UMF		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-50UMF-P		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T50UMF-A10		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T50UMF-B8		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T50UMF-B10		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T50UMF-AL14		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y50UMF-AL14		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y50UMF-B8		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF50UMF-AL6		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF50UMF-B8		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF50UMF-AL14		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF50UMF-AL14		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF50UMF-B8		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T50UMFJB10		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y50UMFJB10		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF50UMFJB10		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF50UMFJB10		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T50UMFJB30		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y50UMFJB30		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF50UMFJB30		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF50UMFJB30		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T50UMFJB50		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y50UMFJB50		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF50UMFJB50		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF50UMFJB50		Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-50UMCL		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-50UMCL-P		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T50UMCL-A10		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
ZP3E-T50UMCL-B8		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-T50UMCL-B10		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
ZP3E-T50UMCL-AL14		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y50UMCL-AL14		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-Y50UMCL-B8		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-TF50UMCL-AL6		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
ZP3E-TF50UMCL-B8		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
ZP3E-TF50UMCL-AL14		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF50UMCL-AL14		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
ZP3E-YF50UMCL-B8		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
ZP3E-T50UMCLJB10		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y50UMCLJB10		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF50UMCLJB10		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF50UMCLJB10		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T50UMCLJB30		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y50UMCLJB30		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF50UMCLJB30		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF50UMCLJB30		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T50UMCLJB50		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y50UMCLJB50		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF50UMCLJB50		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF50UMCLJB50		Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-63UMN		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-63UMN-P		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T63UMN-A16		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T63UMN-B12		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T63UMN-B18		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T63UMN-AL16		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMN-AL16		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMN-B12		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF63UMN-AL12		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF63UMN-B12		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF63UMN-AL16		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMN-AL16		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMN-B12		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T63UMNJB10		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y63UMNJB10		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF63UMNJB10		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF63UMNJB10		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T63UMNJB30		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y63UMNJB30		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF63UMNJB30		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF63UMNJB30		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T63UMNJB50		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y63UMNJB50		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF63UMNJB50		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF63UMNJB50		Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-63UMS		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-63UMS-P		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T63UMS-A16		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T63UMS-B12		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T63UMS-B18		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T63UMS-AL16		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMS-AL16		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMS-B12		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF63UMS-AL12		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF63UMS-B12		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF63UMS-AL16		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMS-AL16		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMS-B12		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T63UMSJB10		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y63UMSJB10		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF63UMSJB10		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF63UMSJB10		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T63UMSJB30		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y63UMSJB30		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF63UMSJB30		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF63UMSJB30		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T63UMSJB50		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y63UMSJB50		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF63UMSJB50		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF63UMSJB50		Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-63UMU		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-63UMU-P		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T63UMU-A16		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T63UMU-B12		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T63UMU-B18		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T63UMU-AL16		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMU-AL16		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMU-B12		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF63UMU-AL12		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF63UMU-B12		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF63UMU-AL16		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMU-AL16		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMU-B12		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T63UMUJB10		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y63UMUJB10		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF63UMUJB10		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF63UMUJB10		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T63UMUJB30		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y63UMUJB30		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF63UMUJB30		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF63UMUJB30		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T63UMUJB50		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y63UMUJB50		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF63UMUJB50		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF63UMUJB50		Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-63UMF		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-63UMF-P		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T63UMF-A16		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T63UMF-B12		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T63UMF-B18		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T63UMF-AL16		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMF-AL16		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMF-B12		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF63UMF-AL12		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF63UMF-B12		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF63UMF-AL16		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMF-AL16		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMF-B12		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T63UMFJB10		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y63UMFJB10		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF63UMFJB10		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF63UMFJB10		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T63UMFJB30		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y63UMFJB30		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF63UMFJB30		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF63UMFJB30		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T63UMFJB50		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y63UMFJB50		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF63UMFJB50		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF63UMFJB50		Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-63UMCL		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-63UMCL-P		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T63UMCL-A16		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T63UMCL-B12		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T63UMCL-B18		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T63UMCL-AL16		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMCL-AL16		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y63UMCL-B12		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF63UMCL-AL12		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF63UMCL-B12		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF63UMCL-AL16		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMCL-AL16		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF63UMCL-B12		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T63UMCLJB10		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y63UMCLJB10		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF63UMCLJB10		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF63UMCLJB10		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T63UMCLJB30		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y63UMCLJB30		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF63UMCLJB30		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF63UMCLJB30		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T63UMCLJB50		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y63UMCLJB50		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF63UMCLJB50		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF63UMCLJB50		Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-80UMN		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-80UMN-P		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T80UMN-A16		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T80UMN-B12		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T80UMN-B18		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T80UMN-AL16		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMN-AL16		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMN-B12		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF80UMN-AL12		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF80UMN-B12		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF80UMN-AL16		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMN-AL16		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMN-B12		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T80UMNJB10		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y80UMNJB10		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF80UMNJB10		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF80UMNJB10		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T80UMNJB30		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y80UMNJB30		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF80UMNJB30		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF80UMNJB30		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T80UMNJB50		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y80UMNJB50		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF80UMNJB50		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF80UMNJB50		Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-80UMS		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-80UMS-P		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T80UMS-A16		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T80UMS-B12		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T80UMS-B18		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T80UMS-AL16		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMS-AL16		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMS-B12		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF80UMS-AL12		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF80UMS-B12		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF80UMS-AL16		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMS-AL16		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMS-B12		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T80UMSJB10		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y80UMSJB10		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF80UMSJB10		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF80UMSJB10		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T80UMSJB30		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y80UMSJB30		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF80UMSJB30		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF80UMSJB30		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T80UMSJB50		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y80UMSJB50		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF80UMSJB50		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF80UMSJB50		Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-80UMU		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-80UMU-P		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T80UMU-A16		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T80UMU-B12		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T80UMU-B18		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T80UMU-AL16		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMU-AL16		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMU-B12		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF80UMU-AL12		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF80UMU-B12		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF80UMU-AL16		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMU-AL16		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMU-B12		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T80UMUJB10		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y80UMUJB10		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF80UMUJB10		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF80UMUJB10		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T80UMUJB30		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y80UMUJB30		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF80UMUJB30		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF80UMUJB30		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T80UMUJB50		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y80UMUJB50		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF80UMUJB50		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF80UMUJB50		Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-80UMF		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-80UMF-P		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T80UMF-A16		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T80UMF-B12		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T80UMF-B18		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T80UMF-AL16		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMF-AL16		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMF-B12		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF80UMF-AL12		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF80UMF-B12		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF80UMF-AL16		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMF-AL16		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMF-B12		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T80UMFJB10		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y80UMFJB10		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF80UMFJB10		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF80UMFJB10		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T80UMFJB30		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y80UMFJB30		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF80UMFJB30		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF80UMFJB30		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T80UMFJB50		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y80UMFJB50		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF80UMFJB50		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF80UMFJB50		Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-80UMCL		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-80UMCL-P		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T80UMCL-A16		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T80UMCL-B12		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T80UMCL-B18		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T80UMCL-AL16		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMCL-AL16		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y80UMCL-B12		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF80UMCL-AL12		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF80UMCL-B12		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF80UMCL-AL16		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMCL-AL16		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF80UMCL-B12		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T80UMCLJB10		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y80UMCLJB10		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF80UMCLJB10		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF80UMCLJB10		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T80UMCLJB30		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y80UMCLJB30		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF80UMCLJB30		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF80UMCLJB30		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T80UMCLJB50		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y80UMCLJB50		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF80UMCLJB50		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF80UMCLJB50		Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-100UMN		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-100UMN-P		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T100UMN-A16		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T100UMN-B12		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T100UMN-B18		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T100UMN-AL16		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMN-AL16		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMN-B12		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF100UMN-AL12		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF100UMN-B12		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF100UMN-AL16		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMN-AL16		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMN-B12		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T100UMNJB10		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y100UMNJB10		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF100UMNJB10		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF100UMNJB10		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T100UMNJB30		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y100UMNJB30		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF100UMNJB30		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF100UMNJB30		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T100UMNJB50		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y100UMNJB50		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF100UMNJB50		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF100UMNJB50		Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-100UMS		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-100UMS-P		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T100UMS-A16		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T100UMS-B12		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T100UMS-B18		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T100UMS-AL16		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMS-AL16		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMS-B12		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF100UMS-AL12		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF100UMS-B12		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF100UMS-AL16		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMS-AL16		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMS-B12		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T100UMSJB10		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y100UMSJB10		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF100UMSJB10		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF100UMSJB10		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T100UMSJB30		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y100UMSJB30		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF100UMSJB30		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF100UMSJB30		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T100UMSJB50		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y100UMSJB50		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF100UMSJB50		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF100UMSJB50		Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-100UMU		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-100UMU-P		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T100UMU-A16		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T100UMU-B12		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T100UMU-B18		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T100UMU-AL16		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMU-AL16		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMU-B12		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF100UMU-AL12		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF100UMU-B12		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF100UMU-AL16		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMU-AL16		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMU-B12		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T100UMUJB10		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y100UMUJB10		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF100UMUJB10		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF100UMUJB10		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T100UMUJB30		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y100UMUJB30		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF100UMUJB30		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF100UMUJB30		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T100UMUJB50		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y100UMUJB50		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF100UMUJB50		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF100UMUJB50		Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-100UMF		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-100UMF-P		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T100UMF-A16		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T100UMF-B12		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T100UMF-B18		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T100UMF-AL16		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMF-AL16		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMF-B12		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF100UMF-AL12		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF100UMF-B12		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF100UMF-AL16		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMF-AL16		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMF-B12		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T100UMFJB10		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y100UMFJB10		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF100UMFJB10		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF100UMFJB10		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T100UMFJB30		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y100UMFJB30		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF100UMFJB30		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF100UMFJB30		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T100UMFJB50		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y100UMFJB50		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF100UMFJB50		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF100UMFJB50		Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-100UMCL		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-100UMCL-P		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T100UMCL-A16		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T100UMCL-B12		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T100UMCL-B18		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T100UMCL-AL16		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMCL-AL16		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y100UMCL-B12		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF100UMCL-AL12		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF100UMCL-B12		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF100UMCL-AL16		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMCL-AL16		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF100UMCL-B12		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T100UMCLJB10		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y100UMCLJB10		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF100UMCLJB10		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF100UMCLJB10		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T100UMCLJB30		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y100UMCLJB30		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF100UMCLJB30		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF100UMCLJB30		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T100UMCLJB50		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y100UMCLJB50		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF100UMCLJB50		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF100UMCLJB50		Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-125UMN		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-125UMN-P		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T125UMN-A16		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T125UMN-B12		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T125UMN-B18		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T125UMN-AL16		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMN-AL16		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMN-B12		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF125UMN-AL12		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF125UMN-B12		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF125UMN-AL16		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMN-AL16		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMN-B12		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T125UMNJB10		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y125UMNJB10		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF125UMNJB10		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF125UMNJB10		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T125UMNJB30		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y125UMNJB30		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF125UMNJB30		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF125UMNJB30		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T125UMNJB50		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y125UMNJB50		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF125UMNJB50		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF125UMNJB50		Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-125UMS		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-125UMS-P		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T125UMS-A16		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T125UMS-B12		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T125UMS-B18		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T125UMS-AL16		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMS-AL16		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMS-B12		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF125UMS-AL12		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF125UMS-B12		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF125UMS-AL16		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMS-AL16		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMS-B12		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T125UMSJB10		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y125UMSJB10		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF125UMSJB10		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF125UMSJB10		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T125UMSJB30		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y125UMSJB30		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF125UMSJB30		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF125UMSJB30		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T125UMSJB50		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y125UMSJB50		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF125UMSJB50		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF125UMSJB50		Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-125UMU		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-125UMU-P		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T125UMU-A16		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T125UMU-B12		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T125UMU-B18		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T125UMU-AL16		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMU-AL16		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMU-B12		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF125UMU-AL12		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF125UMU-B12		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF125UMU-AL16		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMU-AL16		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMU-B12		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T125UMUJB10		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y125UMUJB10		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF125UMUJB10		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF125UMUJB10		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T125UMUJB30		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y125UMUJB30		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF125UMUJB30		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF125UMUJB30		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T125UMUJB50		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y125UMUJB50		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF125UMUJB50		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF125UMUJB50		Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-125UMF		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-125UMF-P		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T125UMF-A16		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T125UMF-B12		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T125UMF-B18		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T125UMF-AL16		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMF-AL16		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMF-B12		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF125UMF-AL12		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF125UMF-B12		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF125UMF-AL16		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMF-AL16		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMF-B12		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T125UMFJB10		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y125UMFJB10		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF125UMFJB10		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF125UMFJB10		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T125UMFJB30		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y125UMFJB30		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF125UMFJB30		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF125UMFJB30		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T125UMFJB50		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y125UMFJB50		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF125UMFJB50		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF125UMFJB50		Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-125UMCL		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
ZP3E-125UMCL-P		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
ZP3E-T125UMCL-A16		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
ZP3E-T125UMCL-B12		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-T125UMCL-B18		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
ZP3E-T125UMCL-AL16		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMCL-AL16		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-Y125UMCL-B12		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-TF125UMCL-AL12		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
ZP3E-TF125UMCL-B12		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
ZP3E-TF125UMCL-AL16		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMCL-AL16		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-YF125UMCL-B12		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
ZP3E-T125UMCLJB10		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-Y125UMCLJB10		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-TF125UMCLJB10		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-YF125UMCLJB10		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
ZP3E-T125UMCLJB30		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-Y125UMCLJB30		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-TF125UMCLJB30		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-YF125UMCLJB30		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
ZP3E-T125UMCLJB50		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-Y125UMCLJB50		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-TF125UMCLJB50		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
ZP3E-YF125UMCLJB50		Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm

Vacuum PadsSMC

875 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ZP3E High-Rigidity Vacuum Pad (Flat with Groove, ø32-125)

Brand SMC·Vacuum Pads

Available part numbers (875)

ZP3E-32UMN, ZP3E-32UMN-P, ZP3E-T32UMN-A10, ZP3E-T32UMN-B8, ZP3E-T32UMN-B10, ZP3E-T32UMN-AL14, ZP3E-Y32UMN-AL14, ZP3E-Y32UMN-B8, ZP3E-TF32UMN-AL6, ZP3E-TF32UMN-B8 + 865 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	ZP3E-32UMN	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-32UMN-P	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T32UMN-A10	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T32UMN-B8	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T32UMN-B10	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T32UMN-AL14	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y32UMN-AL14	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y32UMN-B8	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF32UMN-AL6	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF32UMN-B8	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF32UMN-AL14	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF32UMN-AL14	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF32UMN-B8	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T32UMNJB10	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y32UMNJB10	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF32UMNJB10	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF32UMNJB10	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T32UMNJB30	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y32UMNJB30	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF32UMNJB30	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF32UMNJB30	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T32UMNJB50	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y32UMNJB50	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF32UMNJB50	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF32UMNJB50	Pad diameter: ø32 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-32UMS	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-32UMS-P	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T32UMS-A10	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T32UMS-B8	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T32UMS-B10	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T32UMS-AL14	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y32UMS-AL14	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y32UMS-B8	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF32UMS-AL6	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF32UMS-B8	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF32UMS-AL14	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF32UMS-AL14	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF32UMS-B8	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T32UMSJB10	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y32UMSJB10	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF32UMSJB10	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF32UMSJB10	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T32UMSJB30	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y32UMSJB30	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF32UMSJB30	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF32UMSJB30	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T32UMSJB50	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y32UMSJB50	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF32UMSJB50	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF32UMSJB50	Pad diameter: ø32 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-32UMU	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-32UMU-P	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T32UMU-A10	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T32UMU-B8	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T32UMU-B10	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T32UMU-AL14	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y32UMU-AL14	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y32UMU-B8	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF32UMU-AL6	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF32UMU-B8	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF32UMU-AL14	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF32UMU-AL14	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF32UMU-B8	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T32UMUJB10	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y32UMUJB10	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF32UMUJB10	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF32UMUJB10	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T32UMUJB30	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y32UMUJB30	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF32UMUJB30	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF32UMUJB30	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T32UMUJB50	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y32UMUJB50	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF32UMUJB50	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF32UMUJB50	Pad diameter: ø32 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-32UMF	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-32UMF-P	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T32UMF-A10	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T32UMF-B8	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T32UMF-B10	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T32UMF-AL14	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y32UMF-AL14	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y32UMF-B8	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF32UMF-AL6	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF32UMF-B8	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF32UMF-AL14	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF32UMF-AL14	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF32UMF-B8	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T32UMFJB10	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y32UMFJB10	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF32UMFJB10	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF32UMFJB10	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T32UMFJB30	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y32UMFJB30	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF32UMFJB30	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF32UMFJB30	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T32UMFJB50	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y32UMFJB50	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF32UMFJB50	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF32UMFJB50	Pad diameter: ø32 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-32UMCL	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-32UMCL-P	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T32UMCL-A10	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T32UMCL-B8	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T32UMCL-B10	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T32UMCL-AL14	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y32UMCL-AL14	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y32UMCL-B8	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF32UMCL-AL6	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF32UMCL-B8	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF32UMCL-AL14	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF32UMCL-AL14	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF32UMCL-B8	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T32UMCLJB10	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y32UMCLJB10	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF32UMCLJB10	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF32UMCLJB10	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T32UMCLJB30	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y32UMCLJB30	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF32UMCLJB30	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF32UMCLJB30	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T32UMCLJB50	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y32UMCLJB50	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF32UMCLJB50	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF32UMCLJB50	Pad diameter: ø32 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-40UMN	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-40UMN-P	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T40UMN-A10	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T40UMN-B8	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T40UMN-B10	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T40UMN-AL14	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y40UMN-AL14	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y40UMN-B8	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF40UMN-AL6	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF40UMN-B8	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF40UMN-AL14	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF40UMN-AL14	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF40UMN-B8	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T40UMNJB10	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y40UMNJB10	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF40UMNJB10	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF40UMNJB10	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T40UMNJB30	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y40UMNJB30	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF40UMNJB30	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF40UMNJB30	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T40UMNJB50	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y40UMNJB50	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF40UMNJB50	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF40UMNJB50	Pad diameter: ø40 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-40UMS	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-40UMS-P	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T40UMS-A10	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T40UMS-B8	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T40UMS-B10	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T40UMS-AL14	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y40UMS-AL14	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y40UMS-B8	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF40UMS-AL6	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF40UMS-B8	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF40UMS-AL14	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF40UMS-AL14	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF40UMS-B8	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T40UMSJB10	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y40UMSJB10	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF40UMSJB10	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF40UMSJB10	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T40UMSJB30	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y40UMSJB30	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF40UMSJB30	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF40UMSJB30	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T40UMSJB50	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y40UMSJB50	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF40UMSJB50	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF40UMSJB50	Pad diameter: ø40 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-40UMU	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-40UMU-P	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T40UMU-A10	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T40UMU-B8	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T40UMU-B10	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T40UMU-AL14	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y40UMU-AL14	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y40UMU-B8	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF40UMU-AL6	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF40UMU-B8	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF40UMU-AL14	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF40UMU-AL14	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF40UMU-B8	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T40UMUJB10	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y40UMUJB10	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF40UMUJB10	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF40UMUJB10	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T40UMUJB30	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y40UMUJB30	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF40UMUJB30	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF40UMUJB30	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T40UMUJB50	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y40UMUJB50	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF40UMUJB50	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF40UMUJB50	Pad diameter: ø40 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-40UMF	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-40UMF-P	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T40UMF-A10	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T40UMF-B8	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T40UMF-B10	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T40UMF-AL14	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y40UMF-AL14	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y40UMF-B8	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF40UMF-AL6	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF40UMF-B8	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF40UMF-AL14	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF40UMF-AL14	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF40UMF-B8	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T40UMFJB10	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y40UMFJB10	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF40UMFJB10	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF40UMFJB10	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T40UMFJB30	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y40UMFJB30	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF40UMFJB30	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF40UMFJB30	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T40UMFJB50	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y40UMFJB50	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF40UMFJB50	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF40UMFJB50	Pad diameter: ø40 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-40UMCL	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-40UMCL-P	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T40UMCL-A10	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T40UMCL-B8	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T40UMCL-B10	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T40UMCL-AL14	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y40UMCL-AL14	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y40UMCL-B8	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF40UMCL-AL6	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF40UMCL-B8	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF40UMCL-AL14	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF40UMCL-AL14	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF40UMCL-B8	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T40UMCLJB10	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y40UMCLJB10	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF40UMCLJB10	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF40UMCLJB10	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T40UMCLJB30	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y40UMCLJB30	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF40UMCLJB30	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF40UMCLJB30	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T40UMCLJB50	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y40UMCLJB50	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF40UMCLJB50	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF40UMCLJB50	Pad diameter: ø40 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-50UMN	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-50UMN-P	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T50UMN-A10	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T50UMN-B8	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T50UMN-B10	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T50UMN-AL14	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y50UMN-AL14	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y50UMN-B8	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF50UMN-AL6	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF50UMN-B8	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF50UMN-AL14	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF50UMN-AL14	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF50UMN-B8	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T50UMNJB10	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y50UMNJB10	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF50UMNJB10	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF50UMNJB10	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T50UMNJB30	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y50UMNJB30	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF50UMNJB30	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF50UMNJB30	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T50UMNJB50	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y50UMNJB50	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF50UMNJB50	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF50UMNJB50	Pad diameter: ø50 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-50UMS	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-50UMS-P	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T50UMS-A10	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T50UMS-B8	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T50UMS-B10	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T50UMS-AL14	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y50UMS-AL14	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y50UMS-B8	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF50UMS-AL6	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF50UMS-B8	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF50UMS-AL14	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF50UMS-AL14	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF50UMS-B8	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T50UMSJB10	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y50UMSJB10	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF50UMSJB10	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF50UMSJB10	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T50UMSJB30	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y50UMSJB30	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF50UMSJB30	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF50UMSJB30	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T50UMSJB50	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y50UMSJB50	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF50UMSJB50	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF50UMSJB50	Pad diameter: ø50 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-50UMU	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-50UMU-P	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T50UMU-A10	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T50UMU-B8	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T50UMU-B10	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T50UMU-AL14	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y50UMU-AL14	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y50UMU-B8	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF50UMU-AL6	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF50UMU-B8	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF50UMU-AL14	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF50UMU-AL14	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF50UMU-B8	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T50UMUJB10	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y50UMUJB10	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF50UMUJB10	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF50UMUJB10	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T50UMUJB30	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y50UMUJB30	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF50UMUJB30	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF50UMUJB30	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T50UMUJB50	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y50UMUJB50	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF50UMUJB50	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF50UMUJB50	Pad diameter: ø50 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-50UMF	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-50UMF-P	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T50UMF-A10	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T50UMF-B8	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T50UMF-B10	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T50UMF-AL14	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y50UMF-AL14	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y50UMF-B8	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF50UMF-AL6	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF50UMF-B8	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF50UMF-AL14	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF50UMF-AL14	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF50UMF-B8	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T50UMFJB10	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y50UMFJB10	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF50UMFJB10	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF50UMFJB10	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T50UMFJB30	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y50UMFJB30	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF50UMFJB30	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF50UMFJB30	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T50UMFJB50	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y50UMFJB50	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF50UMFJB50	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF50UMFJB50	Pad diameter: ø50 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-50UMCL	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-50UMCL-P	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T50UMCL-A10	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1 male, port shared \| Buffer stroke: None
	ZP3E-T50UMCL-B8	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-T50UMCL-B10	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M10x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T50UMCL-AL14	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y50UMCL-AL14	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-Y50UMCL-B8	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-TF50UMCL-AL6	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M6x1 male, port shared \| Buffer stroke: None
	ZP3E-TF50UMCL-B8	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M8x1.25 female, port shared \| Buffer stroke: None
	ZP3E-TF50UMCL-AL14	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M14x1 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF50UMCL-AL14	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M14x1 male, vac. port M5 \| Buffer stroke: None
	ZP3E-YF50UMCL-B8	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M8x1.25 female, vac. port M5 \| Buffer stroke: None
	ZP3E-T50UMCLJB10	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y50UMCLJB10	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF50UMCLJB10	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF50UMCLJB10	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T50UMCLJB30	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y50UMCLJB30	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF50UMCLJB30	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF50UMCLJB30	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T50UMCLJB50	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y50UMCLJB50	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF50UMCLJB50	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF50UMCLJB50	Pad diameter: ø50 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M18x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-63UMN	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-63UMN-P	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T63UMN-A16	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T63UMN-B12	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T63UMN-B18	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T63UMN-AL16	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMN-AL16	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMN-B12	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF63UMN-AL12	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF63UMN-B12	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF63UMN-AL16	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMN-AL16	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMN-B12	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T63UMNJB10	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y63UMNJB10	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF63UMNJB10	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF63UMNJB10	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T63UMNJB30	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y63UMNJB30	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF63UMNJB30	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF63UMNJB30	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T63UMNJB50	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y63UMNJB50	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF63UMNJB50	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF63UMNJB50	Pad diameter: ø63 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-63UMS	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-63UMS-P	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T63UMS-A16	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T63UMS-B12	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T63UMS-B18	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T63UMS-AL16	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMS-AL16	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMS-B12	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF63UMS-AL12	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF63UMS-B12	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF63UMS-AL16	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMS-AL16	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMS-B12	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T63UMSJB10	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y63UMSJB10	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF63UMSJB10	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF63UMSJB10	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T63UMSJB30	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y63UMSJB30	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF63UMSJB30	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF63UMSJB30	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T63UMSJB50	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y63UMSJB50	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF63UMSJB50	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF63UMSJB50	Pad diameter: ø63 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-63UMU	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-63UMU-P	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T63UMU-A16	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T63UMU-B12	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T63UMU-B18	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T63UMU-AL16	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMU-AL16	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMU-B12	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF63UMU-AL12	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF63UMU-B12	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF63UMU-AL16	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMU-AL16	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMU-B12	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T63UMUJB10	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y63UMUJB10	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF63UMUJB10	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF63UMUJB10	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T63UMUJB30	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y63UMUJB30	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF63UMUJB30	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF63UMUJB30	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T63UMUJB50	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y63UMUJB50	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF63UMUJB50	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF63UMUJB50	Pad diameter: ø63 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-63UMF	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-63UMF-P	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T63UMF-A16	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T63UMF-B12	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T63UMF-B18	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T63UMF-AL16	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMF-AL16	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMF-B12	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF63UMF-AL12	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF63UMF-B12	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF63UMF-AL16	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMF-AL16	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMF-B12	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T63UMFJB10	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y63UMFJB10	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF63UMFJB10	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF63UMFJB10	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T63UMFJB30	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y63UMFJB30	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF63UMFJB30	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF63UMFJB30	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T63UMFJB50	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y63UMFJB50	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF63UMFJB50	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF63UMFJB50	Pad diameter: ø63 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-63UMCL	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-63UMCL-P	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T63UMCL-A16	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T63UMCL-B12	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T63UMCL-B18	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T63UMCL-AL16	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMCL-AL16	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y63UMCL-B12	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF63UMCL-AL12	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF63UMCL-B12	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF63UMCL-AL16	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMCL-AL16	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF63UMCL-B12	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T63UMCLJB10	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y63UMCLJB10	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF63UMCLJB10	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF63UMCLJB10	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T63UMCLJB30	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y63UMCLJB30	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF63UMCLJB30	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF63UMCLJB30	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T63UMCLJB50	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y63UMCLJB50	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF63UMCLJB50	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF63UMCLJB50	Pad diameter: ø63 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-80UMN	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-80UMN-P	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T80UMN-A16	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T80UMN-B12	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T80UMN-B18	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T80UMN-AL16	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMN-AL16	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMN-B12	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF80UMN-AL12	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF80UMN-B12	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF80UMN-AL16	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMN-AL16	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMN-B12	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T80UMNJB10	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y80UMNJB10	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF80UMNJB10	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF80UMNJB10	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T80UMNJB30	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y80UMNJB30	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF80UMNJB30	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF80UMNJB30	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T80UMNJB50	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y80UMNJB50	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF80UMNJB50	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF80UMNJB50	Pad diameter: ø80 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-80UMS	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-80UMS-P	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T80UMS-A16	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T80UMS-B12	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T80UMS-B18	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T80UMS-AL16	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMS-AL16	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMS-B12	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF80UMS-AL12	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF80UMS-B12	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF80UMS-AL16	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMS-AL16	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMS-B12	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T80UMSJB10	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y80UMSJB10	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF80UMSJB10	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF80UMSJB10	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T80UMSJB30	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y80UMSJB30	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF80UMSJB30	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF80UMSJB30	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T80UMSJB50	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y80UMSJB50	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF80UMSJB50	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF80UMSJB50	Pad diameter: ø80 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-80UMU	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-80UMU-P	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T80UMU-A16	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T80UMU-B12	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T80UMU-B18	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T80UMU-AL16	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMU-AL16	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMU-B12	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF80UMU-AL12	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF80UMU-B12	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF80UMU-AL16	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMU-AL16	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMU-B12	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T80UMUJB10	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y80UMUJB10	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF80UMUJB10	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF80UMUJB10	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T80UMUJB30	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y80UMUJB30	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF80UMUJB30	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF80UMUJB30	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T80UMUJB50	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y80UMUJB50	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF80UMUJB50	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF80UMUJB50	Pad diameter: ø80 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-80UMF	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-80UMF-P	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T80UMF-A16	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T80UMF-B12	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T80UMF-B18	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T80UMF-AL16	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMF-AL16	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMF-B12	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF80UMF-AL12	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF80UMF-B12	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF80UMF-AL16	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMF-AL16	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMF-B12	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T80UMFJB10	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y80UMFJB10	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF80UMFJB10	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF80UMFJB10	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T80UMFJB30	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y80UMFJB30	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF80UMFJB30	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF80UMFJB30	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T80UMFJB50	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y80UMFJB50	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF80UMFJB50	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF80UMFJB50	Pad diameter: ø80 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-80UMCL	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-80UMCL-P	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T80UMCL-A16	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T80UMCL-B12	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T80UMCL-B18	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T80UMCL-AL16	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMCL-AL16	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y80UMCL-B12	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF80UMCL-AL12	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF80UMCL-B12	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF80UMCL-AL16	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMCL-AL16	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF80UMCL-B12	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T80UMCLJB10	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y80UMCLJB10	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF80UMCLJB10	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF80UMCLJB10	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T80UMCLJB30	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y80UMCLJB30	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF80UMCLJB30	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF80UMCLJB30	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T80UMCLJB50	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y80UMCLJB50	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF80UMCLJB50	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF80UMCLJB50	Pad diameter: ø80 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-100UMN	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-100UMN-P	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T100UMN-A16	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T100UMN-B12	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T100UMN-B18	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T100UMN-AL16	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMN-AL16	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMN-B12	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF100UMN-AL12	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF100UMN-B12	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF100UMN-AL16	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMN-AL16	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMN-B12	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T100UMNJB10	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y100UMNJB10	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF100UMNJB10	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF100UMNJB10	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T100UMNJB30	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y100UMNJB30	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF100UMNJB30	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF100UMNJB30	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T100UMNJB50	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y100UMNJB50	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF100UMNJB50	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF100UMNJB50	Pad diameter: ø100 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-100UMS	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-100UMS-P	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T100UMS-A16	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T100UMS-B12	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T100UMS-B18	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T100UMS-AL16	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMS-AL16	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMS-B12	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF100UMS-AL12	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF100UMS-B12	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF100UMS-AL16	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMS-AL16	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMS-B12	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T100UMSJB10	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y100UMSJB10	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF100UMSJB10	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF100UMSJB10	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T100UMSJB30	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y100UMSJB30	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF100UMSJB30	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF100UMSJB30	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T100UMSJB50	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y100UMSJB50	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF100UMSJB50	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF100UMSJB50	Pad diameter: ø100 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-100UMU	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-100UMU-P	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T100UMU-A16	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T100UMU-B12	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T100UMU-B18	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T100UMU-AL16	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMU-AL16	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMU-B12	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF100UMU-AL12	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF100UMU-B12	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF100UMU-AL16	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMU-AL16	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMU-B12	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T100UMUJB10	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y100UMUJB10	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF100UMUJB10	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF100UMUJB10	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T100UMUJB30	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y100UMUJB30	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF100UMUJB30	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF100UMUJB30	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T100UMUJB50	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y100UMUJB50	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF100UMUJB50	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF100UMUJB50	Pad diameter: ø100 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-100UMF	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-100UMF-P	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T100UMF-A16	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T100UMF-B12	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T100UMF-B18	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T100UMF-AL16	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMF-AL16	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMF-B12	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF100UMF-AL12	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF100UMF-B12	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF100UMF-AL16	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMF-AL16	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMF-B12	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T100UMFJB10	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y100UMFJB10	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF100UMFJB10	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF100UMFJB10	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T100UMFJB30	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y100UMFJB30	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF100UMFJB30	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF100UMFJB30	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T100UMFJB50	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y100UMFJB50	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF100UMFJB50	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF100UMFJB50	Pad diameter: ø100 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-100UMCL	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-100UMCL-P	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T100UMCL-A16	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T100UMCL-B12	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T100UMCL-B18	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T100UMCL-AL16	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMCL-AL16	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y100UMCL-B12	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF100UMCL-AL12	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF100UMCL-B12	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF100UMCL-AL16	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMCL-AL16	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF100UMCL-B12	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T100UMCLJB10	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y100UMCLJB10	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF100UMCLJB10	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF100UMCLJB10	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T100UMCLJB30	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y100UMCLJB30	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF100UMCLJB30	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF100UMCLJB30	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T100UMCLJB50	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y100UMCLJB50	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF100UMCLJB50	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF100UMCLJB50	Pad diameter: ø100 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-125UMN	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-125UMN-P	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T125UMN-A16	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T125UMN-B12	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T125UMN-B18	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T125UMN-AL16	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMN-AL16	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMN-B12	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF125UMN-AL12	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF125UMN-B12	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF125UMN-AL16	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMN-AL16	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMN-B12	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T125UMNJB10	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y125UMNJB10	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF125UMNJB10	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF125UMNJB10	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T125UMNJB30	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y125UMNJB30	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF125UMNJB30	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF125UMNJB30	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T125UMNJB50	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y125UMNJB50	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF125UMNJB50	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF125UMNJB50	Pad diameter: ø125 \| Pad material: NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-125UMS	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-125UMS-P	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T125UMS-A16	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T125UMS-B12	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T125UMS-B18	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T125UMS-AL16	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMS-AL16	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMS-B12	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF125UMS-AL12	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF125UMS-B12	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF125UMS-AL16	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMS-AL16	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMS-B12	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T125UMSJB10	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y125UMSJB10	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF125UMSJB10	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF125UMSJB10	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T125UMSJB30	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y125UMSJB30	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF125UMSJB30	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF125UMSJB30	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T125UMSJB50	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y125UMSJB50	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF125UMSJB50	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF125UMSJB50	Pad diameter: ø125 \| Pad material: Silicone rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-125UMU	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-125UMU-P	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T125UMU-A16	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T125UMU-B12	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T125UMU-B18	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T125UMU-AL16	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMU-AL16	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMU-B12	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF125UMU-AL12	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF125UMU-B12	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF125UMU-AL16	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMU-AL16	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMU-B12	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T125UMUJB10	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y125UMUJB10	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF125UMUJB10	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF125UMUJB10	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T125UMUJB30	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y125UMUJB30	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF125UMUJB30	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF125UMUJB30	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T125UMUJB50	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y125UMUJB50	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF125UMUJB50	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF125UMUJB50	Pad diameter: ø125 \| Pad material: Urethane rubber \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-125UMF	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-125UMF-P	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T125UMF-A16	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T125UMF-B12	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T125UMF-B18	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T125UMF-AL16	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMF-AL16	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMF-B12	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF125UMF-AL12	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF125UMF-B12	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF125UMF-AL16	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMF-AL16	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMF-B12	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T125UMFJB10	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y125UMFJB10	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF125UMFJB10	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF125UMFJB10	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T125UMFJB30	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y125UMFJB30	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF125UMFJB30	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF125UMFJB30	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T125UMFJB50	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y125UMFJB50	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF125UMFJB50	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF125UMFJB50	Pad diameter: ø125 \| Pad material: FKM \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-125UMCL	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad only \| Connection: None \| Buffer stroke: None
	ZP3E-125UMCL-P	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Pad with plate (P) \| Connection: None \| Buffer stroke: None
	ZP3E-T125UMCL-A16	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, port shared \| Buffer stroke: None
	ZP3E-T125UMCL-B12	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-T125UMCL-B18	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M18x1.5 female, port shared \| Buffer stroke: None
	ZP3E-T125UMCL-AL16	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, vertical (T) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMCL-AL16	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-Y125UMCL-B12	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Adapter, lateral (Y) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-TF125UMCL-AL12	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.25 male, port shared \| Buffer stroke: None
	ZP3E-TF125UMCL-B12	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M12x1.75 female, port shared \| Buffer stroke: None
	ZP3E-TF125UMCL-AL16	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, vertical (TF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMCL-AL16	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M16x1.5 male, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-YF125UMCL-B12	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint adapter, lateral (YF) \| Connection: M12x1.75 female, vac. port Rc1/8 \| Buffer stroke: None
	ZP3E-T125UMCLJB10	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-Y125UMCLJB10	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-TF125UMCLJB10	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-YF125UMCLJB10	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 10 mm
	ZP3E-T125UMCLJB30	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-Y125UMCLJB30	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-TF125UMCLJB30	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-YF125UMCLJB30	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 30 mm
	ZP3E-T125UMCLJB50	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, vertical (T) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-Y125UMCLJB50	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Buffer, lateral (Y) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-TF125UMCLJB50	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, vertical (TF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm
	ZP3E-YF125UMCLJB50	Pad diameter: ø125 \| Pad material: Anti-pad-mark NBR \| Mounting: Ball joint buffer, lateral (YF) \| Connection: M22x1.5 male (buffer) \| Buffer stroke: 50 mm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

SMC ZP3E High-Rigidity Vacuum Pad (Flat with Groove, ø32-125)
