SMC ZXP7 Vacuum Gripper for FANUC CRX Series

SMC ZXP7 Vacuum Gripper for FANUC CRX Series

SMC ZXP7 plug-and-play all-in-one vacuum gripper for FANUC CRX series collaborative robots, integrating ejector, supply and release valves, pressure sensor and pads.

Key features

  • Works by connecting one compressed air tube and the M8 robot connector only
  • Integrated vacuum ejector, air supply and release valves, compact pressure sensor and pads
  • Pad options: ZP flat, ribbed, bellows, thin flat and multi-stage bellows ø8 to ø32 in NBR, silicone, urethane or FKM, plus ZP3P film-packaging bellows (blue silicone); 4 adapter pads supplied
  • Pad pitch adjustable (50 to 70 mm); pad flange can be omitted (N) to fit a customer-made flange
  • FANUC CRX plug-in software (tablet TP, R-30iB Mini Plus) for easy programming; mounting ISO9409-1-50-4-M6
  • Replacement pad flange ZXP7-PFL1-A-X1 and suction assist valve ZP2V-B6-05 ordered separately

Specifications

Compatible robots FANUC CRX series
Robot mounting ISO9409-1-50-4-M6
Fluid Air
Operating temperature 5 to 50°C
Max. payload 7 kg (depends on pad and work)
Max. vacuum pressure -84 kPa
Suction flow rate 17 L/min (ANR)
Air consumption 57 L/min (ANR)
Supply pressure 0.3 to 0.55 MPa (standard 0.5 MPa)
Supply port One-touch fitting ø6
Power / connector DC24V ±10%, M8 8-pin (socket)
Mass 794 g (581 g without pad flange), excl. pads
Source SMC Korea catalog CAT.KS160-1A (SMCKR_Attachment_for_Co-Robots_for_FANUC.pdf), p. 4-7, 15 (PDF p. 5-8, 16)
ZXP7A21-ZP08UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP08US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP08UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP08UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP08BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP08BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP08BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP08BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP10UTN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP10UTS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP10UTU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP10UTF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP13UTN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP13UTS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP13UTU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP13UTF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP16UTN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP16UTS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP16UTU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP16UTF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP10UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP10US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP10UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP10UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP13UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP13US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP13UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP13UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP16UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP16US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP16UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP16UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP20UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP20US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP20UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP20UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP25UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP25US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP25UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP25UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP32UN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP32US-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP32UU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP32UF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP10CN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP10CS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP10CU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP10CF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP13CN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP13CS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP13CU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP13CF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP16CN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP16CS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP16CU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP16CF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP20CN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP20CS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP20CU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP20CF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP25CN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP25CS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP25CU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP25CF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP32CN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP32CS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP32CU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP32CF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP10BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP10BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP10BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP10BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP13BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP13BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP13BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP13BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP16BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP16BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP16BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP16BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP20BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP20BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP20BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP20BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP25BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP25BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP25BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP25BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP32BN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP32BS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP32BU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP32BF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP20UTN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP20UTS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP20UTU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP20UTF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP16JN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: NBR
ZXP7A21-ZP16JS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP16JU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: Urethane rubber
ZXP7A21-ZP16JF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: FKM
ZXP7A21-ZPB25JN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: NBR
ZXP7A21-ZPB25JS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZPB25JU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: Urethane rubber
ZXP7A21-ZPB25JF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: FKM
ZXP7A21-ZPB30JN-X1 Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: NBR
ZXP7A21-ZPB30JS-X1 Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZPB30JU-X1 Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: Urethane rubber
ZXP7A21-ZPB30JF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: FKM
ZXP7A21-ZP3P20JT2SF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: ZP3P 2.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P20JT2SFM-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: ZP3P 2.5-stage bellows, mesh att. | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P32JT2SF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: ZP3P 2.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P32JT2SFM-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: ZP3P 2.5-stage bellows, mesh att. | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P20JT5SF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: ZP3P 5.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P25JT5SF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: ZP3P 5.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P32JT5SF-X1 Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: ZP3P 5.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-X1 Pad flange: With (42x42 mm) | Pad dia.: None | Pad shape: None (no pad) | Pad material: None
ZXP7N21-X1 Pad flange: Without | Pad dia.: None | Pad shape: None (no pad) | Pad material: None
Vacuum EquipmentSMC
117 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC ZXP7 Vacuum Gripper for FANUC CRX Series

Brand SMC·Vacuum Equipment

Available part numbers (117)

ZXP7A21-ZP08UN-X1, ZXP7A21-ZP08US-X1, ZXP7A21-ZP08UU-X1, ZXP7A21-ZP08UF-X1, ZXP7A21-ZP08BN-X1, ZXP7A21-ZP08BS-X1, ZXP7A21-ZP08BU-X1, ZXP7A21-ZP08BF-X1, ZXP7A21-ZP10UTN-X1, ZXP7A21-ZP10UTS-X1 + 107 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ZXP7A21-ZP08UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP08US-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP08UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP08UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP08BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP08BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP08BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP08BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø8 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP10UTN-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP10UTS-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP10UTU-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP10UTF-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP13UTN-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP13UTS-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP13UTU-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP13UTF-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP16UTN-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP16UTS-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP16UTU-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP16UTF-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP10UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP10US-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP10UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP10UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP13UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP13US-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP13UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP13UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP16UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP16US-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP16UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP16UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP20UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP20US-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP20UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP20UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP25UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP25US-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP25UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP25UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP32UN-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: NBR
ZXP7A21-ZP32US-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP32UU-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: Urethane rubber
ZXP7A21-ZP32UF-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat | Pad material: FKM
ZXP7A21-ZP10CN-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP10CS-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP10CU-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP10CF-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP13CN-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP13CS-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP13CU-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP13CF-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP16CN-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP16CS-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP16CU-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP16CF-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP20CN-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP20CS-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP20CU-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP20CF-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP25CN-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP25CS-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP25CU-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP25CF-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP32CN-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: NBR
ZXP7A21-ZP32CS-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: Silicone rubber (white)
ZXP7A21-ZP32CU-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: Urethane rubber
ZXP7A21-ZP32CF-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Flat with ribs | Pad material: FKM
ZXP7A21-ZP10BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP10BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP10BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP10BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø10 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP13BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP13BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP13BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP13BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø13 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP16BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP16BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP16BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP16BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP20BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP20BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP20BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP20BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP25BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP25BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP25BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP25BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP32BN-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: NBR
ZXP7A21-ZP32BS-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP32BU-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: Urethane rubber
ZXP7A21-ZP32BF-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: Bellows | Pad material: FKM
ZXP7A21-ZP20UTN-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: NBR
ZXP7A21-ZP20UTS-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: Silicone rubber (white)
ZXP7A21-ZP20UTU-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: Urethane rubber
ZXP7A21-ZP20UTF-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: Thin flat | Pad material: FKM
ZXP7A21-ZP16JN-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: NBR
ZXP7A21-ZP16JS-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZP16JU-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: Urethane rubber
ZXP7A21-ZP16JF-X1Pad flange: With (42x42 mm) | Pad dia.: ø16 | Pad shape: Multi-stage bellows | Pad material: FKM
ZXP7A21-ZPB25JN-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: NBR
ZXP7A21-ZPB25JS-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZPB25JU-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: Urethane rubber
ZXP7A21-ZPB25JF-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: Multi-stage bellows | Pad material: FKM
ZXP7A21-ZPB30JN-X1Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: NBR
ZXP7A21-ZPB30JS-X1Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: Silicone rubber (white)
ZXP7A21-ZPB30JU-X1Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: Urethane rubber
ZXP7A21-ZPB30JF-X1Pad flange: With (42x42 mm) | Pad dia.: ø30 | Pad shape: Multi-stage bellows | Pad material: FKM
ZXP7A21-ZP3P20JT2SF-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: ZP3P 2.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P20JT2SFM-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: ZP3P 2.5-stage bellows, mesh att. | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P32JT2SF-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: ZP3P 2.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P32JT2SFM-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: ZP3P 2.5-stage bellows, mesh att. | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P20JT5SF-X1Pad flange: With (42x42 mm) | Pad dia.: ø20 | Pad shape: ZP3P 5.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P25JT5SF-X1Pad flange: With (42x42 mm) | Pad dia.: ø25 | Pad shape: ZP3P 5.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-ZP3P32JT5SF-X1Pad flange: With (42x42 mm) | Pad dia.: ø32 | Pad shape: ZP3P 5.5-stage bellows | Pad material: Silicone rubber (blue)
ZXP7A21-X1Pad flange: With (42x42 mm) | Pad dia.: None | Pad shape: None (no pad) | Pad material: None
ZXP7N21-X1Pad flange: Without | Pad dia.: None | Pad shape: None (no pad) | Pad material: None

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
