THK Cam Follower CF-SFU (Simple Mount, Snap-Fit Type)

THK Cam Follower CF-SFU (Simple Mount, Snap-Fit Type)

THK CF-SFU type Cam Follower for simplified installation.

Key features

  • Stepped stud design allows fixing into H7 mounting hole without thread engagement
  • Ideal for applications with limited stud fastening space
  • UU double seal standard (no UU code needed in part number)
  • Delivered with plug installed
  • Stud diameter d = 6~20mm
  • Options: V (total needle - N/A for this type; cage only), R (spherical outer ring)

Specifications

Seal UU double seal (standard, included)
Options R=spherical outer ring
Note Plug installed on delivery; cage roller only
CF-SFU-6 THK Cam Follower CF-SFU-6 (simple mount), d=6mm, D=16mm, C=3.59kN | Stud Diameter (d): 6 mm | Outer Diameter (D): 16 mm | Outer Ring Width (C): 11 mm | Total Length (B): 32 mm | Eccentricity (e): 0.3 mm | Mounting Hole (H7): Ø6 mm | Shoulder (t): 20 mm | Shoulder (f): 11 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 3.59 kN | Basic Static Load Rating C0: 3.58 kN | Max Allowable Load F0 (cylindrical): 2.11 kN | Max Allowable Load F0 (spherical): 3.43 kN | Track Load Capacity: 1.08 kN | Limit Speed: 17500 min⁻¹ | Mass: 19.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-8 THK Cam Follower CF-SFU-8 (simple mount), d=8mm, D=19mm, C=4.17kN | Stud Diameter (d): 8 mm | Outer Diameter (D): 19 mm | Outer Ring Width (C): 11 mm | Total Length (B): 32 mm | Eccentricity (e): 0.5 mm | Mounting Hole (H7): Ø8 mm | Shoulder (t): 20 mm | Shoulder (f): 13 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 4.17 kN | Basic Static Load Rating C0: 4.65 kN | Max Allowable Load F0 (cylindrical): 4.73 kN | Max Allowable Load F0 (spherical): 4.02 kN | Track Load Capacity: 1.37 kN | Limit Speed: 14000 min⁻¹ | Mass: 28.5 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-10 THK Cam Follower CF-SFU-10 (simple mount), d=10mm, D=22mm, C=5.33kN | Stud Diameter (d): 10 mm | Outer Diameter (D): 22 mm | Outer Ring Width (C): 12 mm | Total Length (B): 33 mm | Eccentricity (e): 0.5 mm | Mounting Hole (H7): Ø10 mm | Shoulder (t): 20 mm | Shoulder (f): 15 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 5.33 kN | Basic Static Load Rating C0: 6.78 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 4.7 kN | Track Load Capacity: 1.67 kN | Limit Speed: 11900 min⁻¹ | Mass: 43.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-10-1 THK Cam Follower CF-SFU-10-1 (simple mount), d=10mm, D=26mm, C=5.33kN | Stud Diameter (d): 10 mm | Outer Diameter (D): 26 mm | Outer Ring Width (C): 12 mm | Total Length (B): 33 mm | Eccentricity (e): 0.5 mm | Mounting Hole (H7): Ø10 mm | Shoulder (t): 20 mm | Shoulder (f): 15 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 5.33 kN | Basic Static Load Rating C0: 6.78 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 5.49 kN | Track Load Capacity: 2.06 kN | Limit Speed: 11900 min⁻¹ | Mass: 58.5 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-12 THK Cam Follower CF-SFU-12 (simple mount), d=12mm, D=30mm, C=7.87kN | Stud Diameter (d): 12 mm | Outer Diameter (D): 30 mm | Outer Ring Width (C): 14 mm | Total Length (B): 35 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø12 mm | Shoulder (t): 20 mm | Shoulder (f): 20 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 7.87 kN | Basic Static Load Rating C0: 9.79 kN | Max Allowable Load F0 (cylindrical): 9.37 kN | Max Allowable Load F0 (spherical): 7.06 kN | Track Load Capacity: 2.45 kN | Limit Speed: 9800 min⁻¹ | Mass: 93.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-12-1 THK Cam Follower CF-SFU-12-1 (simple mount), d=12mm, D=32mm, C=7.87kN | Stud Diameter (d): 12 mm | Outer Diameter (D): 32 mm | Outer Ring Width (C): 14 mm | Total Length (B): 35 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø12 mm | Shoulder (t): 20 mm | Shoulder (f): 20 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 7.87 kN | Basic Static Load Rating C0: 9.79 kN | Max Allowable Load F0 (cylindrical): 9.37 kN | Max Allowable Load F0 (spherical): 7.45 kN | Track Load Capacity: 2.74 kN | Limit Speed: 9800 min⁻¹ | Mass: 103.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-16 THK Cam Follower CF-SFU-16 (simple mount), d=16mm, D=35mm, C=12.0kN | Stud Diameter (d): 16 mm | Outer Diameter (D): 35 mm | Outer Ring Width (C): 18 mm | Total Length (B): 44.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø16 mm | Shoulder (t): 25 mm | Shoulder (f): 24 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 12.0 kN | Basic Static Load Rating C0: 18.3 kN | Max Allowable Load F0 (cylindrical): 17.3 kN | Max Allowable Load F0 (spherical): 11.2 kN | Track Load Capacity: 3.14 kN | Limit Speed: 7000 min⁻¹ | Mass: 163.5 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-18 THK Cam Follower CF-SFU-18 (simple mount), d=18mm, D=40mm, C=14.7kN | Stud Diameter (d): 18 mm | Outer Diameter (D): 40 mm | Outer Ring Width (C): 20 mm | Total Length (B): 46.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø18 mm | Shoulder (t): 25 mm | Shoulder (f): 26 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 14.7 kN | Basic Static Load Rating C0: 25.2 kN | Max Allowable Load F0 (cylindrical): 26.1 kN | Max Allowable Load F0 (spherical): 14.4 kN | Track Load Capacity: 3.72 kN | Limit Speed: 5950 min⁻¹ | Mass: 235.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-20 THK Cam Follower CF-SFU-20 (simple mount), d=20mm, D=52mm, C=20.7kN | Stud Diameter (d): 20 mm | Outer Diameter (D): 52 mm | Outer Ring Width (C): 24 mm | Total Length (B): 50.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø20 mm | Shoulder (t): 25 mm | Shoulder (f): 36 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 20.7 kN | Basic Static Load Rating C0: 34.8 kN | Max Allowable Load F0 (cylindrical): 32.1 kN | Max Allowable Load F0 (spherical): 23.2 kN | Track Load Capacity: 8.23 kN | Limit Speed: 4900 min⁻¹ | Mass: 436.0 g | Options: R=spherical outer ring | Spherical radius: R1000 | Note: Plug installed on delivery; cage roller only
CF-SFU-20-1 THK Cam Follower CF-SFU-20-1 (simple mount), d=20mm, D=47mm, C=20.7kN | Stud Diameter (d): 20 mm | Outer Diameter (D): 47 mm | Outer Ring Width (C): 24 mm | Total Length (B): 50.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø20 mm | Shoulder (t): 25 mm | Shoulder (f): 36 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 20.7 kN | Basic Static Load Rating C0: 34.8 kN | Max Allowable Load F0 (cylindrical): 32.1 kN | Max Allowable Load F0 (spherical): 21.0 kN | Track Load Capacity: 7.15 kN | Limit Speed: 4900 min⁻¹ | Mass: 361.0 g | Options: R=spherical outer ring | Spherical radius: R1000 | Note: Plug installed on delivery; cage roller only
Roller GuidesTHK
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK Cam Follower CF-SFU (Simple Mount, Snap-Fit Type)

Brand THK·Roller Guides

Available part numbers (10)

CF-SFU-6, CF-SFU-8, CF-SFU-10, CF-SFU-10-1, CF-SFU-12, CF-SFU-12-1, CF-SFU-16, CF-SFU-18, CF-SFU-20, CF-SFU-20-1

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CF-SFU-6THK Cam Follower CF-SFU-6 (simple mount), d=6mm, D=16mm, C=3.59kN | Stud Diameter (d): 6 mm | Outer Diameter (D): 16 mm | Outer Ring Width (C): 11 mm | Total Length (B): 32 mm | Eccentricity (e): 0.3 mm | Mounting Hole (H7): Ø6 mm | Shoulder (t): 20 mm | Shoulder (f): 11 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 3.59 kN | Basic Static Load Rating C0: 3.58 kN | Max Allowable Load F0 (cylindrical): 2.11 kN | Max Allowable Load F0 (spherical): 3.43 kN | Track Load Capacity: 1.08 kN | Limit Speed: 17500 min⁻¹ | Mass: 19.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-8THK Cam Follower CF-SFU-8 (simple mount), d=8mm, D=19mm, C=4.17kN | Stud Diameter (d): 8 mm | Outer Diameter (D): 19 mm | Outer Ring Width (C): 11 mm | Total Length (B): 32 mm | Eccentricity (e): 0.5 mm | Mounting Hole (H7): Ø8 mm | Shoulder (t): 20 mm | Shoulder (f): 13 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 4.17 kN | Basic Static Load Rating C0: 4.65 kN | Max Allowable Load F0 (cylindrical): 4.73 kN | Max Allowable Load F0 (spherical): 4.02 kN | Track Load Capacity: 1.37 kN | Limit Speed: 14000 min⁻¹ | Mass: 28.5 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-10THK Cam Follower CF-SFU-10 (simple mount), d=10mm, D=22mm, C=5.33kN | Stud Diameter (d): 10 mm | Outer Diameter (D): 22 mm | Outer Ring Width (C): 12 mm | Total Length (B): 33 mm | Eccentricity (e): 0.5 mm | Mounting Hole (H7): Ø10 mm | Shoulder (t): 20 mm | Shoulder (f): 15 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 5.33 kN | Basic Static Load Rating C0: 6.78 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 4.7 kN | Track Load Capacity: 1.67 kN | Limit Speed: 11900 min⁻¹ | Mass: 43.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-10-1THK Cam Follower CF-SFU-10-1 (simple mount), d=10mm, D=26mm, C=5.33kN | Stud Diameter (d): 10 mm | Outer Diameter (D): 26 mm | Outer Ring Width (C): 12 mm | Total Length (B): 33 mm | Eccentricity (e): 0.5 mm | Mounting Hole (H7): Ø10 mm | Shoulder (t): 20 mm | Shoulder (f): 15 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 5.33 kN | Basic Static Load Rating C0: 6.78 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 5.49 kN | Track Load Capacity: 2.06 kN | Limit Speed: 11900 min⁻¹ | Mass: 58.5 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-12THK Cam Follower CF-SFU-12 (simple mount), d=12mm, D=30mm, C=7.87kN | Stud Diameter (d): 12 mm | Outer Diameter (D): 30 mm | Outer Ring Width (C): 14 mm | Total Length (B): 35 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø12 mm | Shoulder (t): 20 mm | Shoulder (f): 20 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 7.87 kN | Basic Static Load Rating C0: 9.79 kN | Max Allowable Load F0 (cylindrical): 9.37 kN | Max Allowable Load F0 (spherical): 7.06 kN | Track Load Capacity: 2.45 kN | Limit Speed: 9800 min⁻¹ | Mass: 93.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-12-1THK Cam Follower CF-SFU-12-1 (simple mount), d=12mm, D=32mm, C=7.87kN | Stud Diameter (d): 12 mm | Outer Diameter (D): 32 mm | Outer Ring Width (C): 14 mm | Total Length (B): 35 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø12 mm | Shoulder (t): 20 mm | Shoulder (f): 20 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 7.87 kN | Basic Static Load Rating C0: 9.79 kN | Max Allowable Load F0 (cylindrical): 9.37 kN | Max Allowable Load F0 (spherical): 7.45 kN | Track Load Capacity: 2.74 kN | Limit Speed: 9800 min⁻¹ | Mass: 103.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-16THK Cam Follower CF-SFU-16 (simple mount), d=16mm, D=35mm, C=12.0kN | Stud Diameter (d): 16 mm | Outer Diameter (D): 35 mm | Outer Ring Width (C): 18 mm | Total Length (B): 44.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø16 mm | Shoulder (t): 25 mm | Shoulder (f): 24 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 12.0 kN | Basic Static Load Rating C0: 18.3 kN | Max Allowable Load F0 (cylindrical): 17.3 kN | Max Allowable Load F0 (spherical): 11.2 kN | Track Load Capacity: 3.14 kN | Limit Speed: 7000 min⁻¹ | Mass: 163.5 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-18THK Cam Follower CF-SFU-18 (simple mount), d=18mm, D=40mm, C=14.7kN | Stud Diameter (d): 18 mm | Outer Diameter (D): 40 mm | Outer Ring Width (C): 20 mm | Total Length (B): 46.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø18 mm | Shoulder (t): 25 mm | Shoulder (f): 26 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 14.7 kN | Basic Static Load Rating C0: 25.2 kN | Max Allowable Load F0 (cylindrical): 26.1 kN | Max Allowable Load F0 (spherical): 14.4 kN | Track Load Capacity: 3.72 kN | Limit Speed: 5950 min⁻¹ | Mass: 235.0 g | Options: R=spherical outer ring | Spherical radius: R500 | Note: Plug installed on delivery; cage roller only
CF-SFU-20THK Cam Follower CF-SFU-20 (simple mount), d=20mm, D=52mm, C=20.7kN | Stud Diameter (d): 20 mm | Outer Diameter (D): 52 mm | Outer Ring Width (C): 24 mm | Total Length (B): 50.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø20 mm | Shoulder (t): 25 mm | Shoulder (f): 36 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 20.7 kN | Basic Static Load Rating C0: 34.8 kN | Max Allowable Load F0 (cylindrical): 32.1 kN | Max Allowable Load F0 (spherical): 23.2 kN | Track Load Capacity: 8.23 kN | Limit Speed: 4900 min⁻¹ | Mass: 436.0 g | Options: R=spherical outer ring | Spherical radius: R1000 | Note: Plug installed on delivery; cage roller only
CF-SFU-20-1THK Cam Follower CF-SFU-20-1 (simple mount), d=20mm, D=47mm, C=20.7kN | Stud Diameter (d): 20 mm | Outer Diameter (D): 47 mm | Outer Ring Width (C): 24 mm | Total Length (B): 50.5 mm | Eccentricity (e): 1.0 mm | Mounting Hole (H7): Ø20 mm | Shoulder (t): 25 mm | Shoulder (f): 36 mm | Seal: UU double seal (standard, included) | Basic Dynamic Load Rating C: 20.7 kN | Basic Static Load Rating C0: 34.8 kN | Max Allowable Load F0 (cylindrical): 32.1 kN | Max Allowable Load F0 (spherical): 21.0 kN | Track Load Capacity: 7.15 kN | Limit Speed: 4900 min⁻¹ | Mass: 361.0 g | Options: R=spherical outer ring | Spherical radius: R1000 | Note: Plug installed on delivery; cage roller only
