THK Cross Roller Table VRT3-A (W40×H16, base hole type)

THK Cross Roller Table VRT3-A (W40×H16, base hole type)

THK VRT-A Miniature Cross Roller Table, VRT3-A frame.

Key features

  • Base mounting through-hole type (d×D×h = 4.5×7.5×4.2mm)
  • Table width W=40mm, height M=16mm
  • Stroke range 30~130mm
  • Same load ratings as VRT tab type; base through-hole mounting for improved rigidity
  • Full stainless steel type available on request

Specifications

Frame VRT3-A
Type Base Through-Hole
Mounting Hole (d×D×h) 4.5×7.5×4.2 mm
Table Width (W) 40 mm
Height (M) 16 mm
Full Stainless Type available on request
VRT3055A THK Cross Roller Table VRT3055A, stroke 30mm, 6 rollers, 226g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 30 mm | Rollers (Z): 6 | Mass: 226 g | Basic Dynamic Load Rating C: 2.71 kN | Basic Static Load Rating C0: 3.67 kN | Static Allowable Moment MA: 12.2 N·m | Static Allowable Moment MB: 13.9 N·m | Static Allowable Moment MC: 31.9 N·m | Full Stainless Type: available on request
VRT3080A THK Cross Roller Table VRT3080A, stroke 45mm, 10 rollers, 333g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 45 mm | Rollers (Z): 10 | Mass: 333 g | Basic Dynamic Load Rating C: 4.06 kN | Basic Static Load Rating C0: 6.11 kN | Static Allowable Moment MA: 33.1 N·m | Static Allowable Moment MB: 36.2 N·m | Static Allowable Moment MC: 53.1 N·m | Full Stainless Type: available on request
VRT3105A THK Cross Roller Table VRT3105A, stroke 60mm, 13 rollers, 439g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 60 mm | Rollers (Z): 13 | Mass: 439 g | Basic Dynamic Load Rating C: 4.68 kN | Basic Static Load Rating C0: 7.33 kN | Static Allowable Moment MA: 64.6 N·m | Static Allowable Moment MB: 59.8 N·m | Static Allowable Moment MC: 63.8 N·m | Full Stainless Type: available on request
VRT3130A THK Cross Roller Table VRT3130A, stroke 75mm, 17 rollers, 548g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 75 mm | Rollers (Z): 17 | Mass: 548 g | Basic Dynamic Load Rating C: 5.87 kN | Basic Static Load Rating C0: 9.77 kN | Static Allowable Moment MA: 107.0 N·m | Static Allowable Moment MB: 100.0 N·m | Static Allowable Moment MC: 85.0 N·m | Full Stainless Type: available on request
VRT3155A THK Cross Roller Table VRT3155A, stroke 90mm, 20 rollers, 652g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 90 mm | Rollers (Z): 20 | Mass: 652 g | Basic Dynamic Load Rating C: 6.98 kN | Basic Static Load Rating C0: 12.2 kN | Static Allowable Moment MA: 131.0 N·m | Static Allowable Moment MB: 138.0 N·m | Static Allowable Moment MC: 106.0 N·m | Full Stainless Type: available on request
VRT3180A THK Cross Roller Table VRT3180A, stroke 105mm, 24 rollers, 761g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 105 mm | Rollers (Z): 24 | Mass: 761 g | Basic Dynamic Load Rating C: 8.05 kN | Basic Static Load Rating C0: 14.7 kN | Static Allowable Moment MA: 189.0 N·m | Static Allowable Moment MB: 196.0 N·m | Static Allowable Moment MC: 128.0 N·m | Full Stainless Type: available on request
VRT3205A THK Cross Roller Table VRT3205A, stroke 130mm, 26 rollers, 866g | Frame: VRT3-A | Type: Base Through-Hole | Mounting Hole (d×D×h): 4.5×7.5×4.2 mm | Table Width (W): 40 mm | Height (M): 16 mm | Stroke: 130 mm | Rollers (Z): 26 | Mass: 866 g | Basic Dynamic Load Rating C: 8.57 kN | Basic Static Load Rating C0: 15.9 kN | Static Allowable Moment MA: 222.0 N·m | Static Allowable Moment MB: 230.0 N·m | Static Allowable Moment MC: 138.0 N·m | Full Stainless Type: available on request
Roller GuidesTHK
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK Cross Roller Table VRT3-A (W40×H16, base hole type)

Brand THK·Roller Guides

Available part numbers (7)

VRT3055A, VRT3080A, VRT3105A, VRT3130A, VRT3155A, VRT3180A, VRT3205A

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
