THK Cross Roller Table VRU1 (W30×H17, M2)

THK Cross Roller Table VRU1 (W30×H17, M2)

THK VRU Cross Roller Table, VRU1 frame.

Key features

  • Table width W=30mm, height M=17mm, table mounting tap M2
  • Base mounting through-hole d×D×h = 2.55×4.1×2.5mm
  • Stroke range 12~50mm
  • Side mounting taps provided
  • Stainless steel type available on request (approx. 0.04~0.14 kg)

Specifications

Frame VRU1
Table Width (W) 30 mm
Height (M) 17 mm
Table Mounting Tap M2
Base Hole (d×D×h) 2.55×4.1×2.5 mm
Stainless Type available on request
VRU1025 THK Cross Roller Table VRU1025, stroke 12mm, 5 rollers, 0.08kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 12 mm | Rollers (Z): 5 | Mass (standard): 0.08 kg | Mass (stainless): 0.04 kg | Basic Dynamic Load Rating C: 0.46 kN | Basic Static Load Rating C0: 0.61 kN | Static Allowable Moment MA: 1.52 N·m | Static Allowable Moment MB: 1.25 N·m | Static Allowable Moment MC: 4.12 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1035 THK Cross Roller Table VRU1035, stroke 18mm, 7 rollers, 0.11kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 18 mm | Rollers (Z): 7 | Mass (standard): 0.11 kg | Mass (stainless): 0.05 kg | Basic Dynamic Load Rating C: 0.63 kN | Basic Static Load Rating C0: 0.92 kN | Static Allowable Moment MA: 2.62 N·m | Static Allowable Moment MB: 2.32 N·m | Static Allowable Moment MC: 6.18 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1045 THK Cross Roller Table VRU1045, stroke 25mm, 10 rollers, 0.15kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 25 mm | Rollers (Z): 10 | Mass (standard): 0.15 kg | Mass (stainless): 0.07 kg | Basic Dynamic Load Rating C: 0.95 kN | Basic Static Load Rating C0: 1.53 kN | Static Allowable Moment MA: 4.14 N·m | Static Allowable Moment MB: 4.53 N·m | Static Allowable Moment MC: 10.3 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1055 THK Cross Roller Table VRU1055, stroke 32mm, 12 rollers, 0.18kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 32 mm | Rollers (Z): 12 | Mass (standard): 0.18 kg | Mass (stainless): 0.09 kg | Basic Dynamic Load Rating C: 1.09 kN | Basic Static Load Rating C0: 1.83 kN | Static Allowable Moment MA: 5.92 N·m | Static Allowable Moment MB: 6.41 N·m | Static Allowable Moment MC: 12.4 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1065 THK Cross Roller Table VRU1065, stroke 40mm, 14 rollers, 0.21kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 40 mm | Rollers (Z): 14 | Mass (standard): 0.21 kg | Mass (stainless): 0.1 kg | Basic Dynamic Load Rating C: 1.23 kN | Basic Static Load Rating C0: 2.14 kN | Static Allowable Moment MA: 8.08 N·m | Static Allowable Moment MB: 8.62 N·m | Static Allowable Moment MC: 14.4 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1075 THK Cross Roller Table VRU1075, stroke 45mm, 18 rollers, 0.24kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 45 mm | Rollers (Z): 18 | Mass (standard): 0.24 kg | Mass (stainless): 0.12 kg | Basic Dynamic Load Rating C: 1.5 kN | Basic Static Load Rating C0: 2.75 kN | Static Allowable Moment MA: 13.3 N·m | Static Allowable Moment MB: 14.0 N·m | Static Allowable Moment MC: 18.6 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1085 THK Cross Roller Table VRU1085, stroke 50mm, 20 rollers, 0.27kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 50 mm | Rollers (Z): 20 | Mass (standard): 0.27 kg | Mass (stainless): 0.13 kg | Basic Dynamic Load Rating C: 1.63 kN | Basic Static Load Rating C0: 3.05 kN | Static Allowable Moment MA: 16.4 N·m | Static Allowable Moment MB: 17.2 N·m | Static Allowable Moment MC: 20.6 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
Roller GuidesTHK
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK Cross Roller Table VRU1 (W30×H17, M2)

Brand THK·Roller Guides

Available part numbers (7)

VRU1025, VRU1035, VRU1045, VRU1055, VRU1065, VRU1075, VRU1085

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VRU1025THK Cross Roller Table VRU1025, stroke 12mm, 5 rollers, 0.08kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 12 mm | Rollers (Z): 5 | Mass (standard): 0.08 kg | Mass (stainless): 0.04 kg | Basic Dynamic Load Rating C: 0.46 kN | Basic Static Load Rating C0: 0.61 kN | Static Allowable Moment MA: 1.52 N·m | Static Allowable Moment MB: 1.25 N·m | Static Allowable Moment MC: 4.12 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1035THK Cross Roller Table VRU1035, stroke 18mm, 7 rollers, 0.11kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 18 mm | Rollers (Z): 7 | Mass (standard): 0.11 kg | Mass (stainless): 0.05 kg | Basic Dynamic Load Rating C: 0.63 kN | Basic Static Load Rating C0: 0.92 kN | Static Allowable Moment MA: 2.62 N·m | Static Allowable Moment MB: 2.32 N·m | Static Allowable Moment MC: 6.18 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1045THK Cross Roller Table VRU1045, stroke 25mm, 10 rollers, 0.15kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 25 mm | Rollers (Z): 10 | Mass (standard): 0.15 kg | Mass (stainless): 0.07 kg | Basic Dynamic Load Rating C: 0.95 kN | Basic Static Load Rating C0: 1.53 kN | Static Allowable Moment MA: 4.14 N·m | Static Allowable Moment MB: 4.53 N·m | Static Allowable Moment MC: 10.3 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1055THK Cross Roller Table VRU1055, stroke 32mm, 12 rollers, 0.18kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 32 mm | Rollers (Z): 12 | Mass (standard): 0.18 kg | Mass (stainless): 0.09 kg | Basic Dynamic Load Rating C: 1.09 kN | Basic Static Load Rating C0: 1.83 kN | Static Allowable Moment MA: 5.92 N·m | Static Allowable Moment MB: 6.41 N·m | Static Allowable Moment MC: 12.4 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1065THK Cross Roller Table VRU1065, stroke 40mm, 14 rollers, 0.21kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 40 mm | Rollers (Z): 14 | Mass (standard): 0.21 kg | Mass (stainless): 0.1 kg | Basic Dynamic Load Rating C: 1.23 kN | Basic Static Load Rating C0: 2.14 kN | Static Allowable Moment MA: 8.08 N·m | Static Allowable Moment MB: 8.62 N·m | Static Allowable Moment MC: 14.4 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1075THK Cross Roller Table VRU1075, stroke 45mm, 18 rollers, 0.24kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 45 mm | Rollers (Z): 18 | Mass (standard): 0.24 kg | Mass (stainless): 0.12 kg | Basic Dynamic Load Rating C: 1.5 kN | Basic Static Load Rating C0: 2.75 kN | Static Allowable Moment MA: 13.3 N·m | Static Allowable Moment MB: 14.0 N·m | Static Allowable Moment MC: 18.6 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
VRU1085THK Cross Roller Table VRU1085, stroke 50mm, 20 rollers, 0.27kg | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 50 mm | Rollers (Z): 20 | Mass (standard): 0.27 kg | Mass (stainless): 0.13 kg | Basic Dynamic Load Rating C: 1.63 kN | Basic Static Load Rating C0: 3.05 kN | Static Allowable Moment MA: 16.4 N·m | Static Allowable Moment MB: 17.2 N·m | Static Allowable Moment MC: 20.6 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request
