THK HSR-RM Miniature LM Guide Block (Full Ball, Stainless, High Rigidity)

THK HSR-RM Miniature LM Guide Block (Full Ball, Stainless, High Rigidity)

Miniature Full ball type LM Guide.

Key features

  • HSR miniature series — stainless steel rail, block and balls. 4-direction equal load rating with 45° ball arrangement. 4-row configuration for high rigidity
  • THK Circular Arc groove (DF structure)

Specifications

Type Miniature LM Guide Block
Series HSR
Material Stainless Steel
Structure Full Ball DF
Load Type 4-Direction Equal
Configuration 4-row High Rigidity
Brand THK
HSR-8RM HSR 8RM LM Block H11×W16×L24mm | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 8RM | Height M: 11 mm | Width W: 16 mm | Length L: 24 mm | Max Rail Length: 975 mm | Dynamic Load C: 1.08 kN | Static Load C0: 2.16 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK
HSR-10RM HSR 10RM LM Block H13×W20×L31mm | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 10RM | Height M: 13 mm | Width W: 20 mm | Length L: 31 mm | Max Rail Length: 995 mm | Dynamic Load C: 1.96 kN | Static Load C0: 3.82 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK
HSR-12RM HSR 12RM LM Block H20×W27×L45mm | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 12RM | Height M: 20 mm | Width W: 27 mm | Length L: 45 mm | Max Rail Length: 1240 mm | Dynamic Load C: 4.7 kN | Static Load C0: 8.53 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK
LM GuidesTHK
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK HSR-RM Miniature LM Guide Block (Full Ball, Stainless, High Rigidity)

Brand THK·LM Guides

Available part numbers (3)

HSR-8RM, HSR-10RM, HSR-12RM

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HSR-8RMHSR 8RM LM Block H11×W16×L24mm | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 8RM | Height M: 11 mm | Width W: 16 mm | Length L: 24 mm | Max Rail Length: 975 mm | Dynamic Load C: 1.08 kN | Static Load C0: 2.16 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK
HSR-10RMHSR 10RM LM Block H13×W20×L31mm | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 10RM | Height M: 13 mm | Width W: 20 mm | Length L: 31 mm | Max Rail Length: 995 mm | Dynamic Load C: 1.96 kN | Static Load C0: 3.82 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK
HSR-12RMHSR 12RM LM Block H20×W27×L45mm | Type: Miniature LM Guide Block | Series: HSR | Model: HSR 12RM | Height M: 20 mm | Width W: 27 mm | Length L: 45 mm | Max Rail Length: 1240 mm | Dynamic Load C: 4.7 kN | Static Load C0: 8.53 kN | Material: Stainless Steel | Structure: Full Ball DF | Load Type: 4-Direction Equal | Configuration: 4-row High Rigidity | Brand: THK
