TiMOTION TA19 Series Linear Actuator (up to 1,000 N)

TiMOTION TA19 Series Linear Actuator (up to 1,000 N)

Quiet TiMOTION TA19 series telescopic linear actuator suited to height-adjustable work tables, rated up to 1,000 N push.

Key features

  • Telescopic design: short retracted length
  • Up to 1,000 N push
  • Two motor speeds, 5 load/speed codes
  • Optional Hall sensors
  • 12 V DC, 24 V DC or 24 V DC (PTC)

Specifications

Voltage 12 V DC, 24 V DC or 24 V DC (PTC)
Max. load 1,000 N push
Max. speed at full load 30 mm/s (800 N)
Stroke 180-800 mm
Min. installation Stroke/2 + 165 mm
Certificates IEC60601-1, ES60601-1, EMC
Operating temp. +5 to +45 C
Product segment Care / Comfort Motion
Load codes 5 (full code per ordering key)
Source TiMOTION TA19 series datasheet
TA19-A Push: 600 N | Self-lock: 400 N | Speed at load: 27.0 mm/s | Current at load: 3.2 A | Motor: 3800 RPM
TA19-B Push: 1,000 N | Self-lock: 1,000 N | Speed at load: 11.0 mm/s | Current at load: 4.0 A | Motor: 3800 RPM
TA19-C Push: 800 N | Self-lock: 400 N | Speed at load: 30.0 mm/s | Current at load: 6.5 A | Motor: 5200 RPM
TA19-D Push: 1,000 N | Self-lock: 1,000 N | Speed at load: 18.0 mm/s | Current at load: 5.0 A | Motor: 5200 RPM
TA19-E Push: 800 N | Self-lock: 500 N | Speed at load: 26.5 mm/s | Current at load: 6.0 A | Motor: 5200 RPM
Linear ActuatorsTiMOTION
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TiMOTION TA19 Series Linear Actuator (up to 1,000 N)

Brand TiMOTION·Linear Actuators

Available part numbers (5)

TA19-A, TA19-B, TA19-C, TA19-D, TA19-E

How to order

Send the TiMOTION part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TA19-APush: 600 N | Self-lock: 400 N | Speed at load: 27.0 mm/s | Current at load: 3.2 A | Motor: 3800 RPM
TA19-BPush: 1,000 N | Self-lock: 1,000 N | Speed at load: 11.0 mm/s | Current at load: 4.0 A | Motor: 3800 RPM
TA19-CPush: 800 N | Self-lock: 400 N | Speed at load: 30.0 mm/s | Current at load: 6.5 A | Motor: 5200 RPM
TA19-DPush: 1,000 N | Self-lock: 1,000 N | Speed at load: 18.0 mm/s | Current at load: 5.0 A | Motor: 5200 RPM
TA19-EPush: 800 N | Self-lock: 500 N | Speed at load: 26.5 mm/s | Current at load: 6.0 A | Motor: 5200 RPM
