TPC Mechatronics RMN Series Miniature LM Guide (Standard Width, Sizes 7-15)
TPC Mechatronics RMN Series Miniature LM Guide (Standard Width, Sizes 7-15)
The RMN series is a miniature linear guideway (LM guide) of standard width, supplied as a block and rail.
Key features
- It uses a two-row 45° contact-angle raceway design for a compact, lightweight, low-friction unit with equal load capacity in all four directions and low running noise
- Blocks come in standard (C) and high-load long (H) lengths in sizes 7, 9, 12 and 15
- Rails are available up to 2000 mm, with C, H and P accuracy grades and ZF/Z0/Z1 preload; preload, accuracy, rail length and material are specified at order
| RMN7C | Load type: Standard (C) | Height H: 8 mm | Width W: 17 mm | Length L: 24.1 mm | Rail width WR: 7 mm | Rail mounting bolt: M2x6 | Basic dynamic load rating C: 1.45 kN | Basic static load rating C0: 1.88 kN | Block mass: 0.010 kg | Rail mass: 0.23 kg/m | |
| RMN7H | Load type: High load (H) | Height H: 8 mm | Width W: 17 mm | Length L: 32.4 mm | Rail width WR: 7 mm | Rail mounting bolt: M2x6 | Basic dynamic load rating C: 1.87 kN | Basic static load rating C0: 2.46 kN | Block mass: 0.016 kg | Rail mass: 0.23 kg/m | |
| RMN9C | Load type: Standard (C) | Height H: 10 mm | Width W: 20 mm | Length L: 31 mm | Rail width WR: 9 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 2.47 kN | Basic static load rating C0: 3.36 kN | Block mass: 0.017 kg | Rail mass: 0.39 kg/m | |
| RMN9H | Load type: High load (H) | Height H: 10 mm | Width W: 20 mm | Length L: 42 mm | Rail width WR: 9 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 3.52 kN | Basic static load rating C0: 5.61 kN | Block mass: 0.028 kg | Rail mass: 0.39 kg/m | |
| RMN12C | Load type: Standard (C) | Height H: 13 mm | Width W: 27 mm | Length L: 37 mm | Rail width WR: 12 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 3.58 kN | Basic static load rating C0: 4.77 kN | Block mass: 0.035 kg | Rail mass: 0.66 kg/m | |
| RMN12H | Load type: High load (H) | Height H: 13 mm | Width W: 27 mm | Length L: 48 mm | Rail width WR: 12 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 4.87 kN | Basic static load rating C0: 7.42 kN | Block mass: 0.055 kg | Rail mass: 0.66 kg/m | |
| RMN15C | Load type: Standard (C) | Height H: 16 mm | Width W: 32 mm | Length L: 43 mm | Rail width WR: 15 mm | Rail mounting bolt: M3x10 | Basic dynamic load rating C: 5.36 kN | Basic static load rating C0: 7.21 kN | Block mass: 0.060 kg | Rail mass: 1.08 kg/m | |
| RMN15H | Load type: High load (H) | Height H: 16 mm | Width W: 32 mm | Length L: 59.5 mm | Rail width WR: 15 mm | Rail mounting bolt: M3x10 | Basic dynamic load rating C: 7.44 kN | Basic static load rating C0: 11.54 kN | Block mass: 0.095 kg | Rail mass: 1.08 kg/m |
LM GuidesTPC Mechatronics
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
Need a different model, or a part not listed here? Send us your parts list →
TPC Mechatronics RMN Series Miniature LM Guide (Standard Width, Sizes 7-15)
Available part numbers (8)
RMN7C, RMN7H, RMN9C, RMN9H, RMN12C, RMN12H, RMN15C, RMN15H
How to order
Send the TPC Mechatronics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
TPC Mechatronics
LM Guides
Photo on request
Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| RMN7C | Load type: Standard (C) | Height H: 8 mm | Width W: 17 mm | Length L: 24.1 mm | Rail width WR: 7 mm | Rail mounting bolt: M2x6 | Basic dynamic load rating C: 1.45 kN | Basic static load rating C0: 1.88 kN | Block mass: 0.010 kg | Rail mass: 0.23 kg/m | ||
| RMN7H | Load type: High load (H) | Height H: 8 mm | Width W: 17 mm | Length L: 32.4 mm | Rail width WR: 7 mm | Rail mounting bolt: M2x6 | Basic dynamic load rating C: 1.87 kN | Basic static load rating C0: 2.46 kN | Block mass: 0.016 kg | Rail mass: 0.23 kg/m | ||
| RMN9C | Load type: Standard (C) | Height H: 10 mm | Width W: 20 mm | Length L: 31 mm | Rail width WR: 9 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 2.47 kN | Basic static load rating C0: 3.36 kN | Block mass: 0.017 kg | Rail mass: 0.39 kg/m | ||
| RMN9H | Load type: High load (H) | Height H: 10 mm | Width W: 20 mm | Length L: 42 mm | Rail width WR: 9 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 3.52 kN | Basic static load rating C0: 5.61 kN | Block mass: 0.028 kg | Rail mass: 0.39 kg/m | ||
| RMN12C | Load type: Standard (C) | Height H: 13 mm | Width W: 27 mm | Length L: 37 mm | Rail width WR: 12 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 3.58 kN | Basic static load rating C0: 4.77 kN | Block mass: 0.035 kg | Rail mass: 0.66 kg/m | ||
| RMN12H | Load type: High load (H) | Height H: 13 mm | Width W: 27 mm | Length L: 48 mm | Rail width WR: 12 mm | Rail mounting bolt: M3x8 | Basic dynamic load rating C: 4.87 kN | Basic static load rating C0: 7.42 kN | Block mass: 0.055 kg | Rail mass: 0.66 kg/m | ||
| RMN15C | Load type: Standard (C) | Height H: 16 mm | Width W: 32 mm | Length L: 43 mm | Rail width WR: 15 mm | Rail mounting bolt: M3x10 | Basic dynamic load rating C: 5.36 kN | Basic static load rating C0: 7.21 kN | Block mass: 0.060 kg | Rail mass: 1.08 kg/m | ||
| RMN15H | Load type: High load (H) | Height H: 16 mm | Width W: 32 mm | Length L: 59.5 mm | Rail width WR: 15 mm | Rail mounting bolt: M3x10 | Basic dynamic load rating C: 7.44 kN | Basic static load rating C0: 11.54 kN | Block mass: 0.095 kg | Rail mass: 1.08 kg/m |
