TPC TCK1 / TCK2 / TCKP1 Clamp Cylinder Accessories

TPC TCK1 / TCK2 / TCKP1 Clamp Cylinder Accessories

Double knuckle joints, knuckle pin, limit switch bracket, dog fitting and auto switch bracket for TPC TCK1, TCK2 and TCKP1 welding clamp cylinders, bore 50 and 63 mm.

Key features

  • Double knuckle joint with spring pin in A (16.5 mm) or B (19.5 mm) clevis width
  • Knuckle pin TC1K040-23-54806, carbon steel, Ø12 d9
  • Limit switch bracket and dog fitting can be repositioned by removing the hex socket bolts
  • Dog fitting usable where mounting hole pitch is 97 mm
  • TBAP1-063 switch bracket for D-P7*R strong-field switches on TCKP1

Specifications

Applicable series TCK1, TCK2, TCKP1 (bore 50, 63 mm)
Knuckle material Cast iron
Bracket material Rolled steel
Pin material Carbon steel
Weight Knuckle 0.28 kg, LS bracket 0.22 kg, dog 0.12 kg
Source TPC Mechatronics catalog 72. TCK1_seires_220715_.pdf, p. 343-345
TCKA40-18-206A Item: Double knuckle joint, A width | Series: TCK | Fits: TCK1A/TCK2A/TCKP1A 50, 63
TCKB40-18-207A Item: Double knuckle joint, B width | Series: TCK | Fits: TCK1B/TCK2B/TCKP1B 50, 63
Cylinder AccessoriesTPC Mechatronics
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TPC TCK1 / TCK2 / TCKP1 Clamp Cylinder Accessories

Brand TPC Mechatronics·Cylinder Accessories

Available part numbers (2)

TCKA40-18-206A, TCKB40-18-207A

How to order

Send the TPC Mechatronics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TCKA40-18-206AItem: Double knuckle joint, A width | Series: TCK | Fits: TCK1A/TCK2A/TCKP1A 50, 63
TCKB40-18-207AItem: Double knuckle joint, B width | Series: TCK | Fits: TCK1B/TCK2B/TCKP1B 50, 63
