TPC TCM3 Cylinder Brackets, Knuckles, Pins & Rod Packings

TPC TCM3 Cylinder Brackets, Knuckles, Pins & Rod Packings

Mounting brackets, knuckle joints, pins, auto switch bands and replacement rod packings for TPC TCM3 series compact cylinders, bore 20-40 mm.

Key features

  • Foot, flange, clevis and trunnion brackets ordered separately (foot ordered as L ships 2 pcs)
  • Integrated clevis brackets TCM-E020B / E032B for TCM3E, supplied with pin and snap ring
  • Single (TI) and double (TY) knuckle joints; ordered with cylinder as I / Y they ship unassembled
  • TBM2 bands mount D-C73K / D-C73TN auto switches to the round tube
  • Replaceable urethane rod packing TCM3xx-RP; NBR rod packing SORA for non-rotating K types

Specifications

Series TCM3, TCM3W, TCM3K, TCM3KW, TCM3R, TCM3RK
Bore range 20-40 mm
Knuckle material Rolled steel plate (020/032), free-cutting steel / cast iron (040)
Pin material Carbon steel
Rod packing material Urethane (RP), NBR (SORA)
Source TPC Mechatronics catalog TCM3 series (all options) 230217, p. 2, 7, 13, 18-21, 52, 61
TCM320-RP Item: Rod packing (urethane) | For bore: 20 mm | Detail: TCM3/W/R/KW spare
TCM325-RP Item: Rod packing (urethane) | For bore: 25 mm | Detail: TCM3/W/R/KW spare
TCM332-RP Item: Rod packing (urethane) | For bore: 32 mm | Detail: TCM3/W/R/KW spare
TCM340-RP Item: Rod packing (urethane) | For bore: 40 mm | Detail: TCM3/W/R/KW spare
SORA-10 Item: Rod packing (NBR) | For bore: 20-25 mm | Detail: TCM3K/KW/RK spare
SORA-12 Item: Rod packing (NBR) | For bore: 32 mm | Detail: TCM3K/KW/RK spare
SORA-16 Item: Rod packing (NBR) | For bore: 40 mm | Detail: TCM3K/KW/RK spare
