WON ST Anti-Creep Cross Roller Table WRGU-AC Series

WON ST Anti-Creep Cross Roller Table WRGU-AC Series

Cross roller table unit using anti-creep cross roller guide ways with a rack and pinion cage that prevents cage drift, for high acceleration and vertical-axis applications.

Key features

  • Rack and pinion anti-creep cage prevents cage drift
  • Resin cage for quiet, smooth running
  • Suitable for high acceleration and vertical axes
  • Width tolerance +/-0.1 mm

Specifications

Cage Anti-creep (AC2)
Width tolerance +/-0.1 mm
WRGU3055AC2 Max. stroke: 24 mm | Width W: 60 mm | Height M: 28 mm | Length L: 55 mm | Mass: 0.57 kg | C (dynamic): 6.53 kN | C0 (static): 9.37 kN
WRGU3080AC2 Max. stroke: 55 mm | Width W: 60 mm | Height M: 28 mm | Length L: 80 mm | Mass: 0.80 kg | C (dynamic): 8.20 kN | C0 (static): 12.50 kN
WRGU3105AC2 Max. stroke: 67 mm | Width W: 60 mm | Height M: 28 mm | Length L: 105 mm | Mass: 1.03 kg | C (dynamic): 11.27 kN | C0 (static): 18.75 kN
WRGU3130AC2 Max. stroke: 78 mm | Width W: 60 mm | Height M: 28 mm | Length L: 130 mm | Mass: 1.26 kg | C (dynamic): 14.12 kN | C0 (static): 25.00 kN
WRGU3155AC2 Max. stroke: 90 mm | Width W: 60 mm | Height M: 28 mm | Length L: 155 mm | Mass: 1.49 kg | C (dynamic): 16.81 kN | C0 (static): 31.25 kN
WRGU3180AC2 Max. stroke: 102 mm | Width W: 60 mm | Height M: 28 mm | Length L: 180 mm | Mass: 1.72 kg | C (dynamic): 19.38 kN | C0 (static): 37.50 kN
WRGU3205AC2 Max. stroke: 113 mm | Width W: 60 mm | Height M: 28 mm | Length L: 205 mm | Mass: 1.95 kg | C (dynamic): 21.86 kN | C0 (static): 43.75 kN
WRGU6110AC2 Max. stroke: 53 mm | Width W: 100 mm | Height M: 45 mm | Length L: 110 mm | Mass: 3.2 kg | C (dynamic): 28.9 kN | C0 (static): 39.0 kN
WRGU6160AC2 Max. stroke: 78 mm | Width W: 100 mm | Height M: 45 mm | Length L: 160 mm | Mass: 4.6 kg | C (dynamic): 43.2 kN | C0 (static): 65.0 kN
WRGU6210AC2 Max. stroke: 140 mm | Width W: 100 mm | Height M: 45 mm | Length L: 210 mm | Mass: 6.0 kg | C (dynamic): 49.9 kN | C0 (static): 78.0 kN
WRGU6260AC2 Max. stroke: 165 mm | Width W: 100 mm | Height M: 45 mm | Length L: 260 mm | Mass: 7.4 kg | C (dynamic): 62.5 kN | C0 (static): 104.0 kN
WRGU6310AC2 Max. stroke: 190 mm | Width W: 100 mm | Height M: 45 mm | Length L: 310 mm | Mass: 8.7 kg | C (dynamic): 74.4 kN | C0 (static): 130.0 kN
WRGU6360AC2 Max. stroke: 252 mm | Width W: 100 mm | Height M: 45 mm | Length L: 360 mm | Mass: 10.1 kg | C (dynamic): 80.1 kN | C0 (static): 143.0 kN
WRGU6410AC2 Max. stroke: 296 mm | Width W: 100 mm | Height M: 45 mm | Length L: 410 mm | Mass: 11.5 kg | C (dynamic): 85.7 kN | C0 (static): 156.0 kN
Cross Roller GuidesWON ST
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WON ST Anti-Creep Cross Roller Table WRGU-AC Series

Brand WON ST·Cross Roller Guides

Available part numbers (14)

WRGU3055AC2, WRGU3080AC2, WRGU3105AC2, WRGU3130AC2, WRGU3155AC2, WRGU3180AC2, WRGU3205AC2, WRGU6110AC2, WRGU6160AC2, WRGU6210AC2 + 4 more — see full table ↓

How to order

Send the WON ST part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WRGU3055AC2Max. stroke: 24 mm | Width W: 60 mm | Height M: 28 mm | Length L: 55 mm | Mass: 0.57 kg | C (dynamic): 6.53 kN | C0 (static): 9.37 kN
WRGU3080AC2Max. stroke: 55 mm | Width W: 60 mm | Height M: 28 mm | Length L: 80 mm | Mass: 0.80 kg | C (dynamic): 8.20 kN | C0 (static): 12.50 kN
WRGU3105AC2Max. stroke: 67 mm | Width W: 60 mm | Height M: 28 mm | Length L: 105 mm | Mass: 1.03 kg | C (dynamic): 11.27 kN | C0 (static): 18.75 kN
WRGU3130AC2Max. stroke: 78 mm | Width W: 60 mm | Height M: 28 mm | Length L: 130 mm | Mass: 1.26 kg | C (dynamic): 14.12 kN | C0 (static): 25.00 kN
WRGU3155AC2Max. stroke: 90 mm | Width W: 60 mm | Height M: 28 mm | Length L: 155 mm | Mass: 1.49 kg | C (dynamic): 16.81 kN | C0 (static): 31.25 kN
WRGU3180AC2Max. stroke: 102 mm | Width W: 60 mm | Height M: 28 mm | Length L: 180 mm | Mass: 1.72 kg | C (dynamic): 19.38 kN | C0 (static): 37.50 kN
WRGU3205AC2Max. stroke: 113 mm | Width W: 60 mm | Height M: 28 mm | Length L: 205 mm | Mass: 1.95 kg | C (dynamic): 21.86 kN | C0 (static): 43.75 kN
WRGU6110AC2Max. stroke: 53 mm | Width W: 100 mm | Height M: 45 mm | Length L: 110 mm | Mass: 3.2 kg | C (dynamic): 28.9 kN | C0 (static): 39.0 kN
WRGU6160AC2Max. stroke: 78 mm | Width W: 100 mm | Height M: 45 mm | Length L: 160 mm | Mass: 4.6 kg | C (dynamic): 43.2 kN | C0 (static): 65.0 kN
WRGU6210AC2Max. stroke: 140 mm | Width W: 100 mm | Height M: 45 mm | Length L: 210 mm | Mass: 6.0 kg | C (dynamic): 49.9 kN | C0 (static): 78.0 kN
WRGU6260AC2Max. stroke: 165 mm | Width W: 100 mm | Height M: 45 mm | Length L: 260 mm | Mass: 7.4 kg | C (dynamic): 62.5 kN | C0 (static): 104.0 kN
WRGU6310AC2Max. stroke: 190 mm | Width W: 100 mm | Height M: 45 mm | Length L: 310 mm | Mass: 8.7 kg | C (dynamic): 74.4 kN | C0 (static): 130.0 kN
WRGU6360AC2Max. stroke: 252 mm | Width W: 100 mm | Height M: 45 mm | Length L: 360 mm | Mass: 10.1 kg | C (dynamic): 80.1 kN | C0 (static): 143.0 kN
WRGU6410AC2Max. stroke: 296 mm | Width W: 100 mm | Height M: 45 mm | Length L: 410 mm | Mass: 11.5 kg | C (dynamic): 85.7 kN | C0 (static): 156.0 kN
