WON ST Cross Roller Table WRGT-B Series

WON ST Cross Roller Table WRGT-B Series

Compact cross roller table unit (B type, counterbored base mounting holes) with cross roller guide ways between a precision table and base for rigid finite linear motion.

Key features

  • Compact, highly precise and rigid unit for finite linear motion
  • Cross roller guide ways mounted between a precision table and base
  • Pre-filled with lithium grease

Specifications

Lubrication Pre-filled with lithium grease
WRGT1025B Max. stroke: 12 mm | Width W: 20 mm | Height M: 8 mm | Length L: 25 mm | C (dynamic): 0.46 kN | C0 (static): 0.61 kN
WRGT1035B Max. stroke: 18 mm | Width W: 20 mm | Height M: 8 mm | Length L: 35 mm | C (dynamic): 0.63 kN | C0 (static): 0.92 kN
WRGT1045B Max. stroke: 25 mm | Width W: 20 mm | Height M: 8 mm | Length L: 45 mm | C (dynamic): 0.95 kN | C0 (static): 1.53 kN
WRGT1055B Max. stroke: 32 mm | Width W: 20 mm | Height M: 8 mm | Length L: 55 mm | C (dynamic): 1.09 kN | C0 (static): 1.84 kN
WRGT1065B Max. stroke: 40 mm | Width W: 20 mm | Height M: 8 mm | Length L: 65 mm | C (dynamic): 1.23 kN | C0 (static): 2.14 kN
WRGT1075B Max. stroke: 45 mm | Width W: 20 mm | Height M: 8 mm | Length L: 75 mm | C (dynamic): 1.50 kN | C0 (static): 2.75 kN
WRGT1085B Max. stroke: 50 mm | Width W: 20 mm | Height M: 8 mm | Length L: 85 mm | C (dynamic): 1.63 kN | C0 (static): 3.06 kN
WRGT2035B Max. stroke: 18 mm | Width W: 30 mm | Height M: 12 mm | Length L: 35 mm | C (dynamic): 0.84 kN | C0 (static): 1.08 kN
WRGT2050B Max. stroke: 30 mm | Width W: 30 mm | Height M: 12 mm | Length L: 50 mm | C (dynamic): 1.17 kN | C0 (static): 1.63 kN
WRGT2065B Max. stroke: 40 mm | Width W: 30 mm | Height M: 12 mm | Length L: 65 mm | C (dynamic): 1.46 kN | C0 (static): 2.17 kN
WRGT2080B Max. stroke: 50 mm | Width W: 30 mm | Height M: 12 mm | Length L: 80 mm | C (dynamic): 2.01 kN | C0 (static): 3.25 kN
WRGT2095B Max. stroke: 60 mm | Width W: 30 mm | Height M: 12 mm | Length L: 95 mm | C (dynamic): 2.27 kN | C0 (static): 3.79 kN
WRGT2110B Max. stroke: 70 mm | Width W: 30 mm | Height M: 12 mm | Length L: 110 mm | C (dynamic): 2.52 kN | C0 (static): 4.34 kN
WRGT2125B Max. stroke: 80 mm | Width W: 30 mm | Height M: 12 mm | Length L: 125 mm | C (dynamic): 2.76 kN | C0 (static): 4.88 kN
WRGT3055B Max. stroke: 30 mm | Width W: 40 mm | Height M: 16 mm | Length L: 55 mm | C (dynamic): 2.71 kN | C0 (static): 3.67 kN
WRGT3080B Max. stroke: 45 mm | Width W: 40 mm | Height M: 16 mm | Length L: 80 mm | C (dynamic): 4.06 kN | C0 (static): 6.11 kN
WRGT3105B Max. stroke: 60 mm | Width W: 40 mm | Height M: 16 mm | Length L: 105 mm | C (dynamic): 4.68 kN | C0 (static): 7.33 kN
WRGT3130B Max. stroke: 75 mm | Width W: 40 mm | Height M: 16 mm | Length L: 130 mm | C (dynamic): 5.86 kN | C0 (static): 9.78 kN
WRGT3155B Max. stroke: 90 mm | Width W: 40 mm | Height M: 16 mm | Length L: 155 mm | C (dynamic): 6.98 kN | C0 (static): 12.2 kN
WRGT3180B Max. stroke: 105 mm | Width W: 40 mm | Height M: 16 mm | Length L: 180 mm | C (dynamic): 8.05 kN | C0 (static): 14.7 kN
WRGT3205B Max. stroke: 130 mm | Width W: 40 mm | Height M: 16 mm | Length L: 205 mm | C (dynamic): 8.57 kN | C0 (static): 15.9 kN
Cross Roller GuidesWON ST
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WON ST Cross Roller Table WRGT-B Series

Brand WON ST·Cross Roller Guides

Available part numbers (21)

WRGT1025B, WRGT1035B, WRGT1045B, WRGT1055B, WRGT1065B, WRGT1075B, WRGT1085B, WRGT2035B, WRGT2050B, WRGT2065B + 11 more — see full table ↓

How to order

Send the WON ST part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WRGT1025BMax. stroke: 12 mm | Width W: 20 mm | Height M: 8 mm | Length L: 25 mm | C (dynamic): 0.46 kN | C0 (static): 0.61 kN
WRGT1035BMax. stroke: 18 mm | Width W: 20 mm | Height M: 8 mm | Length L: 35 mm | C (dynamic): 0.63 kN | C0 (static): 0.92 kN
WRGT1045BMax. stroke: 25 mm | Width W: 20 mm | Height M: 8 mm | Length L: 45 mm | C (dynamic): 0.95 kN | C0 (static): 1.53 kN
WRGT1055BMax. stroke: 32 mm | Width W: 20 mm | Height M: 8 mm | Length L: 55 mm | C (dynamic): 1.09 kN | C0 (static): 1.84 kN
WRGT1065BMax. stroke: 40 mm | Width W: 20 mm | Height M: 8 mm | Length L: 65 mm | C (dynamic): 1.23 kN | C0 (static): 2.14 kN
WRGT1075BMax. stroke: 45 mm | Width W: 20 mm | Height M: 8 mm | Length L: 75 mm | C (dynamic): 1.50 kN | C0 (static): 2.75 kN
WRGT1085BMax. stroke: 50 mm | Width W: 20 mm | Height M: 8 mm | Length L: 85 mm | C (dynamic): 1.63 kN | C0 (static): 3.06 kN
WRGT2035BMax. stroke: 18 mm | Width W: 30 mm | Height M: 12 mm | Length L: 35 mm | C (dynamic): 0.84 kN | C0 (static): 1.08 kN
WRGT2050BMax. stroke: 30 mm | Width W: 30 mm | Height M: 12 mm | Length L: 50 mm | C (dynamic): 1.17 kN | C0 (static): 1.63 kN
WRGT2065BMax. stroke: 40 mm | Width W: 30 mm | Height M: 12 mm | Length L: 65 mm | C (dynamic): 1.46 kN | C0 (static): 2.17 kN
WRGT2080BMax. stroke: 50 mm | Width W: 30 mm | Height M: 12 mm | Length L: 80 mm | C (dynamic): 2.01 kN | C0 (static): 3.25 kN
WRGT2095BMax. stroke: 60 mm | Width W: 30 mm | Height M: 12 mm | Length L: 95 mm | C (dynamic): 2.27 kN | C0 (static): 3.79 kN
WRGT2110BMax. stroke: 70 mm | Width W: 30 mm | Height M: 12 mm | Length L: 110 mm | C (dynamic): 2.52 kN | C0 (static): 4.34 kN
WRGT2125BMax. stroke: 80 mm | Width W: 30 mm | Height M: 12 mm | Length L: 125 mm | C (dynamic): 2.76 kN | C0 (static): 4.88 kN
WRGT3055BMax. stroke: 30 mm | Width W: 40 mm | Height M: 16 mm | Length L: 55 mm | C (dynamic): 2.71 kN | C0 (static): 3.67 kN
WRGT3080BMax. stroke: 45 mm | Width W: 40 mm | Height M: 16 mm | Length L: 80 mm | C (dynamic): 4.06 kN | C0 (static): 6.11 kN
WRGT3105BMax. stroke: 60 mm | Width W: 40 mm | Height M: 16 mm | Length L: 105 mm | C (dynamic): 4.68 kN | C0 (static): 7.33 kN
WRGT3130BMax. stroke: 75 mm | Width W: 40 mm | Height M: 16 mm | Length L: 130 mm | C (dynamic): 5.86 kN | C0 (static): 9.78 kN
WRGT3155BMax. stroke: 90 mm | Width W: 40 mm | Height M: 16 mm | Length L: 155 mm | C (dynamic): 6.98 kN | C0 (static): 12.2 kN
WRGT3180BMax. stroke: 105 mm | Width W: 40 mm | Height M: 16 mm | Length L: 180 mm | C (dynamic): 8.05 kN | C0 (static): 14.7 kN
WRGT3205BMax. stroke: 130 mm | Width W: 40 mm | Height M: 16 mm | Length L: 205 mm | C (dynamic): 8.57 kN | C0 (static): 15.9 kN
