WON ST Cross Roller Table WRGU Series

WON ST Cross Roller Table WRGU Series

Cross roller table unit with integrated table and base guided by cross roller guide ways, providing compact, precise and rigid finite linear motion.

Key features

  • Cross roller table unit with side attachment taps
  • Sizes 1 to 9 (table width 30 to 145 mm)
  • Pre-filled with lithium grease

Specifications

Lubrication Pre-filled with lithium grease
WRGU1025 Max. stroke: 12 mm | Width W: 30 mm | Height M: 17 mm | Length L: 25 mm | Mass: 0.08 kg | C (dynamic): 0.46 kN | C0 (static): 0.61 kN
WRGU1035 Max. stroke: 18 mm | Width W: 30 mm | Height M: 17 mm | Length L: 35 mm | Mass: 0.11 kg | C (dynamic): 0.63 kN | C0 (static): 0.92 kN
WRGU1045 Max. stroke: 25 mm | Width W: 30 mm | Height M: 17 mm | Length L: 45 mm | Mass: 0.15 kg | C (dynamic): 0.95 kN | C0 (static): 1.53 kN
WRGU1055 Max. stroke: 32 mm | Width W: 30 mm | Height M: 17 mm | Length L: 55 mm | Mass: 0.18 kg | C (dynamic): 1.09 kN | C0 (static): 1.84 kN
WRGU1065 Max. stroke: 40 mm | Width W: 30 mm | Height M: 17 mm | Length L: 65 mm | Mass: 0.21 kg | C (dynamic): 1.23 kN | C0 (static): 2.14 kN
WRGU1075 Max. stroke: 45 mm | Width W: 30 mm | Height M: 17 mm | Length L: 75 mm | Mass: 0.24 kg | C (dynamic): 1.50 kN | C0 (static): 2.75 kN
WRGU1085 Max. stroke: 50 mm | Width W: 30 mm | Height M: 17 mm | Length L: 85 mm | Mass: 0.27 kg | C (dynamic): 1.63 kN | C0 (static): 3.06 kN
WRGU2035 Max. stroke: 18 mm | Width W: 40 mm | Height M: 21 mm | Length L: 35 mm | Mass: 0.2 kg | C (dynamic): 0.84 kN | C0 (static): 1.08 kN
WRGU2050 Max. stroke: 30 mm | Width W: 40 mm | Height M: 21 mm | Length L: 50 mm | Mass: 0.26 kg | C (dynamic): 1.17 kN | C0 (static): 1.63 kN
WRGU2065 Max. stroke: 40 mm | Width W: 40 mm | Height M: 21 mm | Length L: 65 mm | Mass: 0.34 kg | C (dynamic): 1.46 kN | C0 (static): 2.17 kN
WRGU2080 Max. stroke: 50 mm | Width W: 40 mm | Height M: 21 mm | Length L: 80 mm | Mass: 0.42 kg | C (dynamic): 2.01 kN | C0 (static): 3.25 kN
WRGU2095 Max. stroke: 60 mm | Width W: 40 mm | Height M: 21 mm | Length L: 95 mm | Mass: 0.5 kg | C (dynamic): 2.27 kN | C0 (static): 3.79 kN
WRGU2110 Max. stroke: 70 mm | Width W: 40 mm | Height M: 21 mm | Length L: 110 mm | Mass: 0.58 kg | C (dynamic): 2.52 kN | C0 (static): 4.34 kN
WRGU2125 Max. stroke: 80 mm | Width W: 40 mm | Height M: 21 mm | Length L: 125 mm | Mass: 0.66 kg | C (dynamic): 2.76 kN | C0 (static): 4.88 kN
WRGU3055 Max. stroke: 30 mm | Width W: 60 mm | Height M: 28 mm | Length L: 55 mm | Mass: 0.57 kg | C (dynamic): 2.71 kN | C0 (static): 3.67 kN
WRGU3080 Max. stroke: 45 mm | Width W: 60 mm | Height M: 28 mm | Length L: 80 mm | Mass: 0.8 kg | C (dynamic): 4.06 kN | C0 (static): 6.11 kN
WRGU3105 Max. stroke: 60 mm | Width W: 60 mm | Height M: 28 mm | Length L: 105 mm | Mass: 1.03 kg | C (dynamic): 4.68 kN | C0 (static): 7.33 kN
WRGU3130 Max. stroke: 75 mm | Width W: 60 mm | Height M: 28 mm | Length L: 130 mm | Mass: 1.26 kg | C (dynamic): 5.86 kN | C0 (static): 9.78 kN
WRGU3155 Max. stroke: 90 mm | Width W: 60 mm | Height M: 28 mm | Length L: 155 mm | Mass: 1.49 kg | C (dynamic): 6.98 kN | C0 (static): 12.2 kN
WRGU3180 Max. stroke: 105 mm | Width W: 60 mm | Height M: 28 mm | Length L: 180 mm | Mass: 1.72 kg | C (dynamic): 8.05 kN | C0 (static): 14.7 kN
WRGU3205 Max. stroke: 130 mm | Width W: 60 mm | Height M: 28 mm | Length L: 205 mm | Mass: 1.95 kg | C (dynamic): 8.57 kN | C0 (static): 15.9 kN
WRGU4085 Max. stroke: 50 mm | Width W: 80 mm | Height M: 35 mm | Length L: 85 mm | Mass: 1.5 kg | C (dynamic): 5.92 kN | C0 (static): 8.10 kN
WRGU4125 Max. stroke: 75 mm | Width W: 80 mm | Height M: 35 mm | Length L: 125 mm | Mass: 2.3 kg | C (dynamic): 8.85 kN | C0 (static): 13.5 kN
WRGU4165 Max. stroke: 105 mm | Width W: 80 mm | Height M: 35 mm | Length L: 165 mm | Mass: 3.1 kg | C (dynamic): 11.5 kN | C0 (static): 18.9 kN
WRGU4205 Max. stroke: 135 mm | Width W: 80 mm | Height M: 35 mm | Length L: 205 mm | Mass: 3.8 kg | C (dynamic): 14.0 kN | C0 (static): 24.3 kN
WRGU4245 Max. stroke: 155 mm | Width W: 80 mm | Height M: 35 mm | Length L: 245 mm | Mass: 4.6 kg | C (dynamic): 16.4 kN | C0 (static): 29.7 kN
WRGU4285 Max. stroke: 185 mm | Width W: 80 mm | Height M: 35 mm | Length L: 285 mm | Mass: 5.3 kg | C (dynamic): 18.7 kN | C0 (static): 35.1 kN
WRGU6110 Max. stroke: 60 mm | Width W: 100 mm | Height M: 45 mm | Length L: 110 mm | Mass: 3.2 kg | C (dynamic): 16.4 kN | C0 (static): 22.7 kN
WRGU6160 Max. stroke: 95 mm | Width W: 100 mm | Height M: 45 mm | Length L: 160 mm | Mass: 4.6 kg | C (dynamic): 20.5 kN | C0 (static): 30.2 kN
WRGU6210 Max. stroke: 130 mm | Width W: 100 mm | Height M: 45 mm | Length L: 210 mm | Mass: 6.0 kg | C (dynamic): 28.2 kN | C0 (static): 45.4 kN
WRGU6260 Max. stroke: 165 mm | Width W: 100 mm | Height M: 45 mm | Length L: 260 mm | Mass: 7.4 kg | C (dynamic): 35.4 kN | C0 (static): 60.5 kN
WRGU6310 Max. stroke: 200 mm | Width W: 100 mm | Height M: 45 mm | Length L: 310 mm | Mass: 8.7 kg | C (dynamic): 38.8 kN | C0 (static): 68.0 kN
WRGU6360 Max. stroke: 235 mm | Width W: 100 mm | Height M: 45 mm | Length L: 360 mm | Mass: 10.1 kg | C (dynamic): 45.4 kN | C0 (static): 83.2 kN
WRGU6410 Max. stroke: 265 mm | Width W: 100 mm | Height M: 45 mm | Length L: 410 mm | Mass: 11.5 kg | C (dynamic): 51.7 kN | C0 (static): 98.3 kN
WRGU9210 Max. stroke: 130 mm | Width W: 145 mm | Height M: 60 mm | Length L: 210 mm | Mass: 12.0 kg | C (dynamic): 52.3 kN | C0 (static): 75.8 kN
WRGU9310 Max. stroke: 180 mm | Width W: 145 mm | Height M: 60 mm | Length L: 310 mm | Mass: 17.6 kg | C (dynamic): 81.1 kN | C0 (static): 133 kN
WRGU9410 Max. stroke: 350 mm | Width W: 145 mm | Height M: 60 mm | Length L: 410 mm | Mass: 23.2 kg | C (dynamic): 81.1 kN | C0 (static): 133 kN
WRGU9510 Max. stroke: 450 mm | Width W: 145 mm | Height M: 60 mm | Length L: 510 mm | Mass: 28.8 kg | C (dynamic): 98.7 kN | C0 (static): 171 kN
WRGU9610 Max. stroke: 550 mm | Width W: 145 mm | Height M: 60 mm | Length L: 610 mm | Mass: 34.4 kg | C (dynamic): 115 kN | C0 (static): 209 kN
WRGU9710 Max. stroke: 650 mm | Width W: 145 mm | Height M: 60 mm | Length L: 710 mm | Mass: 40.0 kg | C (dynamic): 131 kN | C0 (static): 246 kN
WRGU9810 Max. stroke: 750 mm | Width W: 145 mm | Height M: 60 mm | Length L: 810 mm | Mass: 45.6 kg | C (dynamic): 139 kN | C0 (static): 265 kN
WRGU9910 Max. stroke: 850 mm | Width W: 145 mm | Height M: 60 mm | Length L: 910 mm | Mass: 51.2 kg | C (dynamic): 155 kN | C0 (static): 303 kN
WRGU91010 Max. stroke: 950 mm | Width W: 145 mm | Height M: 60 mm | Length L: 1010 mm | Mass: 56.8 kg | C (dynamic): 169 kN | C0 (static): 341 kN
Cross Roller GuidesWON ST
43 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WON ST Cross Roller Table WRGU Series

Brand WON ST·Cross Roller Guides

Available part numbers (43)

WRGU1025, WRGU1035, WRGU1045, WRGU1055, WRGU1065, WRGU1075, WRGU1085, WRGU2035, WRGU2050, WRGU2065 + 33 more — see full table ↓
