• WON ST Shaft End Support WK Series
1 1

WON ST Shaft End Support WK Series

WON ST Shaft End Support WK Series

Aluminum shaft end support that holds the end of a linear motion shaft without special machining and bolts to a flat surface.

Key features

  • Aluminum AL6061 body
  • Slit clamp with fastening bolt for the shaft
  • Two mounting bolt holes for plane mounting

Specifications

Material Aluminum AL6061
Mounting Plane
WK10 Shaft diameter d: 10 mm | Shaft center height H: 20 mm | E: 21 mm | Width W: 42 mm | Length L: 14 mm | Height F: 32.8 mm | Base thickness T: 6 mm | P: 18 mm | Mounting pitch B: 32 mm | Mounting bolt S1: M5 | Fastening bolt S2: M4
WK12 Shaft diameter d: 12 mm | Shaft center height H: 23 mm | E: 21 mm | Width W: 42 mm | Length L: 14 mm | Height F: 38 mm | Base thickness T: 6 mm | P: 20 mm | Mounting pitch B: 32 mm | Mounting bolt S1: M5 | Fastening bolt S2: M4
WK13 Shaft diameter d: 13 mm | Shaft center height H: 23 mm | E: 21 mm | Width W: 42 mm | Length L: 14 mm | Height F: 38 mm | Base thickness T: 6 mm | P: 20 mm | Mounting pitch B: 32 mm | Mounting bolt S1: M5 | Fastening bolt S2: M4
WK16 Shaft diameter d: 16 mm | Shaft center height H: 27 mm | E: 24 mm | Width W: 48 mm | Length L: 16 mm | Height F: 44 mm | Base thickness T: 8 mm | P: 25 mm | Mounting pitch B: 38 mm | Mounting bolt S1: M5 | Fastening bolt S2: M4
WK20 Shaft diameter d: 20 mm | Shaft center height H: 31 mm | E: 30 mm | Width W: 60 mm | Length L: 20 mm | Height F: 51 mm | Base thickness T: 10 mm | P: 30 mm | Mounting pitch B: 45 mm | Mounting bolt S1: M6 | Fastening bolt S2: M5
WK25 Shaft diameter d: 25 mm | Shaft center height H: 35 mm | E: 35 mm | Width W: 70 mm | Length L: 24 mm | Height F: 60 mm | Base thickness T: 12 mm | P: 38 mm | Mounting pitch B: 56 mm | Mounting bolt S1: M6 | Fastening bolt S2: M6
WK30 Shaft diameter d: 30 mm | Shaft center height H: 42 mm | E: 42 mm | Width W: 84 mm | Length L: 28 mm | Height F: 70 mm | Base thickness T: 12 mm | P: 44 mm | Mounting pitch B: 64 mm | Mounting bolt S1: M8 | Fastening bolt S2: M6
WK35 Shaft diameter d: 35 mm | Shaft center height H: 50 mm | E: 49 mm | Width W: 98 mm | Length L: 32 mm | Height F: 82 mm | Base thickness T: 15 mm | P: 50 mm | Mounting pitch B: 74 mm | Mounting bolt S1: M10 | Fastening bolt S2: M8
WK40 Shaft diameter d: 40 mm | Shaft center height H: 60 mm | E: 57 mm | Width W: 114 mm | Length L: 36 mm | Height F: 96 mm | Base thickness T: 15 mm | P: 60 mm | Mounting pitch B: 90 mm | Mounting bolt S1: M10 | Fastening bolt S2: M8
Shaft SupportsWON ST
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →
