Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| STF32 | Rail width W: 26 mm | Max. length L: 6000 mm | c: 10 mm | Shaft dia. ds: 6 mm | Rail height h: 10 mm | h1: 5 mm | Mounting hole d x D x p: 6.5 x 12 x 6.5 mm | G: 25 mm | Hole pitch P: 125 mm | ||
| STF52 | Rail width W: 42 mm | Max. length L: 6000 mm | c: 16 mm | Shaft dia. ds: 10 mm | Rail height h: 18 mm | h1: 9 mm | Mounting hole d x D x p: 11 x 19 x 13 mm | G: 25 mm | Hole pitch P: 250 mm |
Need a different model, or a part not listed here? Send us your parts list →
