WON ST Track Roller Guide TS Series (Outside Type)

WON ST Track Roller Guide TS Series (Outside Type)

Outside-type track roller guide consisting of an aluminum guide rail with inserted heat-treated shafts and a roller block, supplied with fixture or clearance adjustable block.

Key features

  • Four-direction load capacity (radial and thrust) via multi-row angular contact ball bearing rollers
  • Max. velocity 10 m/s, max. acceleration 50 m/s2
  • Low noise: no rolling-element recirculation
  • Fixture block or clearance adjustable block (eccentric roller) available
  • TS32H and larger use a hollow rail

Specifications

Block types Fixture block (B) / Clearance adjustable block (BC)
Max. rail length 6000 mm
TS20 Block width W: 60 mm | Rail width W1: 20 mm | Block length L1: 110 mm | Height H: 25.5 mm | Rail shaft dia. ds: 4 mm | Cy: 1860 N | Coy: 1600 N | Cz: 870 N | Coz: 760 N | Mx: 7.0 N·m | My: 21.8 N·m | Mz: 46.7 N·m
TS25 Block width W: 85 mm | Rail width W1: 25 mm | Block length L1: 125 mm | Height H: 34.1 mm | Rail shaft dia. ds: 6 mm | Cy: 5960 N | Coy: 4560 N | Cz: 2850 N | Coz: 2200 N | Mx: 27.1 N·m | My: 78.4 N·m | Mz: 164.0 N·m
TS32H Block width W: 90 mm | Rail width W1: 32 mm | Block length L1: 145 mm | Height H: 38.5 mm | Rail shaft dia. ds: 6 mm | Cy: 5960 N | Coy: 4560 N | Cz: 2850 N | Coz: 2200 N | Mx: 37.1 N·m | My: 92.6 N·m | Mz: 193.8 N·m
TS42H Block width W: 120 mm | Rail width W1: 42 mm | Block length L1: 170 mm | Height H: 47.5 mm | Rail shaft dia. ds: 10 mm | Cy: 13930 N | Coy: 10200 N | Cz: 6620 N | Coz: 4920 N | Mx: 106.0 N·m | My: 231 N·m | Mz: 487 N·m
TS52H Block width W: 130 mm | Rail width W1: 52 mm | Block length L1: 205 mm | Height H: 60 mm | Rail shaft dia. ds: 10 mm | Cy: 13930 N | Coy: 10200 N | Cz: 6620 N | Coz: 4920 N | Mx: 139.0 N·m | My: 298 N·m | Mz: 627 N·m
Track Roller GuidesWON ST
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WON ST Track Roller Guide TS Series (Outside Type)

Brand WON ST·Track Roller Guides

Available part numbers (5)

TS20, TS25, TS32H, TS42H, TS52H

How to order

Send the WON ST part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TS20Block width W: 60 mm | Rail width W1: 20 mm | Block length L1: 110 mm | Height H: 25.5 mm | Rail shaft dia. ds: 4 mm | Cy: 1860 N | Coy: 1600 N | Cz: 870 N | Coz: 760 N | Mx: 7.0 N·m | My: 21.8 N·m | Mz: 46.7 N·m
TS25Block width W: 85 mm | Rail width W1: 25 mm | Block length L1: 125 mm | Height H: 34.1 mm | Rail shaft dia. ds: 6 mm | Cy: 5960 N | Coy: 4560 N | Cz: 2850 N | Coz: 2200 N | Mx: 27.1 N·m | My: 78.4 N·m | Mz: 164.0 N·m
TS32HBlock width W: 90 mm | Rail width W1: 32 mm | Block length L1: 145 mm | Height H: 38.5 mm | Rail shaft dia. ds: 6 mm | Cy: 5960 N | Coy: 4560 N | Cz: 2850 N | Coz: 2200 N | Mx: 37.1 N·m | My: 92.6 N·m | Mz: 193.8 N·m
TS42HBlock width W: 120 mm | Rail width W1: 42 mm | Block length L1: 170 mm | Height H: 47.5 mm | Rail shaft dia. ds: 10 mm | Cy: 13930 N | Coy: 10200 N | Cz: 6620 N | Coz: 4920 N | Mx: 106.0 N·m | My: 231 N·m | Mz: 487 N·m
TS52HBlock width W: 130 mm | Rail width W1: 52 mm | Block length L1: 205 mm | Height H: 60 mm | Rail shaft dia. ds: 10 mm | Cy: 13930 N | Coy: 10200 N | Cz: 6620 N | Coz: 4920 N | Mx: 139.0 N·m | My: 298 N·m | Mz: 627 N·m
