WOONYOUNG DC SSR with Self Heat Sink WYMS (50-500VDC, 5-40A)

WOONYOUNG DC SSR with Self Heat Sink WYMS (50-500VDC, 5-40A)

Integral DC SSR with self heat sink that can be mounted on DIN rail without an additional heat sink.

Key features

  • Integrated heat sink
  • DIN rail mountable
  • DC load switching

Specifications

Input voltage range 4-32 VDC
Output DC
Dielectric strength 1500 VAC / 1 min
Weight 0.4 kg
WYMS1C0505D4 Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C0510D4 Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 10 A | Contact voltage drop: 1.95 VDC
WYMS1C0520D4 Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 20 A | Contact voltage drop: 1.8 VDC
WYMS1C0530D4 Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 30 A | Contact voltage drop: 1.8 VDC
WYMS1C0540D4 Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 40 A | Contact voltage drop: 1.8 VDC
WYMS1C105D4 Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C110D4 Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 10 A | Contact voltage drop: 2.0 VDC
WYMS1C120D4 Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 20 A | Contact voltage drop: 2.0 VDC
WYMS1C130D4 Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 30 A | Contact voltage drop: 2.0 VDC
WYMS1C140D4 Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 40 A | Contact voltage drop: 2.0 VDC
WYMS1C205D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C210D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 10 A | Contact voltage drop: 1.95 VDC
WYMS1C220D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 20 A | Contact voltage drop: 1.8 VDC
WYMS1C505D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C510D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 10 A | Contact voltage drop: 1.95 VDC
WYMS1C520D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 20 A | Contact voltage drop: 1.8 VDC
WYMS1C530D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 30 A | Source: selection table p.50 only
WYMS1C540D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 40 A | Source: selection table p.50 only
Solid State RelaysWOONYOUNG
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WOONYOUNG DC SSR with Self Heat Sink WYMS (50-500VDC, 5-40A)

Brand WOONYOUNG·Solid State Relays

Available part numbers (18)

WYMS1C0505D4, WYMS1C0510D4, WYMS1C0520D4, WYMS1C0530D4, WYMS1C0540D4, WYMS1C105D4, WYMS1C110D4, WYMS1C120D4, WYMS1C130D4, WYMS1C140D4 + 8 more — see full table ↓

How to order

Send the WOONYOUNG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WYMS1C0505D4Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C0510D4Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 10 A | Contact voltage drop: 1.95 VDC
WYMS1C0520D4Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 20 A | Contact voltage drop: 1.8 VDC
WYMS1C0530D4Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 30 A | Contact voltage drop: 1.8 VDC
WYMS1C0540D4Rated voltage: 50 VDC | Voltage range: 10-50 VDC | Rated load current: 40 A | Contact voltage drop: 1.8 VDC
WYMS1C105D4Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C110D4Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 10 A | Contact voltage drop: 2.0 VDC
WYMS1C120D4Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 20 A | Contact voltage drop: 2.0 VDC
WYMS1C130D4Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 30 A | Contact voltage drop: 2.0 VDC
WYMS1C140D4Rated voltage: 100 VDC | Voltage range: 10-100 VDC | Rated load current: 40 A | Contact voltage drop: 2.0 VDC
WYMS1C205D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C210D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 10 A | Contact voltage drop: 1.95 VDC
WYMS1C220D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 20 A | Contact voltage drop: 1.8 VDC
WYMS1C505D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 5 A | Contact voltage drop: 2.0 VDC
WYMS1C510D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 10 A | Contact voltage drop: 1.95 VDC
WYMS1C520D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 20 A | Contact voltage drop: 1.8 VDC
WYMS1C530D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 30 A | Source: selection table p.50 only
WYMS1C540D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 40 A | Source: selection table p.50 only
