Woonyoung SP Series CP Type PFC Switching Power Supply, 1-Output, 600 W

Woonyoung SP Series CP Type PFC Switching Power Supply, 1-Output, 600 W

600 W enclosed AC-DC switching power supply with built-in PFC circuit, wide AC input and fan cooling for a single regulated DC output.

Key features

  • Built-in PFC circuit, power factor 0.9 typ
  • Wide AC input range 90-264 V
  • Over current, over voltage, over temperature and short circuit protection
  • Remote sensing and remote control functions
  • Built-in inrush current limiter

Specifications

Output type Single output
Output power 600 W
Input voltage AC 90-264 V
Cooling Fan cooling
Operating temperature 0 to +50 °C
Withstand voltage (input-output) AC 1,500 V 1 min
Functions Remote sensing, remote control
Weight 2.9 kg
WYSP-600S05CP Output power: 600 W | Output voltage: 5 V DC | Output current: 120.0 A | Input voltage: AC 90-264 V | Efficiency: 75% typ | Weight: 2.9 kg
WYSP-600S12CP Output power: 600 W | Output voltage: 12 V DC | Output current: 50.0 A | Input voltage: AC 90-264 V | Efficiency: 75% typ | Weight: 2.9 kg
WYSP-600S24CP Output power: 600 W | Output voltage: 24 V DC | Output current: 25.0 A | Input voltage: AC 90-264 V | Efficiency: 80% typ | Weight: 2.9 kg
WYSP-600S48CP Output power: 600 W | Output voltage: 48 V DC | Output current: 12.5 A | Input voltage: AC 90-264 V | Efficiency: 80% typ | Weight: 2.9 kg
Switching Power SuppliesWoonyoung
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung SP Series CP Type PFC Switching Power Supply, 1-Output, 600 W

Brand Woonyoung·Switching Power Supplies

Available part numbers (4)

WYSP-600S05CP, WYSP-600S12CP, WYSP-600S24CP, WYSP-600S48CP
