Woonyoung W00I2A Epoxy Earth Bushing for GIS, 25.8kV

Epoxy-cast earth bushing that provides an earth terminal for GIS and C-GIS, with special conductor-to-epoxy interface treatment to prevent gas leakage.

Key features

Earth terminal for GIS and C-GIS
Easy to install
Special conductor/epoxy interface treatment prevents gas leakage
Manufactured by automatic vacuum casting

Specifications

Operating voltage (max.)	25.8 kV
AC withstand voltage (60 Hz, 1 min)	60 kV
Lightning impulse withstand voltage	150 kV
Maximum system current	600 A / 200 A (two ratings printed)

W00I2A

Maximum system current: 600 A / 200 A | Operating voltage: 25.8 kV

Epoxy InsulatorsWoonyoung

1 product code available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung W00I2A Epoxy Earth Bushing for GIS, 25.8kV

Brand Woonyoung·Epoxy Insulators

Available part numbers (1)

W00I2A

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
