Woonyoung W24I5A High-Voltage Epoxy Mold Fuse Holder, 24kV, SF6 Gas

Epoxy-molded 24 kV power-fuse holder for protecting instrument transformers in SF6 switchgear, with externally replaceable fuse and built-in voltage sensor.

Key features

Power fuse can be replaced from outside
Built-in voltage detecting sensor shows whether the fuse has blown
Limits fuse temperature rise under increasing load
Good electrical and thermal characteristics
For use in SF6 gas
Manufactured by automatic pressure gelation (APG)

Specifications

Highest voltage for equipment (Um)	24 kV
Power-frequency withstand voltage (60 s)	50 kV
Lightning impulse withstand voltage (1.2/50 us)	125 kV
Voltage detecting sensor capacitance	15-30 pF
Power fuse current	1-2 A
Power fuse size	dia. 22 x 280 mm
Weight (approx.)	7 kg
Service condition	SF6 gas

W24I5A

Weight: 7 kg
