Woonyoung WY2211-TD Series DIN-Rail Transformer, 220 V to 110 V

Woonyoung WY2211-TD Series DIN-Rail Transformer, 220 V to 110 V

Single-phase DIN-rail control transformer converting a 220 V line to 110 V, standardized from 10 VA to 350 VA.

Key features

  • Single-phase multi-winding (isolating) design with separate primary and secondary windings
  • Standard ratings from 10 VA to 350 VA
  • Power indicator LED lights when AC input voltage is applied
  • Mounts directly on DIN rail; bolt mounting on panels also supported
  • Built-in thermal alarm contact for overheating protection
  • CE and RoHS marked

Specifications

Phase Single phase
Mounting DIN rail & panel (bolt mounting also possible)
Frequency 50/60 Hz
Thermal protection Thermal alarm contact (TH1-TH2): 10-60 VA 100 C, 80-350 VA 120 C
Ring terminal size 10-180 VA: max 6, min 3.5; 220-350 VA: max 9, min 4
Certifications CE, RoHS
Other ratings Available on request
Primary voltage 0-220 V
Secondary voltage 0-110 V
Capacity range 10-350 VA
WY2211-10TD Capacity: 10 VA | Dimensions W x H x D: 68.8 x 84.8 x 96.8 mm | Mounting pitch a x b: 77.5 x 50 mm | Terminal pitch c / d: 30 / 7 mm | Terminal screw: M3.5 | Weight: 0.76 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-20TD Capacity: 20 VA | Dimensions W x H x D: 68.8 x 84.8 x 96.8 mm | Mounting pitch a x b: 77.5 x 50 mm | Terminal pitch c / d: 30 / 7 mm | Terminal screw: M3.5 | Weight: 0.76 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-30TD Capacity: 30 VA | Dimensions W x H x D: 68.8 x 87.8 x 96.8 mm | Mounting pitch a x b: 77.5 x 50 mm | Terminal pitch c / d: 30 / 7 mm | Terminal screw: M3.5 | Weight: 0.89 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-40TD Capacity: 40 VA | Dimensions W x H x D: 68.8 x 93.8 x 96.8 mm | Mounting pitch a x b: 77.5 x 50 mm | Terminal pitch c / d: 30 / 7 mm | Terminal screw: M3.5 | Weight: 0.76 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-60TD Capacity: 60 VA | Dimensions W x H x D: 68.8 x 108.8 x 96.8 mm | Mounting pitch a x b: 77.5 x 50 mm | Terminal pitch c / d: 30 / 7 mm | Terminal screw: M3.5 | Weight: 0.89 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-80TD Capacity: 80 VA | Dimensions W x H x D: 86.9 x 99.9 x 106 mm | Mounting pitch a x b: 93 x 66 mm | Terminal pitch c / d: 50 / 7 mm | Terminal screw: M3.5 | Weight: 1.80 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-120TD Capacity: 120 VA | Dimensions W x H x D: 86.9 x 113.9 x 106 mm | Mounting pitch a x b: 93 x 66 mm | Terminal pitch c / d: 50 / 7 mm | Terminal screw: M3.5 | Weight: 2.40 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-180TD Capacity: 180 VA | Dimensions W x H x D: 86.9 x 128.9 x 106 mm | Mounting pitch a x b: 93 x 66 mm | Terminal pitch c / d: 50 / 7 mm | Terminal screw: M3.5 | Weight: 3.00 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-220TD Capacity: 220 VA | Dimensions W x H x D: 115 x 117.7 x 130 mm | Mounting pitch a x b: 116 x 90.9 mm | Terminal pitch c / d: 65 / 10 mm | Terminal screw: M4 | Weight: 4.00 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-280TD Capacity: 280 VA | Dimensions W x H x D: 115 x 134.7 x 130 mm | Mounting pitch a x b: 116 x 90.9 mm | Terminal pitch c / d: 65 / 10 mm | Terminal screw: M4 | Weight: 5.00 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
WY2211-350TD Capacity: 350 VA | Dimensions W x H x D: 115 x 146.7 x 130 mm | Mounting pitch a x b: 116 x 90.9 mm | Terminal pitch c / d: 65 / 10 mm | Terminal screw: M4 | Weight: 5.60 kg | Primary voltage: 0-220 V | Secondary voltage: 0-110 V
