Timer
Omron
[OMRON] — H3RN Solid-state Timer (Ultra-slim, SPDT/DPST-NO, G2R Socket, 24VAC/12-24VDC)
Family ID: OMRON-H3RN
Ultra-slim Timer for G2R Relay Socket. Short-time range: 0.1s~10min. Long-time range: 0.1min~10h. Supply voltage: 24VAC / 12VDC / 24VDC (specify at order). Socket sold separately (P2RFZ-05-E or P2R-057P for SPDT / P2RFZ-08-E or P2R-087P for DPST-NO).
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| H3RN-1 | SPDT, Short-range (0.1s~10min), 24VAC or 12/24VDC | OMRON | Type: Solid-state Timer | Contact: SPDT | Time Range: Short (0.1s to 10min) | Supply Voltage: 24VAC / 12VDC / 24VDC (specify at order) | Socket: P2RFZ-05-E (track/front) or P2R-057P (back) | ||
| H3RN-11 | SPDT, Long-range (0.1min~10h), 24VAC or 12/24VDC | OMRON | Type: Solid-state Timer | Contact: SPDT | Time Range: Long (0.1min to 10h) | Supply Voltage: 24VAC / 12VDC / 24VDC (specify at order) | Socket: P2RFZ-05-E (track/front) or P2R-057P (back) | ||
| H3RN-2 | DPST-NO, Short-range (0.1s~10min), 24VAC or 12/24VDC | OMRON | Type: Solid-state Timer | Contact: DPST-NO | Time Range: Short (0.1s to 10min) | Supply Voltage: 24VAC / 12VDC / 24VDC (specify at order) | Socket: P2RFZ-08-E (track/front) or P2R-087P (back) | ||
| H3RN-21 | DPST-NO, Long-range (0.1min~10h), 24VAC or 12/24VDC | OMRON | Type: Solid-state Timer | Contact: DPST-NO | Time Range: Long (0.1min to 10h) | Supply Voltage: 24VAC / 12VDC / 24VDC (specify at order) | Socket: P2RFZ-08-E (track/front) or P2R-087P (back) |
