Linear Bushings THK

[THK] — SK LM Shaft Support Unit Aluminum (SK10~SK40)

Family ID: THK-SK

SK type LM Shaft Support — lightweight aluminum support bracket for LM shafts. Slotted mounting surface; bolt tightening firmly secures the LM shaft. Shaft diameters: 10~40mm.

9 product codes available in this family

Product Codes & Specifications

	Product Code	Description	Brand	Spec
	SK10	THK LM shaft support, shaft φ10mm, H=32.8mm, W=42mm, L=14mm	THK	Shaft Dia.: d=10mm \| Height: H=32.8mm \| Width: W=42mm \| Length: L=14mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK12	THK LM shaft support, shaft φ12mm, H=37.5mm, W=42mm, L=14mm	THK	Shaft Dia.: d=12mm \| Height: H=37.5mm \| Width: W=42mm \| Length: L=14mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK13	THK LM shaft support, shaft φ13mm, H=37.5mm, W=42mm, L=14mm	THK	Shaft Dia.: d=13mm \| Height: H=37.5mm \| Width: W=42mm \| Length: L=14mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK16	THK LM shaft support, shaft φ16mm, H=44mm, W=48mm, L=16mm	THK	Shaft Dia.: d=16mm \| Height: H=44mm \| Width: W=48mm \| Length: L=16mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK20	THK LM shaft support, shaft φ20mm, H=51mm, W=60mm, L=20mm	THK	Shaft Dia.: d=20mm \| Height: H=51mm \| Width: W=60mm \| Length: L=20mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK25	THK LM shaft support, shaft φ25mm, H=60mm, W=70mm, L=24mm	THK	Shaft Dia.: d=25mm \| Height: H=60mm \| Width: W=70mm \| Length: L=24mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK30	THK LM shaft support, shaft φ30mm, H=70mm, W=84mm, L=28mm	THK	Shaft Dia.: d=30mm \| Height: H=70mm \| Width: W=84mm \| Length: L=28mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK35	THK LM shaft support, shaft φ35mm, H=83mm, W=98mm, L=32mm	THK	Shaft Dia.: d=35mm \| Height: H=83mm \| Width: W=98mm \| Length: L=32mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
	SK40	THK LM shaft support, shaft φ40mm, H=96mm, W=114mm, L=36mm	THK	Shaft Dia.: d=40mm \| Height: H=96mm \| Width: W=114mm \| Length: L=36mm \| Material: Aluminum \| Type: LM shaft support (clamp type) \| Feature: Slotted; bolt-tightened shaft fixing
