[OMRON] — XS Series M12 4-pin Sensor I/O Connector Cable (Single-ended XS2F + Double-ended XS5W Smart Click)
Family ID: OMRON-XS-M12
OMRON XS series M12 4-pin Sensor I/O connector cables for connecting M12 connector-type OMRON sensors and amplifiers — including E3S-DC color mark photoelectric sensors and other compatible OMRON M12 4-pin sensors. Available in two configurations: XS2F single-ended (connector + flying leads, for direct PLC wiring) and XS5W double-ended smart click (connector both sides, for connection to splitter/junction boxes). Each configuration available in straight or L-shaped (right-angle) connector types and 2m or 5m cable lengths. PVC-jacketed for general industrial use. Pin assignment: Brown (1) +V, White (2) external input or output, Blue (3) 0V, Black (4) C/Q output.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| XS2F-D421-D80-F | OMRON XS2F-D421-D80-F M12 sensor cable, single-ended, straight, 4-pin, 2m. | OMRON | Connector Size: M12 4-pin | Configuration: Single-ended, straight connector | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS2F-D421-G80-F | OMRON XS2F-D421-G80-F M12 sensor cable, single-ended, straight, 4-pin, 5m. | OMRON | Connector Size: M12 4-pin | Configuration: Single-ended, straight connector | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS2F-D422-D80-F | OMRON XS2F-D422-D80-F M12 sensor cable, single-ended, L-shaped, 4-pin, 2m. | OMRON | Connector Size: M12 4-pin | Configuration: Single-ended, L-shaped (right-angle) connector | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS2F-D422-G80-F | OMRON XS2F-D422-G80-F M12 sensor cable, single-ended, L-shaped, 4-pin, 5m. | OMRON | Connector Size: M12 4-pin | Configuration: Single-ended, L-shaped (right-angle) connector | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS5W-D421-D81-F | OMRON XS5W-D421-D81-F M12 sensor cable, double-ended smart click, straight/straight, 4-pin, 2m. | OMRON | Connector Size: M12 4-pin | Configuration: Double-ended smart click, straight/straight | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS5W-D421-G81-F | OMRON XS5W-D421-G81-F M12 sensor cable, double-ended smart click, straight/straight, 4-pin, 5m. | OMRON | Connector Size: M12 4-pin | Configuration: Double-ended smart click, straight/straight | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS5W-D422-D81-F | OMRON XS5W-D422-D81-F M12 sensor cable, double-ended smart click, L-shaped/L-shaped, 4-pin, 2m. | OMRON | Connector Size: M12 4-pin | Configuration: Double-ended smart click, L-shaped/L-shaped | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors | ||
| XS5W-D422-G81-F | OMRON XS5W-D422-D81-F M12 sensor cable, double-ended smart click, L-shaped/L-shaped, 4-pin, 5m. | OMRON | Connector Size: M12 4-pin | Configuration: Double-ended smart click, L-shaped/L-shaped | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors |
