[THK] — Cam Follower CF (Economy Type)
Family ID: THK-CF
THK CF type Cam Follower, economy series. Driver slot on stud head for easy installation. Stainless steel type (M) also available for corrosion resistance. Stud diameter d = 5~10mm, outer diameter D = 13~26mm. Options: V (full needle), M (stainless), UU (seal), R (spherical outer ring). Spherical radius: R250 (CF5) / R500 (CF6~CF10).
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| CF5 | THK Cam Follower CF5 (economy), d=5mm, D=13mm, C(cage)=3.14kN | THK | Stud Diameter (d): 5 mm | Outer Diameter (D): 13 mm | Outer Ring Width (C): 9 mm | Stud Thread: M5×0.8 | Total Length (B): 23 mm | Basic Dynamic Load Rating C (cage): 3.14 kN | Basic Static Load Rating C0 (cage): 2.77 kN | Basic Dynamic Load Rating C (full needle): 5.1 kN | Basic Static Load Rating C0 (full needle): 5.5 kN | Max Allowable Load F0 (cylindrical): 1.42 kN | Max Allowable Load F0 (spherical): 2.25 kN | Track Load Capacity (full needle): 0.53 kN | Limit Speed (cage): 29000 min⁻¹ | Limit Speed (full needle): 11600 min⁻¹ | Mass (cage): 10.5 g | Mass (full needle): 11.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R250 | ||
| CF6 | THK Cam Follower CF6 (economy), d=6mm, D=16mm, C(cage)=3.59kN | THK | Stud Diameter (d): 6 mm | Outer Diameter (D): 16 mm | Outer Ring Width (C): 11 mm | Stud Thread: M6×1 | Total Length (B): 28 mm | Basic Dynamic Load Rating C (cage): 3.59 kN | Basic Static Load Rating C0 (cage): 3.58 kN | Basic Dynamic Load Rating C (full needle): 6.94 kN | Basic Static Load Rating C0 (full needle): 8.5 kN | Max Allowable Load F0 (cylindrical): 2.11 kN | Max Allowable Load F0 (spherical): 3.43 kN | Track Load Capacity (full needle): 1.08 kN | Limit Speed (cage): 25000 min⁻¹ | Limit Speed (full needle): 11000 min⁻¹ | Mass (cage): 18.5 g | Mass (full needle): 19.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500 | ||
| CF8 | THK Cam Follower CF8 (economy), d=8mm, D=19mm, C(cage)=4.17kN | THK | Stud Diameter (d): 8 mm | Outer Diameter (D): 19 mm | Outer Ring Width (C): 11 mm | Stud Thread: M8×1.25 | Total Length (B): 32 mm | Basic Dynamic Load Rating C (cage): 4.17 kN | Basic Static Load Rating C0 (cage): 4.65 kN | Basic Dynamic Load Rating C (full needle): 8.13 kN | Basic Static Load Rating C0 (full needle): 11.2 kN | Max Allowable Load F0 (cylindrical): 4.73 kN | Max Allowable Load F0 (spherical): 4.02 kN | Track Load Capacity (full needle): 1.37 kN | Limit Speed (cage): 20000 min⁻¹ | Limit Speed (full needle): 8700 min⁻¹ | Mass (cage): 28.5 g | Mass (full needle): 29.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500 | ||
| CF10 | THK Cam Follower CF10 (economy), d=10mm, D=22mm, C(cage)=5.33kN | THK | Stud Diameter (d): 10 mm | Outer Diameter (D): 22 mm | Outer Ring Width (C): 12 mm | Stud Thread: M10×1.25 | Total Length (B): 36 mm | Basic Dynamic Load Rating C (cage): 5.33 kN | Basic Static Load Rating C0 (cage): 6.78 kN | Basic Dynamic Load Rating C (full needle): 9.42 kN | Basic Static Load Rating C0 (full needle): 14.3 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 4.7 kN | Track Load Capacity (full needle): 1.67 kN | Limit Speed (cage): 17000 min⁻¹ | Limit Speed (full needle): 7200 min⁻¹ | Mass (cage): 45.0 g | Mass (full needle): 46.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500 | ||
| CF10-1 | THK Cam Follower CF10-1 (economy), d=10mm, D=26mm, C(cage)=5.33kN | THK | Stud Diameter (d): 10 mm | Outer Diameter (D): 26 mm | Outer Ring Width (C): 12 mm | Stud Thread: M10×1.25 | Total Length (B): 36 mm | Basic Dynamic Load Rating C (cage): 5.33 kN | Basic Static Load Rating C0 (cage): 6.78 kN | Basic Dynamic Load Rating C (full needle): 9.42 kN | Basic Static Load Rating C0 (full needle): 14.3 kN | Max Allowable Load F0 (cylindrical): 5.81 kN | Max Allowable Load F0 (spherical): 5.49 kN | Track Load Capacity (full needle): 2.06 kN | Limit Speed (cage): 17000 min⁻¹ | Limit Speed (full needle): 7200 min⁻¹ | Mass (cage): 60.0 g | Mass (full needle): 61.0 g | Options: V=full needle, M=stainless, UU=seal, R=spherical outer ring | Spherical radius: R500 |
