[THK] — Cross Roller Table VRU1 (W30×H17, M2)
Family ID: THK-VRU1
THK VRU Cross Roller Table, VRU1 frame. Table width W=30mm, height M=17mm, table mounting tap M2. Base mounting through-hole d×D×h = 2.55×4.1×2.5mm. Stroke range 12~50mm. Side mounting taps provided. Stainless steel type available on request (approx. 0.04~0.14 kg).
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| VRU1025 | THK Cross Roller Table VRU1025, stroke 12mm, 5 rollers, 0.08kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 12 mm | Rollers (Z): 5 | Mass (standard): 0.08 kg | Mass (stainless): 0.04 kg | Basic Dynamic Load Rating C: 0.46 kN | Basic Static Load Rating C0: 0.61 kN | Static Allowable Moment MA: 1.52 N·m | Static Allowable Moment MB: 1.25 N·m | Static Allowable Moment MC: 4.12 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request | ||
| VRU1035 | THK Cross Roller Table VRU1035, stroke 18mm, 7 rollers, 0.11kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 18 mm | Rollers (Z): 7 | Mass (standard): 0.11 kg | Mass (stainless): 0.05 kg | Basic Dynamic Load Rating C: 0.63 kN | Basic Static Load Rating C0: 0.92 kN | Static Allowable Moment MA: 2.62 N·m | Static Allowable Moment MB: 2.32 N·m | Static Allowable Moment MC: 6.18 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request | ||
| VRU1045 | THK Cross Roller Table VRU1045, stroke 25mm, 10 rollers, 0.15kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 25 mm | Rollers (Z): 10 | Mass (standard): 0.15 kg | Mass (stainless): 0.07 kg | Basic Dynamic Load Rating C: 0.95 kN | Basic Static Load Rating C0: 1.53 kN | Static Allowable Moment MA: 4.14 N·m | Static Allowable Moment MB: 4.53 N·m | Static Allowable Moment MC: 10.3 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request | ||
| VRU1055 | THK Cross Roller Table VRU1055, stroke 32mm, 12 rollers, 0.18kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 32 mm | Rollers (Z): 12 | Mass (standard): 0.18 kg | Mass (stainless): 0.09 kg | Basic Dynamic Load Rating C: 1.09 kN | Basic Static Load Rating C0: 1.83 kN | Static Allowable Moment MA: 5.92 N·m | Static Allowable Moment MB: 6.41 N·m | Static Allowable Moment MC: 12.4 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request | ||
| VRU1065 | THK Cross Roller Table VRU1065, stroke 40mm, 14 rollers, 0.21kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 40 mm | Rollers (Z): 14 | Mass (standard): 0.21 kg | Mass (stainless): 0.1 kg | Basic Dynamic Load Rating C: 1.23 kN | Basic Static Load Rating C0: 2.14 kN | Static Allowable Moment MA: 8.08 N·m | Static Allowable Moment MB: 8.62 N·m | Static Allowable Moment MC: 14.4 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request | ||
| VRU1075 | THK Cross Roller Table VRU1075, stroke 45mm, 18 rollers, 0.24kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 45 mm | Rollers (Z): 18 | Mass (standard): 0.24 kg | Mass (stainless): 0.12 kg | Basic Dynamic Load Rating C: 1.5 kN | Basic Static Load Rating C0: 2.75 kN | Static Allowable Moment MA: 13.3 N·m | Static Allowable Moment MB: 14.0 N·m | Static Allowable Moment MC: 18.6 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request | ||
| VRU1085 | THK Cross Roller Table VRU1085, stroke 50mm, 20 rollers, 0.27kg | THK | Frame: VRU1 | Table Width (W): 30 mm | Height (M): 17 mm | Stroke: 50 mm | Rollers (Z): 20 | Mass (standard): 0.27 kg | Mass (stainless): 0.13 kg | Basic Dynamic Load Rating C: 1.63 kN | Basic Static Load Rating C0: 3.05 kN | Static Allowable Moment MA: 16.4 N·m | Static Allowable Moment MB: 17.2 N·m | Static Allowable Moment MC: 20.6 N·m | Table Mounting Tap: M2 | Base Hole (d×D×h): 2.55×4.1×2.5 mm | Stainless Type: available on request |
