Roller Guides
THK
[THK] — Cross Roller Guide VR12
Family ID: THK-VR12
Cross Roller Guide VR12 type. Rail length 200~1200mm, 7~41 rollers per set. Basic dynamic load rating C_Z = 17.6 kN per roller; static C0Z = 17.2 kN per roller. 4-rail + 2-cage assembly (1 set). Roller diameter 11.906 mm (cross arrangement). Stainless type (VR12M) available on request.
11 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| VR12-200x7Z | THK Cross Roller Guide VR12, Rail 200mm, 7 rollers, max stroke 110mm | THK | Rail Length: 200 mm | Rollers (Z): 7 | Max Stroke: 110 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-300x10Z | THK Cross Roller Guide VR12, Rail 300mm, 10 rollers, max stroke 190mm | THK | Rail Length: 300 mm | Rollers (Z): 10 | Max Stroke: 190 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-400x14Z | THK Cross Roller Guide VR12, Rail 400mm, 14 rollers, max stroke 230mm | THK | Rail Length: 400 mm | Rollers (Z): 14 | Max Stroke: 230 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-500x17Z | THK Cross Roller Guide VR12, Rail 500mm, 17 rollers, max stroke 310mm | THK | Rail Length: 500 mm | Rollers (Z): 17 | Max Stroke: 310 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-600x21Z | THK Cross Roller Guide VR12, Rail 600mm, 21 rollers, max stroke 350mm | THK | Rail Length: 600 mm | Rollers (Z): 21 | Max Stroke: 350 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-700x24Z | THK Cross Roller Guide VR12, Rail 700mm, 24 rollers, max stroke 430mm | THK | Rail Length: 700 mm | Rollers (Z): 24 | Max Stroke: 430 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-800x28Z | THK Cross Roller Guide VR12, Rail 800mm, 28 rollers, max stroke 470mm | THK | Rail Length: 800 mm | Rollers (Z): 28 | Max Stroke: 470 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-900x31Z | THK Cross Roller Guide VR12, Rail 900mm, 31 rollers, max stroke 550mm | THK | Rail Length: 900 mm | Rollers (Z): 31 | Max Stroke: 550 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-1000x34Z | THK Cross Roller Guide VR12, Rail 1000mm, 34 rollers, max stroke 630mm | THK | Rail Length: 1000 mm | Rollers (Z): 34 | Max Stroke: 630 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-1100x38Z | THK Cross Roller Guide VR12, Rail 1100mm, 38 rollers, max stroke 670mm | THK | Rail Length: 1100 mm | Rollers (Z): 38 | Max Stroke: 670 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) | ||
| VR12-1200x41Z | THK Cross Roller Guide VR12, Rail 1200mm, 41 rollers, max stroke 750mm | THK | Rail Length: 1200 mm | Rollers (Z): 41 | Max Stroke: 750 mm | Roller Diameter: 11.906 mm (cross roller) | Basic Dynamic Load Rating C_Z: 17.6 kN (per roller) | Basic Static Load Rating C0Z: 17.2 kN (per roller) | Rail Mass: 5.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR12M (order basis) |
