Pressure Control Modular
Yuken
Yuken — 01 Series Brake Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-01-BRAKE
01 Series Modular Valves — Brake. Sandwich/stack mounting. Detailed specifications by inquiry.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MBR-01-C-30 | Brake modular valve, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Brake | Pressure Range: C: max 14 MPa | Max Pressure: 25 MPa | Max Flow: 35 L/min | ||
| MBR-01-H-30 | Brake modular valve, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Brake | Pressure Range: H: 7–21 MPa | Max Pressure: 25 MPa | Max Flow: 35 L/min |
