Yuken — 06 Series Reducing Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-06-REDUCING
06 (3/4) Series Reducing Modular Valves. Sandwich/stack mounting (ISO 4401). P/A/B-line, pressure ranges A/B/C/H. Max 35 MPa / 500 L/min.
12 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MRP-06-A-70 | Reducing modular valve, P-line, range A | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 125 L/min | ||
| MRP-06-B-70 | Reducing modular valve, P-line, range B | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRP-06-C-70 | Reducing modular valve, P-line, range C | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRP-06-H-70 | Reducing modular valve, P-line, range H | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRA-06-A-70 | Reducing modular valve, A-line, range A | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 125 L/min | ||
| MRA-06-B-70 | Reducing modular valve, A-line, range B | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRA-06-C-70 | Reducing modular valve, A-line, range C | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRA-06-H-70 | Reducing modular valve, A-line, range H | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRB-06-A-70 | Reducing modular valve, B-line, range A | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 125 L/min | ||
| MRB-06-B-70 | Reducing modular valve, B-line, range B | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRB-06-C-70 | Reducing modular valve, B-line, range C | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min | ||
| MRB-06-H-70 | Reducing modular valve, B-line, range H | Yuken | Series: 06 (3/4) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 500 L/min |
