Yuken — 01 Series Reducing Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-01-REDUCING
01 Series Modular Valves — Reducing. Sandwich/stack mounting. Detailed specifications by inquiry.
16 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MRP-01-A-70 | Reducing modular valve, P-line, range A | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MRP-01-A-B-70 | Reducing modular valve, P-line, range A | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MRP-01-B-70 | Reducing modular valve, P-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: B: 0.8–7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MRP-01-B-B-70 | Reducing modular valve, P-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: B: 0.8–7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MRP-01-C-70 | Reducing modular valve, P-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MRP-01-C-B-70 | Reducing modular valve, P-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MRP-01-H-70 | Reducing modular valve, P-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MRP-01-H-B-70 | Reducing modular valve, P-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MRA-01-A-70 | Reducing modular valve, A-line, range A | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRA-01-B-70 | Reducing modular valve, A-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: B: 0.8–7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRA-01-C-70 | Reducing modular valve, A-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRA-01-H-70 | Reducing modular valve, A-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRB-01-A-70 | Reducing modular valve, B-line, range A | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: A: max 3.5 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRB-01-B-70 | Reducing modular valve, B-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: B: 0.8–7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRB-01-C-70 | Reducing modular valve, B-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MRB-01-H-70 | Reducing modular valve, B-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min |
