Yuken — 01 Series Relief Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-01-RELIEF
01 Series Modular Valves — Relief. Sandwich/stack mounting. Detailed specifications by inquiry.
16 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MBP-01-B-70 | Relief modular valve, P-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MBP-01-B-B-70 | Relief modular valve, P-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MBP-01-C-70 | Relief modular valve, P-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MBP-01-C-B-70 | Relief modular valve, P-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MBP-01-H-70 | Relief modular valve, P-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MBP-01-H-B-70 | Relief modular valve, P-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MBP-01-K-70 | Relief modular valve, P-line, range K | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side | ||
| MBP-01-K-B-70 | Relief modular valve, P-line, range K | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side | ||
| MBA-01-B-70 | Relief modular valve, A-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBA-01-C-70 | Relief modular valve, A-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBA-01-H-70 | Relief modular valve, A-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBA-01-K-70 | Relief modular valve, A-line, range K | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBB-01-B-70 | Relief modular valve, B-line, range B | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBB-01-C-70 | Relief modular valve, B-line, range C | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBB-01-H-70 | Relief modular valve, B-line, range H | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MBB-01-K-70 | Relief modular valve, B-line, range K | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min |
